| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
25879116 |
ARM, WSW (W/NOZZLE HOSE) |
CK1, 2 (06-36) (EXC PPV) |
2010-2013 |
01 |
| 001 |
25879117 |
ARM, WSW (W/NOZZLE HOSE) |
CK1, 2 (06-36) (EXC PPV) |
2010-2013 |
01 |
| 002 |
15788727 |
CAP, WSW ARM FIN (10.147) |
CK1, 2 (06-36) (EXC PPV) |
2010-2013 |
02 |
| 003 |
11609634 |
NUT, HEX WASH, M10X1.25, 7MM THK, 20 WA OD, 9 STL, 7111M, CON SPR WA. (WSW ARM) |
|
2010-2013 |
02 |
| 004 |
25820729 |
PANEL, AIR INL GRL (INCLS 5) (BLACK) |
CK1, 2 (06) |
2010-2013 |
01 |
| 004 |
25820730 |
PANEL, AIR INL GRL (INCLS 5) (BLACK) |
CK1, 2 (06) |
2010-2013 |
01 |
| 005 |
11609796 |
CLIP, AIR INL GRL PNL (PART OF 4) (11.0 X 12.9 X 6.1MM) (8.950) |
CK1, 2 (06-36) |
2010-2013 |
03 |
| 006 |
25872303 |
PANEL, AIR INL GRL (CTR) (INCLS 7, 23, 27) (BLACK) |
CK1, 2 (06) |
2010-2013 |
01 |
| 007 |
20908176 |
HOSE, WSWA NOZ (PART OF 6) |
CK1, 2 (06-36) |
2010-2013 |
01 |
| 008 |
15999788 |
RETAINER, AIR INL GRL PNL (17X15.25X8.6) (U-SHAPED/CLIP) |
CK1, 2, 3 |
2010-2013 |
02 |
| 009 |
11513947 |
BOLT, HEX, W/WA, M6X1X35, 24 O.D., AC PT, 9.8, POR (WSW SYS MDL) |
|
2010-2013 |
03 |
| 010 |
25923882 |
MODULE, WSW SYS |
CK1, 2, 3 |
2012-2013 |
01 |
| 011 |
25731418 |
CAP, WSWA SOLV CNTNR (10.154) |
CK1, 2, 3 |
2010-2013 |
01 |
| 011 |
25731418 |
CAP, WSWA SOLV CNTNR (10.154) |
CK1, 2 (06) (C25) |
2010-2013 |
01 |
| 012 |
|
CONTAINER, WSWA SOLV (*KIT1) |
|
2013-2013 |
|
| 013 |
11609989 |
BOLT, HEX W/FLAT WASHER, M6X1X25, 15 THD, 17 OD, 6202M STL, GMW3200, TAPTITE (WSWA SOLV CNTNR) |
|
2010-2013 |
03 |
| 014 |
|
INDICATOR, WSWA SOLV LVL (*KIT2) |
|
2011-2013 |
|
| 015 |
15248578 |
GROMMET, WSWA SOLV CNTNR (*KIT1, KIT2) |
CK1, 2, 3 |
2010-2013 |
01 |
| 016 |
15927514 |
GROMMET, WSWA PUMP (PUMP GROMMET) (*KIT1, KIT3) (ACDelco #15927514) |
CK1, 2, 3 |
2010-2013 |
01 |
| 017 |
|
PUMP, WSWA (*KIT3) |
|
2011-2013 |
|
| 018 |
|
PUMP, WSWA (*KIT3) |
|
2011-2013 |
|
| 019 |
10150076 |
CLIP, WSWA NOZ HOSE (CLIP TO RET THE COWL HOSE IN THE FENDER) (18.8 MM DIA) (ROUND CLIP) (3.425) |
CK1, 2, 3 |
2010-2013 |
01 |
| 020 |
25887957 |
HOSE, R/WDO WA PUMP (SEE GROUP 16.000 WIPER SYSTEM/ REAR WINDOW FOR DETAILED ILLUSTRATED VIEW) (REAR JUMPER HOSE) |
CK1, 2 (06) (C25) |
2010-2013 |
01 |
| 021 |
25887977 |
HOSE, WSWA PUMP (FRT JUMPER HOSE) |
CK1, 2, 3 |
2010-2013 |
01 |
| 022 |
11589183 |
NUT, PUSH IN, W/SEAL, 4.2X1.41, 6.35-6.48 SQ HL, 9.5 SQ HD, 0.787-2.765 PNL THK, NYL (AIR INL GRL PNL) |
|
2010-2013 |
04 |
| 023 |
15200240 |
WEATHERSTRIP, HOOD RR (PART OF 6) |
CK1, 2 (06-36) |
2010-2013 |
01 |
| 024 |
11508765 |
SCREW, TORX, W/ RD WA, M4.2X1.41X16, 11.1 O.D., STL, NIOR (AIR INL GRL PNL) |
|
2010-2013 |
04 |
| 025 |
12368668 |
WIPER, W/S (PART OF 26) (REFILL) (USED TO SERVICE 15214346 BLADE ASM) |
CK1, 2 (06-36) (EXC PPV) |
2010-2013 |
02 |
| 026 |
22793882 |
BLADE, WSW (INCLS 25) (CONVENTIONAL BLADE) |
CK1, 2 (06-36) (EXC PPV) |
2010-2013 |
02 |
| 027 |
15048061 |
RETAINER, AIR INL GRL PNL (PART OF 6) (PUSH IN) |
CK1, 2 (06-36) |
2010-2013 |
01 |
| K01 |
20999340 |
CONTAINER KIT, WSWA SOLV (INCLS 12, 15, 16) (USE T/W 20999338 WHEN REPLACING 15248577, 15213911 OR 15942522.) |
CK1, 2 (06) |
2010-2013 |
01 |
| K02 |
20999338 |
INDICATOR KIT, WSWA SOLV LVL (INCLS 14, 15) (LEVEL SENSOR KIT W/GROMMET) (KIT HAS 16MM DIAM LVL SENSOR) (ACDelco #20999338) (USE T/W 20999340 WHEN REPLACING 15248577, 15213911 OR 15942522.) |
CK1, 2 (06) |
2010-2013 |
01 |
| K03 |
15942524 |
PUMP KIT, WSWA W/SEAL (INCLS 16-18) (RR PUMP KIT W/GROMMET) (ACDelco #15942524) |
CK1, 2 (06) (C25) |
2010-2013 |
01 |
| K03 |
20999342 |
PUMP KIT, WSWA W/SEAL (INCLS 16-18) (FRONT PUMP KIT) |
CK1, 2 (06) (C25) |
2011-2013 |
01 |
