| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15877373 |
PLATE, R/FLR RR TR (INCLS 17, 18) (LINEN) |
CK1 (06) (ULT, 41I) |
2008-2009 |
01 |
| 001 |
15931763 |
PLATE, R/FLR RR TR (INCLS 17, 18) (EBONY) (W/ CADILLAC INSERT)
| CK1 (06) (Y91, Z75, 19I) |
2007-2009 |
01 |
|
| 001 |
25902618 |
PLATE, R/FLR RR TR (INCLS 17, 18) (CASHMERE) |
CK1 (06) (Y91, Z75, 39I) |
2009-2009 |
01 |
| 002 |
15905683 |
MOLDING, BK BODY OPG GARN (INCLS 3) (GRAY) |
CK1, 2 (06) (Z75, 19I) |
2007-2009 |
01 |
| 002 |
15905684 |
MOLDING, BK BODY OPG GARN (INCLS 3) (CASHMERE) |
CK1, 2 (06) (Z75, 39I) |
2009-2009 |
01 |
| 002 |
15936713 |
MOLDING, BK BODY OPG GARN (INCLS 3) (LINEN) |
CK1 (06) (ULT, 41I) |
2008-2009 |
01 |
| 003 |
11561654 |
RETAINER, BODY RR COR G/MLDG (PART OF 2) (PLAIN) (8.5MM DIA HOLE) (BIRDS BEAK SINGLE) (12.800)
| CK1, 2 (06) |
2007-2009 |
06 |
|
| 004 |
|
MOLDING, BODY RR COR UPR GARN ( |
|
2007-2009 |
|
| 005 |
11588650 |
CLIP, 12X14X16.6, GM4345M (PART OF 10, 19)
|
2007-2009 |
10 |
|
| 006 |
11609651 |
CLIP, BODY L/PLR G/MLDG (PART OF 10, 19) (M21.8X15.0X20.5) (14.731)
| CK1, 2 (06) |
2007-2009 |
02 |
|
| 007 |
15873285 |
PLATE, RR S/D SILL TR (INCLS 8) (EBONY) (W/CADILLAC INSERT)
| CK107 (Y91, Z75, 19I) |
2007-2009 |
02 |
|
| 007 |
15877412 |
PLATE, RR S/D SILL TR (INCLS 8) (LINEN) |
CK107 (ULT, 41I) |
2008-2009 |
02 |
| 007 |
25902616 |
PLATE, RR S/D SILL TR (INCLS 8) (CASHMERE) |
CK107 (06) (Y91, Z75, 39I) |
2009-2009 |
01 |
| 007 |
25902616 |
PLATE, RR S/D SILL TR (INCLS 8) (CASHMERE) |
CK107 (Y91, Z75, 39I) |
2009-2009 |
01 |
| 008 |
11589329 |
CLIP, 12X8.9X15.5, SAE 1050 SPR STL, GMW3044 (PART OF 7)
|
2007-2009 |
04 |
|
| 009 |
15043000 |
PLUG, R/CMPT SILL TR PLT HOLE (38.0 X 17.0 X 18.0MM) (OBLONG) (16.600) |
CK1, 2 (06) |
2007-2009 |
10 |
| 010 |
15875101 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15) (CASHMERE) (MOLDED IN COLOR FLECKED PLASTIC UPR TR) |
CK107 (06) (39I) (EXC ARS) |
2009-2009 |
01 |
| 010 |
15875107 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15) (CASHMERE) (MOLDED IN COLOR FLECKED PLASTIC UPR TR) |
CK107 (06) (39I) (EXC ARS) |
2009-2009 |
01 |
| 010 |
15877443 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15) (LINEN) |
CK107 (06) (ULT, 41I) |
2008-2009 |
01 |
| 010 |
15877445 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15) (LINEN) |
CK107 (06) (ULT, 41I) |
2008-2009 |
01 |
| 010 |
15900725 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15) (EBONY/GRANITE OPAL) (DUAL TONE PART) |
CK107 (06) (19I) (EXC ARS) |
2009-2009 |
01 |
| 010 |
15900731 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15) (EBONY) (DUAL TONE PART) (GRAY UPR)
| CK107 (06) (19I) (EXC ARS) |
2009-2009 |
01 |
|
| 010 |
