| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
11503747 |
ГАЙКА, M6X1 (PART OF 18) |
|
2003-2005 |
03 |
| 002 |
|
SENSOR, VEH YAW (W/VEH LATL ACCLRM) (PART OF 18) |
|
2003-2005 |
|
| 003 |
|
БОЛТ, RR WHL STRG CONT MDL BRKT |
|
2003-2005 |
|
| 004 |
26095380 |
BRACKET, RR WHL STRG CONT MDL |
CK2 (06) (NYS) |
2005-2005 |
01 |
| 005 |
15087554 |
MODULE, RR WHL STRG CONT |
CK1, 2 (NYS) |
2003-2005 |
01 |
| 006 |
|
БОЛТ, RR WHL STRG CONT MDL |
|
2003-2005 |
|
| 007 |
|
ГАЙКА, RR WHL STRG CONT MDL BRKT |
|
2003-2005 |
|
| 008 |
|
ГАЙКА, RR WHL STRG CONT MDL BRKT |
|
2003-2005 |
|
| 009 |
|
HARNESS, CHAS WRG (СМ. ГРУППУ 02.000 CHASSIS HARNESS ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2003-2005 |
|
| 010 |
|
HARNESS, RR AXLE WRG (СМ. ГРУППУ 06.000 РУЛЕВОЙ МЕХАНИЗМ В СБОРЕ/RR AXLE ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2003-2005 |
|
| 011 |
11570082 |
БОЛТ, HFH, M8X1.25X22, 19 THD, 18 OD, 10.9, GMW3359 (R/AXLE WRG HARN STRP) (ACDelco #11570082)
|
2003-2005 |
02 |
|
| 012 |
11517895 |
BOLT-HEX, M8X1.25X29.4, 24 OD, 6202M, 7114M, TAP, TR-PT (R/AXLE WRG HARN GUIDE) |
|
2003-2005 |
01 |
| 013 |
15173050 |
GUIDE, R/AXLE WRG HARN |
CK259 (06) (NYS) |
2003-2005 |
01 |
| 014 |
11610115 |
BOLT-HEX W/CON WASHER, M6X1X33, 23.37 THD, 17 OD, 8.8, GMW3200, M-PT (TRLR WRG HARN GND) |
|
2003-2005 |
02 |
| 015 |
11609411 |
ГАЙКА, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (CHAS RR WRG HARN GND)
|
2003-2005 |
01 |
|
| 016 |
11503747 |
ГАЙКА, M6X1 (PART OF 18) |
|
2003-2005 |
02 |
| 017 |
|
BRACKET, VEH YAW SEN LATL ACCLRM (PART OF 18) |
|
2003-2005 |
|
| 018 |
15951953 |
SENSOR, VEH YAW (W/VEH LATL ACCLRM) (INCLS 1, 2, 16, 17) |
CK1, 2, 3 (JL4) |
2004-2005 |
01 |
