| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 003 |
97306382 |
DUCT, CTR INT MANIF |
CK2, 3 (LLY) |
2004-2005 |
01 |
| 009 |
94004042 |
STUD, INT MANIF (M8X25 L=37) (M8X25 L-37) (3.417) |
CK2, 3 (LLY) |
2005-2005 |
01 |
| 009 |
94013084 |
STUD, INT MANIF (UPPER CORNERS) (3.358) |
CK2, 3 (LLY) |
2004-2005 |
04 |
| 009 |
94340628 |
STUD, INT MANIF (BOTTOM OF UPPER INTAKE) |
CK2, 3 (LLY) |
2004-2005 |
04 |
| 010 |
97251963 |
GASKET, INT MANIF TUBE (RECTANGULAR (RUBBER)GASKET) |
CK2, 3 (LLY) |
2004-2005 |
02 |
| 013 |
94009660 |
БОЛТ, INT MANIF (M8X28) (3.278) |
CK2, 3 (LLY) |
2004-2005 |
02 |
| 013 |
94010881 |
БОЛТ, INT MANIF (M8X25 FLANGE) (2.483) |
CK2, 3 (LLY) |
2004-2005 |
18 |
| 032 |
94013083 |
STUD, ENG OIL CLR (TOP OF VLV CVR) (M8X20 L=38) (3.162) |
CK2, 3 (LLY) |
2004-2005 |
01 |
| 053 |
94010021 |
БОЛТ, EGR VLV ADAP PIPE (M8X60) (1.251) |
CK2, 3 (LLY) |
2004-2005 |
02 |
| 055 |
94009471 |
NUT (ACCEL PED LVR SUPT) |
|
2004-2005 |
04 |
| 064 |
94013084 |
STUD, INT MANIF (UPPER CORNERS) (3.358) |
CK2, 3 (LLY) |
2004-2005 |
04 |
| 144 |
94011756 |
БОЛТ, MAP SEN (9.190) |
CK2, 3 (LLY) |
2005-2005 |
01 |
| 300 |
|
COVER, INT MANIF |
|
2004-2005 |
|
| 318 |
94009481 |
ГАЙКА, ENG MT BRKT (M8X1.25X8) (7.242) |
CK2, 3 (LLY) |
2004-2005 |
AR |
| 364 |
97306568 |
GASKET, INT MANIF TUBE |
CK2, 3 (LLY) |
2004-2005 |
01 |
| 365 |
97729991 |
SEAL, INT MANIF |
CK2, 3 (LLY) |
2004-2005 |
02 |
| 595 |
97327852 |
BRACKET, MAP SEN |
CK2, 3 (LLY) |
2004-2005 |
01 |
| 740 |
97303647 |
TUBE, EGR VLV INT MANIF PASG |
CK2, 3 (LLY) |
2004-2005 |
01 |
| 741 |
97305297 |
TUBE, INT MANIF (MATES TO ШЛАНГИ DUCT CROSSOVER TO RH AND LH CYL HD) |
CK2, 3 (LLY) |
2004-2005 |
01 |
| 908 |
12623671 |
SENSOR, TURBO PRESS (ACDelco #213-4658) |
CK2, 3 (LLY) |
2004-2005 |
01 |
