| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
11508567 |
БОЛТ, HFH, M6X1X10, 9.8, GM6174M (МАСЛЯНЫЙ ПОДДОН CVR) |
|
2002-2005 |
04 |
| 002 |
11588714 |
БОЛТ, HFH, M6X1X30, 22.7 THD, 14.2 OD, 8.8, GMW3359, M-PT. (МАСЛЯНЫЙ ПОДДОН CVR) (*KIT1)
|
2002-2005 |
04 |
|
| 003 |
|
MOTOR, RR STRG ACTC (*KIT1) |
|
2004-2005 |
|
| 003 |
|
MOTOR, RR STRG ACTC (*KIT1) |
|
2005-2005 |
|
| 004 |
26080651 |
SEAL, RR WHL STRG ACTR MOT (O-RING) (*KIT1) |
CK2 (06) (NYS) |
2003-2005 |
01 |
| 005 |
|
GEAR, PLANETARY |
|
2004-2005 |
|
| 005 |
|
GEAR, PLANETARY |
|
2005-2005 |
|
| 006 |
|
BEARING, PINION UPPER |
|
2004-2005 |
|
| 006 |
|
BEARING, PINION UPPER |
|
2005-2005 |
|
| 007 |
|
RING, RETAINING |
|
2004-2005 |
|
| 007 |
|
RING, RETAINING |
|
2005-2005 |
|
| 008 |
|
ROD, OTR TIE (*KIT2) |
|
2004-2005 |
|
| 008 |
|
ROD, OTR TIE (*KIT2) |
|
2005-2005 |
|
| 009 |
11516073 |
ГАЙКА, M12X1.75 (R/SEAT BELT (BKL SI)) (*KIT2, KIT3)
|
2002-2005 |
01 |
|
| 010 |
|
ROD, INR TIE (*KIT3) |
|
2004-2005 |
|
| 010 |
|
ROD, INR TIE (*KIT3) |
|
2005-2005 |
|
| 011 |
|
CLAMP, INNER SUPPORT |
|
2004-2005 |
|
| 011 |
|
CLAMP, INNER SUPPORT |
|
2005-2005 |
|
| 012 |
26083915 |
ГАЙКА, RR WHL STRG LNKG OTR TIE ROD ADJ |
CK1, 2 (06) (NYS) |
2003-2005 |
02 |
| 013 |
|
CLAMP, TIE ROD END (*KIT3) |
|
2004-2005 |
|
| 013 |
|
CLAMP, TIE ROD END (*KIT3) |
|
2005-2005 |
|
| 014 |
|
BOOT, TIE ROD (*KIT4) |
|
2004-2005 |
|
| 014 |
|
BOOT, TIE ROD (*KIT4) |
|
2005-2005 |
|
| 015 |
|
CLAMP, SEAL RET (*KIT3) |
|
2004-2005 |
|
| 015 |
|
CLAMP, SEAL RET (*KIT3) |
|
2005-2005 |
|
| 016 |
|
SEAL, PINION |
|
2004-2005 |
|
| 016 |
|
SEAL, PINION |
|
2005-2005 |
|
| 017 |
|
RING, GEAR |
|
2004-2005 |
|
| 017 |
|
RING, GEAR |
|
2005-2005 |
|
| 018 |
|
SEAL, O-RING |
|
2004-2005 |
|
| 018 |
|
SEAL, O-RING |
|
2005-2005 |
|
| 019 |
|
ШЛАНГИ, ACTUATOR |
|
2004-2005 |
|
| 019 |
|
ШЛАНГИ, ACTUATOR |
|
2005-2005 |
|
| 020 |
|
COVER, SENSOR (*KIT5) |
|
2004-2005 |
|
| 020 |
|
COVER, SENSOR (*KIT5) |
|
2005-2005 |
|
| 021 |
26077557 |
БОЛТ, RR WHL STRG POSN SEN (*KIT5) |
CK1, 2 (NYS) |
2002-2005 |
05 |
| 022 |
|
SENSOR, RR ACTUATOR (*KIT5) |
|
2004-2005 |
|
| 022 |
|
SENSOR, RR ACTUATOR (*KIT5) |
|
2005-2005 |
|
| 023 |
|
SEAL, RR WHL STRG POSN SEN (O-RING) (*KIT5) |
1, 2 (06-53) |
2005-2005 |
|
| 024 |
|
ГАЙКА, (*KIT5) |
|
2004-2005 |
|
| 024 |
|
ГАЙКА, (*KIT5) |
|
2005-2005 |
|
| 025 |
|
SHIELD, GREASE |
|
2004-2005 |
|
| 025 |
|
SHIELD, GREASE |
|
2005-2005 |
|
| 026 |
|
RING, RETAINING |
|
2004-2005 |
|
| 026 |
|
RING, RETAINING |
|
2005-2005 |
|
| 027 |
|
BEARING, LOWER |
|
2004-2005 |
|
| 027 |
|
BEARING, LOWER |
|
2005-2005 |
|
| 028 |
|
CLAMP, INNER SUPPORT |
|
2004-2005 |
|
| 028 |
|
CLAMP, INNER SUPPORT |
|
2005-2005 |
|
| 029 |
|
RING, BULKHEAD RET |
|
2004-2005 |
|
| 029 |
|
RING, BULKHEAD RET |
|
2005-2005 |
|
| 030 |
|
BUSHING, BULKHEAD |
|
2004-2005 |
|
| 030 |
|
BUSHING, BULKHEAD |
|
2005-2005 |
|
| 031 |
|
SEAL, O-RING |
|
2004-2005 |
|
| 031 |
|
SEAL, O-RING |
|
2005-2005 |
|
| 032 |
|
BULKHEAD, |
|
2004-2005 |
|
| 032 |
|
BULKHEAD, |
|
2005-2005 |
|
| 033 |
|
ПРУЖИНА, CREST |
|
2004-2005 |
|
| 033 |
|
ПРУЖИНА, CREST |
|
2005-2005 |
|
| 034 |
|
CUP, RETAINER |
|
2004-2005 |
|
| 034 |
|
CUP, RETAINER |
|
2005-2005 |
|
| 035 |
|
RING, RETAINING |
|
2004-2005 |
|
| 035 |
|
RING, RETAINING |
|
2005-2005 |
|
| 036 |
88964489 |
ACTUATOR, RR WHL STRG (INCLS 1-35) |
CK2 (06) (NYS) |
2003-2005 |
01 |
| K01 |
26108739 |
MOTOR KIT, RR WHL STRG ACTR (INCLS 2, 3, 4) |
CK2 (06) (GT4, GT5, G86, NYS) |
2003-2005 |
01 |
| K02 |
26102900 |
ROD KIT, RR WHL STRG LNKG OTR TIE (INCLS 8, 9) |
CK2 (06) (NYS) |
2003-2005 |
02 |
| K03 |
26091588 |
ROD KIT, RR WHL STRG LNKG INR TIE (INCLS 9, 10, 13, 15)
| CK2 (06) (NYS) |
2003-2005 |
02 |
|
| K04 |
88963416 |
BOOT KIT, RR WHL STRG ACTR (INCLS 14) (THE RUBBER JOINT BOOT) |
CK2 (06) (GT4, GT5, G86, NYS) |
2003-2005 |
02 |
| K05 |
26091590 |
SENSOR KIT, RR WHL STRG POSN (INCLS 20-24) |
CK2 (06) (NYS) |
2003-2005 |
01 |
