| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
12572805 |
CYLINDER, CLU MAS (INCLS 2-5, 26) (INCLS SWITCH) |
CK2, 3 (ML6) |
2001-2006 |
01 |
| 002 |
88958857 |
CAP, CLU M/CYL RSVR (PART OF 1) |
CK2, 3 (ML6) |
2001-2006 |
01 |
| 003 |
19167195 |
SWITCH, CLU PED POSN (PART OF 1) (AT MASTER CYL) (4.054) |
CK2, 3 (ML6) |
2001-2006 |
01 |
| 003 |
19167195 |
SWITCH, CLU PED POSN (PART OF 1) (AT MASTER CYL) |
CK2, 3 (ML6) |
2001-2006 |
01 |
| 004 |
|
PUSHROD, CLU MASTER CYL (PART OF 1) |
|
2001-2006 |
|
| 005 |
12473050 |
BUSHING, CLU M/CYL PUSH ROD (PART OF 1) |
CK2, 3 (ML6) |
2001-2006 |
01 |
| 006 |
|
ГАЙКА, BRK PED BRKT (PART OF 7) |
|
2001-2006 |
|
| 007 |
15713209 |
BRACKET, CLU PED (INCLS 6) (L=45 W=80 H=80) (DASH PANEL) |
CK1 (LU3) |
2003-2006 |
01 |
| 007 |
15713209 |
BRACKET, CLU PED (INCLS 6) (L=45 W=80 H=80) (DASH PANEL) |
CK1, 2, 3 (LQ4, LR4, LLY, L18, L31) |
2005-2006 |
01 |
| 008 |
11517182 |
БОЛТ, CLU PED BRKT (M10X1.5X30, 15 THD) (8.900) |
CK1, 2, 3 (MG5, ML6, MW3, M96, TZ0) |
2003-2006 |
03 |
| 009 |
|
BRACKET, CLU PED (PART OF 17) |
|
2001-2006 |
|
| 010 |
|
BRACKET, CLU PED RTN SPR (PART OF 17) |
|
2001-2006 |
|
| 011 |
11516887 |
BOLT/SCREW, RD WA HD, 6 LOBED, M6X1X25, 17 OD, 6138M, MACH, P-PT, TORX DR (PART OF 17) |
|
2001-2006 |
02 |
| 012 |
11516793 |
ГАЙКА, HEX, W/CON WA, M6X1X5.5, 16 O.D., 9, 7111M (PART OF 17) |
|
2001-2006 |
02 |
| 013 |
|
SEAL, CLU PED BRKT (PART OF 17) |
|
2001-2006 |
|
| 014 |
15734674 |
BUSHING, CLU PED PIV (TO BRKT) (PART OF 17) (45.0X20.94MM) |
CK2, 3 (ML6) |
2001-2006 |
02 |
| 015 |
15023000 |
BUSHING, CLU PED PIV (TO PEDAL) (PART OF 17) (25.4X26.9MM) |
CK2, 3 (ML6) |
2001-2006 |
02 |
| 016 |
15773468 |
ПРУЖИНА, CLU PED RTN (PART OF 17) (LG=56.3MM) |
CK2, 3 (ML6) |
2001-2006 |
02 |
| 017 |
15251905 |
PEDAL, CLU (W/BRKT) (INCLS 9-16, 18-22) |
CK2, 3 (ML6) |
2001-2005 |
01 |
| 018 |
15734410 |
SPACER, CLU PED PIV (PART OF 17) |
CK2, 3 (ML6) |
2004-2006 |
01 |
| 019 |
93221087 |
BUSHING, CLU PED (PART OF 17) (INCLS RETAINER) (0.775) |
CK2, 3 (ML6) |
2001-2006 |
02 |
| 020 |
15120867 |
SEAT, CLU PED ASST SPR (PART OF 17) |
CK2, 3 (ML6) |
2001-2006 |
02 |
| 021 |
15047314 |
ПРУЖИНА, CLU PED RTN (PART OF 17) (LG=38.6MM) |
CK2, 3 (ML6) |
2001-2006 |
01 |
| 022 |
15706041 |
COVER, CLU PED (PART OF 17) |
CK2, 3 (ML6) |
2003-2006 |
01 |
| 023 |
|
CLIP, CLU ACTR CYL (PART OF 25) |
|
2001-2006 |
|
| 024 |
|
CLIP, CLU ACTR CYL (PART OF 25) |
|
2001-2006 |
|
| 025 |
15019756 |
CYLINDER, CLU ACTR (INCL THROWOUT BEARING) (INCLS 23, 24) |
CK2, 3 (ML6) |
2001-2006 |
01 |
| 026 |
88958853 |
CLIP, CLU ACTR CYL (PART OF 1) (LENGTH 17.5MM) |
CK2, 3 (ML6) |
2001-2006 |
02 |