20844007 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15) (LINEN) |
CK107 (06) (HP2, ULT, 41I) |
2009-2009 |
02 |
| 010 |
20844008 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15) (LINEN) |
CK107 (06) (HP2, ULT, 41I) |
2009-2009 |
02 |
| 010 |
25797297 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15) (EBONY) (CLOTH WRAPPED) |
CK107 (06) (Z75, 19I) (EXC ARS) |
2007-2009 |
01 |
| 010 |
25797300 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15) (EBONY) (MOLDED IN PLASTIC) |
CK107 (06) (Z75, 19I) (EXC ARS) |
2007-2009 |
01 |
| 010 |
25902632 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15) (CASHMERE) (CLOTH WRAPPED UPR TR) |
CK107 (06) (Z75, 39I) (EXC ARS) |
2009-2009 |
01 |
| 010 |
25902633 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15) (CASHMERE) (CLOTH WRAPPED UPR TR) |
CK107 (06) (Z75, 39I) (EXC ARS) |
2009-2009 |
01 |
| 011 |
11589329 |
CLIP, 12X8.9X15.5, SAE 1050 SPR STL, GMW3044 (PART OF 10, 19)
|
2007-2009 |
08 |
|
| 012 |
15295390 |
BEZEL, R/SEAT SHLDR BELT OPG (PART OF 10, 19) (EBONY) |
CK107 (06) (Z75, 19I) |
2007-2009 |
01 |
| 012 |
15295394 |
BEZEL, R/SEAT SHLDR BELT OPG (PART OF 10, 19) (EBONY) |
CK107 (06) (Z75, 19I) |
2007-2009 |
01 |
| 012 |
25827829 |
BEZEL, R/SEAT SHLDR BELT OPG (PART OF 10, 19) (LINEN) |
CK107 (06) (ULT, 41I) |
2008-2009 |
01 |
| 012 |
25827831 |
BEZEL, R/SEAT SHLDR BELT OPG (PART OF 10, 19) (LINEN) |
CK107 (06) (ULT, 41I) |
2008-2009 |
01 |
| 012 |
25903597 |
BEZEL, R/SEAT SHLDR BELT OPG (PART OF 10, 19) (CASHMERE) |
CK107 (06) (Z75, 39I) |
2009-2009 |
01 |
| 012 |
25903598 |
BEZEL, R/SEAT SHLDR BELT OPG (PART OF 10, 19) (CASHMERE) |
CK107 (06) (Z75, 39I) |
2009-2009 |
01 |
| 013 |
15214081 |
GUIDE, R/SEAT SHLDR BELT (PART OF 10, 19) (EBONY) |
CK1, 2 (06) (19I) |
2009-2009 |
02 |
| 013 |
25827828 |
GUIDE, R/SEAT SHLDR BELT (PART OF 10, 19) (LINEN) |
CK1 (ULT, 41I) |
2008-2009 |
02 |
| 014 |
11609465 |
|
|
2007-2009 |
02 |
| 015 |
15278075 |
PLUG, BODY L/PLR GARN MLDG (PART OF 10, 19) (GRAY)
| CK107 (06) (19I, 83I) |
2009-2009 |
01 |
|
| 015 |
15278076 |
PLUG, BODY L/PLR GARN MLDG (PART OF 10, 19) (GRAY)
| CK107 (06) (19I, 83I) |
2009-2009 |
01 |
|
| 015 |
15278083 |
PLUG, BODY L/PLR GARN MLDG (PART OF 10, 19) (CASHMERE) |
CK107 (06) (39I) |
2009-2009 |
01 |
| 015 |
15278084 |
PLUG, BODY L/PLR GARN MLDG (PART OF 10, 19) (CASHMERE) |
CK107 (06) (39I) |
2009-2009 |
01 |
| 015 |
25827826 |
PLUG, BODY L/PLR GARN MLDG (PART OF 10, 19) (LINEN) |
CK107 (06) (ULT, 41I) |
2008-2009 |
01 |
| 015 |
25827830 |
PLUG, BODY L/PLR GARN MLDG (PART OF 10, 19) (LINEN) |
CK107 (06) (ULT, 41I) |
2008-2009 |
01 |
| 016 |
|
PANEL, BODY SI TR ( |
|
2007-2009 |
|
| 017 |
11589329 |
CLIP, 12X8.9X15.5, SAE 1050 SPR STL, GMW3044 (PART OF 1)
