| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15770042 |
BRACKET, RKR PNL MLDG (INCLS 24) |
CK159 (06) (BPH) |
2005-2006 |
01 |
| 001 |
15770043 |
BRACKET, RKR PNL MLDG (INCLS 24) |
CK159 (06) (BPH) |
2005-2006 |
01 |
| 002 |
15079209 |
TAPE, RKR PNL MLDG BLACKOUT (REAR) |
CK159 (06) (BPH) |
2005-2006 |
01 |
| 002 |
15079210 |
TAPE, RKR PNL MLDG BLACKOUT (REAR) |
CK159 (06) (BPH) |
2005-2006 |
01 |
| 003 |
11609715 |
RIVET, RR WHL OPG MLDG RET (6.3 SHANK DIA) (16.76 LENGTH, 13.46 OD, 1.52-8.26 GRIP) |
CK157, 159 (06) (BPH) |
2005-2006 |
06 |
| 004 |
15770038 |
RETAINER, RR WHL OPG MLDG (PART OF 11) (Z SHAPE) |
CK159 (06) (BPH) |
2005-2006 |
02 |
| 005 |
11516807 |
RIVET, POP, 4.8 DIA, 19.9 LONG, 16 OD, 5-5.25 HOLE, 1-9 GRIP RANGE, AL, BLACK (PART OF 11)
|
2005-2006 |
06 |
|
| 006 |
15770030 |
CLIP, RR WHL OPG MLDG (PART OF 11) |
CK159 (06) (BPH) |
2005-2006 |
06 |
| 007 |
10362372 |
BRACKET, ASST STEP |
CK157, 159 (06) (BPH) |
2005-2006 |
10 |
| 008 |
11609733 |
БОЛТ, HEX W/CON WA, M8X1.25X30, 20 THD, 24 OD, 10.9, GMW4205, MAT POINT (ASST STEP BRKT)
|
2005-2006 |
10 |
|
| 009 |
15773385 |
PLATE, ASST STEP ANC (INCLS STUDS) |
CK157, 159 (06) (BPH) |
2005-2006 |
10 |
| 010 |
19167221 |
RIVET, ASST STEP BRKT |
CK159 (06) (BPH) |
2005-2006 |
02 |
| 011 |
15769301 |
MOLDING, RR WHL OPG FRT (INCLS 4-6, 17) (CHARCOAL) (EXCLUDES FASTENERS) |
CK159 (06) (BPH) |
2005-2006 |
01 |
| 011 |
15769302 |
MOLDING, RR WHL OPG FRT (INCLS 4-6, 17) (CHARCOAL) (EXCLUDES FASTENERS) |
CK159 (06) (BPH) |
2005-2006 |
01 |
| 012 |
88937278 |
PAD, ASST STEP (PART OF 13) (22 LONG) (2 RT, 2 LEFT) |
CK159 (06) (BPH) |
2005-2006 |
04 |
| 013 |
15766082 |
STEP, ASST (INCLS 12) |
CK159 (06) (BPH) |
2005-2006 |
01 |
| 013 |
15766083 |
STEP, ASST (INCLS 12) |
CK159 (06) (BPH) |
2005-2006 |
01 |
| 014 |
11609746 |
ГАЙКА, HFH, M8X1.25, 8.9THK, 17.6 O.D., 10 STL, GMW3200, PREV TORQUE (ASST STEP BRKT)
|
2005-2006 |
04 |
|
| 015 |
15773389 |
PLATE, ASST STEP ANC (INCLS HOLES) |
CK157, 159 (06) (BPH) |
2005-2006 |
10 |
| 016 |
15766367 |
MOLDING, RKR PNL (INCLS 17) (GRAY) (MOLDED IN COLOR) |
CK159 (06) (BPH) |
2005-2006 |
01 |
| 016 |
15766368 |
MOLDING, RKR PNL (INCLS 17) (GRAY) (MOLDED IN COLOR) |
CK159 (06) (BPH) |
2005-2006 |
01 |
| 017 |
15993201 |
RETAINER, PUBX OTR S/PNL EXTN (PART OF 11, 16) (FOR 9.3MM DIA HOLE) (NYLON)
| CK159 (06) (BPH) |
2005-2006 |
02 |
|
| 018 |
15768594 |
MOLDING, F/FDR WHL OPG |
CK159 (06) (BPH) |
2006-2006 |
01 |
| 018 |
15768595 |
MOLDING, F/FDR WHL OPG |
CK159 (06) (BPH) |
2006-2006 |
01 |
| 019 |
20664092 |
RETAINER, RR WHL OPG MLDG (BLACK) (6.3MM DIA X 23MM) (1.276)
| CK159 (06) (BPH) |
2005-2006 |
06 |
|
| 020 |
15993201 |
RIVET, F/FDR WHL OPG MLDG (FOR 9.3MM DIA HOLE) (NYLON) (17.505)
| CK159 (06) (BPH) |
2005-2006 |
02 |
|
| 021 |
15770036 |
RETAINER, F/FDR WHL OPG MLDG |
CK159 (06) (BPH) |
2006-2006 |
02 |
| 022 |
|
CLIP, F/FDR UPR MLDG |
|
2005-2006 |
|
| 023 |
15079205 |
TAPE, RKR PNL MLDG BLACKOUT (FRONT) |
CK1 (06) (BPH) |
2005-2006 |
01 |
| 023 |
15079206 |
TAPE, RKR PNL MLDG BLACKOUT (FRONT) |
CK1 (06) (BPH) |
2005-2006 |
01 |
| 024 |
11609715 |
RIVET, BODY SI LWR MLDG RET (PART OF 1) (6.3 SHANK DIA) (16.76 LENGTH, 13.46 OD, 1.52-8.26 GRIP) |
CK157, 159 (06) (BPH) |
2006-2006 |
10 |
