| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15938661 |
LINER, RR W/H (INCLS 6) (W/NUT) |
CK107 (06) (Y91, Z75, Z88) |
2007-2013 |
01 |
| 001 |
15938662 |
LINER, RR W/H (INCLS 6) (W/NUT) |
CK107 (06) (Y91, Z75, Z88) |
2007-2013 |
01 |
| 002 |
11562172 |
BOLT, RR W/H LNR (8.153) |
CK1 (06-36) |
2007-2013 |
AR |
| 003 |
11589292 |
RETAINER, PUSH-IN, FITS 8.5 DIA HOLE IN 2-4.5 THK PNL, NYLON 6/6 GMP.PA66.015 (RR W/H LNR (PUSH IN)) |
|
2007-2013 |
02 |
| 004 |
01605396 |
RETAINER, PUSH-IN, FITS .250 HOLE, .92 LG.700-OD NYLON BLACK (RR W/H LNR (PUSH IN)) |
|
2007-2013 |
04 |
| 005 |
11570498 |
BOLT, HWH W/FL WA, M4.2X1.41X20, 11.4 THD, 17 OD, ISO 2702 STL , GMW4205, T (RR W/H LNR) |
|
2007-2013 |
10 |
| 006 |
11513599 |
NUT, U-TYPE, M4.2X1.41, 0.65-3.80 PNL THK, PZ (PART OF 1) (ACDelco #11513599) |
|
2007-2013 |
02 |
| 007 |
11513599 |
NUT, U-TYPE, M4.2X1.41, 0.65-3.80 PNL THK, PZ (RR W/H LNR) (ACDelco #11513599) |
|
2007-2013 |
06 |
| 008 |
11518531 |
NUT, PUSH-IN, M4.2X1.41, 15.9X8.4, .7-2.1 PNL, SAE 1050 STL, 7111M, 8.65 SQ HOL (RR W/H PNL) (10.512) |
|
2007-2013 |
02 |
| 009 |
11518531 |
NUT, PUSH-IN, M4.2X1.41, 15.9X8.4, .7-2.1 PNL, SAE 1050 STL, 7111M, 8.65 SQ HOL (RR W/H LNR) (10.512) |
|
2007-2013 |
02 |
