| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15226272 |
HANDLE, PARK BRK REL (INCLS CABLE) (*KIT1)
| CK2 (06-36) (JH2, JH6) |
2005-2006 |
01 |
|
| 002 |
11516567 |
BOLT/SCREW, HEX W/FL WA 17 OD, M6X1X20, 9.8, 4345M, DOG PT (PARK BRK REL HDL HSG) |
|
2000-2006 |
01 |
| 003 |
89059136 |
PAD, PARK BRK LVR PED (*KIT1) |
CK2 (06) (JH2, JH6) |
2005-2006 |
01 |
| 003 |
89059136 |
PAD, PARK BRK LVR PED (*KIT1) |
K2 (36) (JH2, JH6) |
2005-2006 |
01 |
| 004 |
|
LEVER, PARK BRK (*KIT1) |
|
2000-2006 |
|
| 004 |
15143446 |
LEVER, PARK BRK (INCLS BUMPER, CABLE PAD) (*KIT1) |
CK1, 2 (06) (JH2, JH6) |
2005-2005 |
01 |
| 004 |
15143446 |
LEVER, PARK BRK (INCLS BUMPER, CABLE PAD) (*KIT1) |
K2 (36) (JH2, JH6) |
2005-2005 |
01 |
| 005 |
11517560 |
SCREW, FLAT WA (NRW) AND HX WA HD, M8X1.25X25 (PARK BRK RR CBL) |
|
2000-2006 |
05 |
| 006 |
15757271 |
GUIDE, PARK BRK RR CBL (REAR) |
CK2 (06-36) |
2000-2006 |
01 |
| 007 |
15046320 |
GUIDE, PARK BRK RR CBL (FRONT) |
CK2 (06-36) |
2000-2006 |
01 |
| 008 |
15102289 |
CABLE, PARK BRK RR (ACDelco #15102289) |
K2 (06-36) (EXC NYS) |
2004-2005 |
01 |
| 009 |
11570082 |
БОЛТ, HFH, M8X1.25X22, 19 THD, 18 OD, 10.9, GMW3359 (PARK BRK RR) (ACDelco #11570082)
|
2000-2006 |
01 |
|
| 010 |
15941089 |
CABLE, PARK BRK RR (INCLS 11) (ACDelco #15941089) |
CK2 (06) (EXC NYS) |
2005-2005 |
01 |
| 010 |
15941089 |
CABLE, PARK BRK RR (INCLS 11) (ACDelco #15941089) |
K2 (36) (EXC NYS) |
2005-2005 |
01 |
| 011 |
15030046 |
CLIP, PARK BRK RR CBL (PART OF 10) |
CK2 (06) (LQ4, JH6) |
2005-2006 |
01 |
| 011 |
15733984 |
CLIP, PARK BRK RR CBL (PART OF 10) |
CK2 (JH6) |
2002-2006 |
01 |
| 012 |
11570082 |
БОЛТ, HFH, M8X1.25X22, 19 THD, 18 OD, 10.9, GMW3359 (PARK BRK RR CBL CLIP) (ACDelco #11570082)
|
2000-2006 |
01 |
|
| 013 |
25890197 |
CABLE, PARK BRK INTER (W/EQUALIZER) (ACDelco #25890197) |
CK259 (06) |
2005-2005 |
01 |
| 013 |
25890197 |
CABLE, PARK BRK INTER (W/EQUALIZER) (ACDelco #25890197) |
K259 (36) |
2005-2005 |
01 |
| 014 |
|
CABLE, PARK BRK FRT (*KIT1) |
|
2003-2005 |
|
| 015 |
15045983 |
SWITCH, PARK BRK IND (*KIT1) |
CK1, 2, 3 |
2001-2006 |
01 |
| 016 |
09418944 |
SCREW, HWH, SELF TAP, #10-16X1, 3/8 O.D., M6010M, ZN (PARK BRK IND) |
|
2000-2006 |
01 |
| 017 |
11516780 |
ГАЙКА, HEX W/CON WA, M8X1.25, 10THK, 19 O.D., 10, 7111M (PARK BRK CONT) (8.917)
|
2000-2006 |
03 |
|
| K01 |
25780186 |
MODULE, PARK BRK CONT (INCLS 1, 3, 4, 14, 15) (INCLS HANDLE, LEVER, CABLE SWITCH) |
K2 (06-36) (JH2, JH6) |
2005-2006 |
01 |
