| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 002 |
11516521 |
БОЛТ, HFH M6X1X20, 9.8, 7114M, DOG PT, 14.2 OD (GEN CONT MDL COOL RAD BRKT) |
|
2005-2007 |
02 |
| 004 |
|
GROMMET, GEN CONT MDL COOL RAD (PART OF 5) |
|
2005-2007 |
|
| 007 |
|
RETAINER, GEN CONT MDL COOL RAD PIPE FITTING (PART OF 6) |
|
2005-2007 |
|
| 008 |
11518646 |
БОЛТ, HEX HD, W/CON WA, M6X1X30, 24.33THD, 17 OD, 9.8, 6138M, BLK (GEN CONT MDL COOL RAD) |
|
2005-2007 |
02 |
| 009 |
|
GROMMET, GEN CONT MDL COOL RAD BRKT (PART OF 5) |
|
2005-2007 |
|
| 010 |
11609374 |
BOLT-WASHER, M6X1X16, 17 OD, 12 THD, 9.8, GMW3359, 1.47 H-REG FL WA. (GEN CONT MDL COOL RAD) |
|
2005-2007 |
02 |
