| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
20927066 |
HARNESS, BODY WRG (INCLS 5, 8) |
CK107 (06) (AN3, ARS, E61, UUK, UUL, UUM, UVC, Y91, Z75) (EXC HP2, T89) |
2010-2010 |
01 |
| 001 |
20927062 |
HARNESS, BODY WRG (INCLS 5, 8) |
CK107 (06) (AN3, E61, UUK, UUL, UUM, UVC, Y91, Z75) (EXC ARS, HP2, T89) |
2010-2010 |
01 |
| 001 |
20927066 |
HARNESS, BODY WRG (INCLS 5, 8) |
CK107 (06) (AN3, ARS, T89, UUK, UUL, UUM, UVC, Y91) (EXPORT) |
2010-2010 |
01 |
| 002 |
|
HARNESS, L/GATE WRG (SEE GROUP 02.000 WIRING HARNESS/LIFT GATE FOR DETAILED ILLUSTRATED VIEW) (INCLUDES BOOT BETWEEN LIFT GATE AND BODY) |
|
2007-2013 |
|
| 003 |
11609411 |
NUT, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (BODY WRG HARN GND) |
|
2007-2013 |
03 |
| 004 |
21011332 |
NUT, HEX STAMPED TY DF FLG 14 (BODY WRG HARN BRKT) (8.921) |
|
2007-2013 |
06 |
| 005 |
|
CONDUIT, BODY WRG HARN (PART OF 1) |
|
2010-2013 |
|
| 006 |
25952151 |
COVER, WRG HARN CONN (EBONY) |
CK1, 2 (06-36) (Z75) |
2010-2010 |
01 |
| 006 |
25952153 |
COVER, WRG HARN CONN (EBONY) |
CK1, 2 (06-36) (Z75) |
2010-2010 |
01 |
| 007 |
|
MODULE, AIRBAG SEN DIAGN (SEE GROUP 16.000 INFLATEABLE RESTRAINT SYSTEM FOR DETAILED ILLUSTRATED VIEW) |
|
2007-2013 |
|
| 008 |
|
CONDUIT, BODY WRG HARN (PART OF 1) |
|
2010-2013 |
|
| 009 |
|
HARNESS, I/P WRG (SEE GROUP 02.000 WIRING HARNESS/INSTRUMENT PANEL FOR DETAILED ILLUSTRATED VIEW) |
|
2007-2013 |
|
| 010 |
|
MODULE, RR VIEW CAMERA IMAGE DISPLAY (SEE GROUP 02.000 SENSOR SYSTEM/REAR OBJECT FOR DETAILED ILLUSTRATED VIEW) (2.195) |
|
2007-2013 |
|
| 011 |
11588337 |
BOLT, HEX W/FL WA, M6X1X20, 9 THD, 17 OD, 6202M, GMW3200, TAP, DOG PT. (BODY WRG HARN GND) |
|
2007-2013 |
02 |
