| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 100 |
|
BLOCK, ENG |
|
2005-2007 |
|
| 101 |
88894269 |
BEARING KIT, CR/SHF (#1, 2, 3, 4) (INCLS 104) (STD) |
CK2, 3 (L18) |
2004-2007 |
04 |
| 102 |
|
BEARING KIT, CR/SHF THR (PART OF 105) |
|
2005-2007 |
|
| 103 |
89017574 |
CRANKSHAFT, |
CK2, 3 (L18) |
2004-2007 |
01 |
| 104 |
|
BEARING, CR/SHF LWR (PART OF 101) |
|
2005-2007 |
|
| 105 |
89017285 |
BEARING KIT, CR/SHF THR (#5) (INCLS 102) |
CK2, 3 (L18) |
2004-2007 |
01 |
| 106 |
|
CAP, CR/SHF BRG (MCHG) |
|
2005-2007 |
|
| 107 |
12556556 |
БОЛТ, CR/SHF BRG CAP (M12X1.75X89) |
CK2, 3 (L18) |
2004-2007 |
10 |
| 108 |
12559668 |
STUD, CR/SHF BRG CAP (M10X1.5X16-M12X1.75X70) |
CK2, 3 (L18) |
2004-2007 |
10 |
| 109 |
|
CAP, CR/SHF #5 BRG |
|
2005-2007 |
|
| 114 |
12561217 |
FLYWHEEL, ENG (INCLS 139) |
CK2, 3 (L18, MN8, M74) |
2004-2005 |
01 |
| 114 |
12582964 |
FLYWHEEL, ENG (INCLS 139) |
CK2, 3 (L18, ML6) |
2004-2006 |
01 |
| 115 |
11609297 |
BOLT-HEX W/FL WA, M11X1.5X25, 20.13 THD, 21 OD, 10.9, GMW3359 (FLYWHL) |
|
2004-2007 |
06 |
| 116 |
12556559 |
ГАЙКА, CONN ROD (PART OF 119) |
CK2, 3 (L18) |
2004-2007 |
16 |
| 117 |
|
CAP, CONN ROD (PART OF 119) |
|
2005-2007 |
|
| 118 |
88894270 |
BEARING KIT, CONN ROD (STD) |
CK2, 3 (L18) |
2004-2007 |
08 |
| 119 |
12583281 |
ROD, CONN (INCLS 116, 117, 120, 902) (FOR USE WITH FLOATING PIN PISTON DESIGN ONLY) (INCLS ROD, BUSHING, CAP, BOLT, NUT) |
CK2, 3 (L18) |
2004-2007 |
08 |
| 120 |
12556558 |
БОЛТ, CONN ROD (PART OF 119) |
CK2, 3 (L18) |
2004-2007 |
16 |
| 121 |
88893910 |
RING KIT, PSTN (0.030 O.S.) |
CK2, 3 (L18) |
2004-2007 |
08 |
| 121 |
88894226 |
RING KIT, PSTN (STD) |
CK2, 3 (L18) |
2004-2007 |
08 |
| 122 |
12552283 |
BALANCER, CR/SHF |
CK2, 3 (L18) |
2004-2007 |
01 |
| 123 |
23504011 |
WASHER, CR/SHF BALR |
CK2, 3 (L18) |
2004-2007 |
01 |
| 124 |
14022672 |
БОЛТ, CR/SHF BALR (M16 X 1.5) |
CK2, 3 (L18) |
2004-2007 |
01 |
| 126 |
12587621 |
SEAL, CR/SHF RR OIL |
CK2, 3 (L18) |
2004-2007 |
01 |
| 127 |
00444613 |
PLUG, HEX HD, 1/8-27 NPTF, STL (ENG BLK OIL GAL) (ACDelco #444613) |
|
2004-2007 |
03 |
| 128 |
11609914 |
PLUG - HX SOCKET DRAIN (ENG BLK OIL GAL) (1.531) |
|
2005-2007 |
03 |
| 129 |
12554553 |
PIN, ENG FRT CVR LOC (1/4X5/8) (0.738) |
CK2, 3 (L18) |
2004-2007 |
01 |
| 130 |
12561663 |
PLUG, ENG BLK COOL DRN HOLE (M28X1.25X12.4, BRASS) |
CK2, 3 (L18) |
2004-2007 |
01 |
| 131 |
11609916 |
PLUG, ENG BLK COOL DRN HOLE (M14X1.5X21.5) (0.253) |
CK2, 3 (L18) |
2005-2007 |
02 |
| 132 |
00444777 |
PLUG, HEX SOC, 1/4-18, STL (8.921) |
|
2004-2007 |
01 |
| 133 |
11609915 |
PLUG - SEALING ZN GMW3044 (ENG BLK OIL GAL) (1.531) |
|
2005-2007 |
AR |
| 135 |
03999200 |
PLUG, CM/SHF BRG HOLE |
CK2, 3 (L18) |
2004-2007 |
01 |
| 139 |
|
FLYWHEEL, (PART OF 114) |
|
2005-2007 |
|
| 140 |
11505820 |
PIN, DOWEL, M6X20, PL (ENG FRT CVR LOC) |
|
2004-2007 |
08 |
| 143 |
11609297 |
BOLT-HEX W/FL WA, M11X1.5X25, 20.13 THD, 21 OD, 10.9, GMW3359 (FLYWHL) |