|
2007-2009 |
10 |
|
| 018 |
15274514 |
COVER, L/GATE LK STKR (PART OF 1) (CASHMERE) |
CK1, 2 (06) (33I, 39I) |
2009-2009 |
01 |
| 018 |
15274516 |
COVER, L/GATE LK STKR (PART OF 1) (EBONY) |
CK1, 2 (06) (19I, 22I, 84I) |
2007-2009 |
01 |
| 018 |
15940206 |
COVER, L/GATE LK STKR (PART OF 1) (LINEN) |
CK1 (06) (41I) |
2008-2009 |
01 |
| 019 |
15877443 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15, 20, 21) (LINEN) |
CK107 (06) (ULT, 41I) |
2008-2009 |
01 |
| 019 |
15877445 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15, 20, 21) (LINEN) |
CK107 (06) (ULT, 41I) |
2008-2009 |
01 |
| 019 |
15900737 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15, 20, 21) (EBONY) (DUAL TONE PART) (GRAY UPR) |
CK107 (06) (ARS, 19I) |
2009-2009 |
01 |
| 019 |
15900738 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15, 20, 21) (CASHMERE) (MOLDED IN COLOR FLECKED PLASTIC UPR TR) |
CK107 (06) (ARS, 39I) |
2009-2009 |
01 |
| 019 |
15900743 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15, 20, 21) (EBONY) (DUAL TONE PART) (GRAY UPR) |
CK107 (06) (ARS, 19I) |
2009-2009 |
01 |
| 019 |
15900744 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15, 20, 21) (CASHMERE) (MOLDED IN COLOR FLECKED PLASTIC UPR TR) |
CK107 (06) (ARS, 39I) |
2009-2009 |
01 |
| 019 |
20844007 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15, 20, 21) (LINEN) |
CK107 (06) (HP2, ULT, 41I) |
2009-2009 |
02 |
| 019 |
20844008 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15, 20, 21) (LINEN) |
CK107 (06) (HP2, ULT, 41I) |
2009-2009 |
02 |
| 019 |
25797294 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15, 20, 21) (EBONY) |
CK107 (06) (ARS, Z75, 19I) |
2007-2009 |
01 |
| 019 |
25797303 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15, 20, 21) (EBONY) |
CK107 (06) (ARS, Z75, 19I) |
2007-2009 |
01 |
| 019 |
25902631 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15, 20, 21) (CASHMERE) (CLOTH WRAPPED UPR TR) |
CK107 (06) (ARS, Z75, 39I) |
2009-2009 |
01 |
| 019 |
25902634 |
MOLDING, BODY L/PLR GARN (INCLS 5, 6, 11-15, 20, 21) (CASHMERE) (CLOTH WRAPPED UPR TR) |
CK107 (06) (ARS, Z75, 39I) |
2009-2009 |
01 |
| 020 |
15113408 |
SWITCH, R/SEAT ADJR (PART OF 19) (ON GARNISH MOLDING) |
CK1, 2 (06) |
2007-2009 |
01 |
| 021 |
15214082 |
BEZEL, BODY L/PLR G/MLDG (PART OF 19) (CASHMERE) |
CK1, 2 (06) (ARS, 33I, 39I) |
2009-2009 |
02 |
| 021 |
15214082 |
BEZEL, BODY L/PLR G/MLDG (PART OF 19) (CASHMERE) |
K107 (06) (ARS, XA1, Z75, 39I) (EXPORT) |
2009-2009 |
02 |
| 021 |
15214084 |
BEZEL, BODY L/PLR G/MLDG (PART OF 19) (EBONY) |
CK1, 2 (06) (ARS, 19I) |
2009-2009 |
02 |
| 021 |
25827827 |
BEZEL, BODY L/PLR G/MLDG (PART OF 19) (LINEN) |
CK1 (06) (ULT, 41I) |
2008-2009 |
02 |