|
2004-2007 |
06 |
| 144 |
89017680 |
PISTON, (INCLS 900, 901) (STD) (USE WITH FLOATING PIN PISTON DESIGN ONLY) (W/PIN RET) |
CK2, 3 (L18) |
2004-2007 |
04 |
| 144 |
89060463 |
PISTON, (INCLS 900, 901) (W/CONN ROD) (0.030O.S.) |
CK1, 2, 3 (L18) |
2005-2007 |
04 |
| 144 |
89060465 |
PISTON, (INCLS 900, 901) (W/CONN ROD) (0.030O.S.) (FOR USE WITH FLOATING PIN DESIGN ONLY) |
CK1, 2, 3 (L18) |
2005-2007 |
04 |
| 200 |
10114177 |
CHAIN, CM/SHF TMG |
CK2, 3 (L18) |
2004-2007 |
01 |
| 201 |
11570082 |
БОЛТ, HFH, M8X1.25X22, 19 THD, 18 OD, 10.9, GMW3359 (CM/SHF SPKT) (ACDelco #11570082)
|
2004-2007 |
03 |
|
| 202 |
12589766 |
SPROCKET, CM/SHF |
CK2, 3 (L18) |
2004-2007 |
01 |
| 203 |
12560177 |
SPROCKET, CR/SHF |
CK2, 3 (L18) |
2004-2007 |
01 |
| 204 |
11515151 |
SCREW, PAN HD, M6X1X13, 12 THD, 9.8, PE, TORX (CM/SHF RET) |
|
2004-2007 |
02 |
| 205 |
10168501 |
RETAINER, CM/SHF |
CK2, 3 (L18) |
2004-2007 |
01 |
| 206 |
12554553 |
PIN, CM/SHF SPKT LOC (PART OF CAM SHAFT ASM ALSO SERVICED SEPARATELY.) (1/4X5/8) |
CK2, 3 (L18) |
2004-2007 |
01 |
| 207 |
12556291 |
CAMSHAFT, ENG (INCLS 903) (INCLSCAMSHAFT, CM/SHF SPKT LOC PIN) |
CK2, 3 (L18) |
2004-2007 |
01 |
| 208 |
12508996 |
BEARING, CM/SHF (#1) |
CK2, 3 (L18) |
2004-2007 |
01 |
| 213 |
12558081 |
PIN, CYL HD LOC (1/2 X 5/8 O.D.) |
CK2, 3 (L18) |
2004-2007 |
04 |
| 233 |
12560729 |
PIN, CR/SHF BALR LOC |
CK2, 3 (L18) |
2004-2007 |
01 |
| 719 |
12591312 |
SENSOR, KNOCK (ACDelco #213-2829) |
CK2, 3 (L18) |
2004-2007 |
02 |
| 719 |
19236381 |
SENSOR, KNOCK (ALL MAKES) |
C259 (06) (L18) |
2004-2005 |
01 |
| 722 |
12567862 |
SHIELD, KNOCK SEN (RIDGEVIEW STAMP) |
CK2, 3 (L18) |
2004-2007 |
01 |
| 722 |
12570302 |
SHIELD, KNOCK SEN (PRIDGEON CLAY) |
CK2, 3 (L18) |
2004-2007 |
01 |
| 723 |
52368558 |
БОЛТ, M6X1X12, 10 THD, 11.6 OD, HDR PT, 9.8, POR (KNOCK SEN SHLD) |
|
2004-2007 |
02 |
| 726 |
12575172 |
SENSOR, CR/SHF POSN (INCL ONE UPPER O-RING SEAL) (ACDelco #213-1556) |
CK2, 3 (L18) |
2004-2007 |
01 |
| 727 |
12562852 |
БОЛТ, CR/SHF POSN SEN (M6X1.0X21, 13 THD) |
CK2, 3 (L18) |
2004-2007 |
01 |
| 728 |
12574403 |
SENSOR, ENG OIL PRESS (2.4 LONG) (3 TERMINAL) (ACDelco #D1822A) |
CK2, 3 (L18) |
2004-2007 |
01 |
| 900 |
|
PIN, PSTN (PART OF 144) |
|
2005-2007 |
|
| 901 |
|
RETAINER, PSTN PIN (PART OF 144) |
|
2005-2007 |
|
| 902 |
|
BUSHING, CONN ROD (PART OF 119) |
|
2005-2007 |
|
| 903 |
12554553 |
PIN, (1/4 X 5/8) (PART OF 207) (0.738) |
|
2004-2007 |
01 |
| 904 |
01453658 |
PIN, DOWEL STRAIGHT 5/8 DIA 1 3/16 LG (TRANS LOC) |
|
2004-2007 |
01 |
| 905 |
15170227 |
CONNECTOR, ENG OIL CLR HOSE (20.98MM FITTING OPENING) |
CK2, 3 (L18) |
2004-2007 |
02 |
| 906 |
12557583 |
BEARING, CLU PILOT (22.7MM ID, 43.3MM OD, 13 THK) (ACDelco #CT1082) |
CK2, 3 (L18, ML6) |
2004-2006 |
01 |
| 907 |
12508997 |
BEARING, CM/SHF (#2 REAR) |
CK2, 3 (L18) |
2004-2007 |
02 |
| 908 |
12508998 |
BEARING, CM/SHF (#3 #4) |
CK2, 3 (L18) |
2004-2007 |
02 |
