| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
|
HARNESS, RF WRG ( |
|
2007-2009 |
|
| 003 |
|
RECEIVER, DIGITAL RDO ( |
|
2007-2009 |
|
| 004 |
19116678 |
CABLE, DIGITAL RDO |
CK1 (06) (UE1, Y91, Z88) (EXC U2K) |
2008-2008 |
01 |
| 004 |
19116705 |
CABLE, DIGITAL RDO |
CK1 (06) (UE1, U2K, Y91, Z88) |
2008-2008 |
01 |
| 005 |
19149310 |
BLOCK, I/P WRG HARN JUNC (PART OF 8) |
K1, 2, 3 |
2007-2009 |
01 |
| 006 |
|
HARNESS, BODY WRG ( |
|
2007-2009 |
|
| 007 |
|
MODULE, COMN INTERFACE (W/MOBILE TEL XCVR) ( |
|
2007-2009 |
|
| 008 |
15296982 |
HARNESS, I/P WRG (INTERNAL GROUND IN UBEC) (INCLS 4, 5) |
K1 (06) (NR3, UE1, U3U, Y91, Z88) (EXC BRS, U2K, U42) |
2008-2008 |
01 |
| 008 |
15296983 |
HARNESS, I/P WRG (INCLS 4, 5) |
K1 (06) (NR3, U3U, Y91, Z88) (EXC BRS, UE1, U2K, U42) |
2008-2008 |
01 |
| 008 |
15296983 |
HARNESS, I/P WRG (INTERNAL GROUND IN UBEC) (INCLS 4, 5) |
K1 (06) (NR3, UVA, UVB, U42, Y91, Z88) (EXC BRS, UE1, U2K) |
2008-2008 |
01 |
| 008 |
15296984 |
HARNESS, I/P WRG (INTERNAL GROUND IN UBEC) (INCLS 4, 5) |
K1 (06) (NR3, UE1, UVA, UVB, U42, Y91, Z88) (EXC BRS, U2K) |
2008-2008 |
01 |
| 008 |
15814162 |
HARNESS, I/P WRG (INTERNAL GROUND IN UBEC) (INCLS 4, 5) |
K1 (06) (NR3, UE1, US9, U2K, Y91, Z88) (EXC BRS, U42) |
2008-2008 |
01 |
| 008 |
15814163 |
HARNESS, I/P WRG (INTERNAL GROUND AT UBEC) (INCLS 4, 5) |
K1 (06) (NR3, UE1, US9, Y91, Z88) (EXC BRS, U2K, U42) |
2008-2008 |
01 |
| 008 |
15839008 |
HARNESS, I/P WRG (INTERNAL GROUND IN UBEC) (INCLS 4, 5) |
K1 (06) (BRS, NR3, UE1, U2K, U3U, Y91, Z88) (EXC U42) |
2008-2008 |
01 |
| 008 |
15839009 |
HARNESS, I/P WRG (INTERNAL GROUND IN UBEC) (INCLS 4, 5) |
K1 (06) (BRS, NR3, UE1, U3U, Y91, Z88) (EXC U2K, U42) |
2008-2008 |
01 |
| 008 |
15839010 |
HARNESS, I/P WRG (INTERNAL GROUND IN UBEC) (INCLS 4, 5) |
K1 (06) (BRS, NR3, U3U, Y91, Z88) (EXC UE1, U2K, U42) |
2008-2008 |
01 |
| 008 |
15839010 |
HARNESS, I/P WRG (INTERNAL GROUND IN UBEC) (INCLS 4, 5) |
K1 (06) (BRS, NR3, UVA, UVB, U42, Y91, Z88) (EXC UE1, U2K) |
2008-2008 |
01 |
| 008 |
15839011 |
HARNESS, I/P WRG (INTERNAL GROUND IN UBEC) (INCLS 4, 5) |
K1 (06) (BRS, NR3, UE1, UVA, UVB, U42, Y91, Z88) (EXC U2K) |
2008-2008 |
01 |
| 008 |
15839022 |
HARNESS, I/P WRG (INTERNAL GROUND IN UBEC) (INCLS 4, 5) |
K1 (06) (BRS, NR3, UE1, US9, U2K, Y91, Z88) (EXC U42) |
2008-2008 |
01 |
| 008 |
15839023 |
HARNESS, I/P WRG (INTERNAL GROUND IN UBEC) (INCLS 4, 5) |
K1 (06) (BRS, NR3, UE1, US9, Y91, Z88) (EXC U2K, U42) |
2008-2008 |
01 |
| 008 |
15839025 |
HARNESS, I/P WRG (INTERNAL GROUND IN UBEC) (INCLS 4, 5) |
K1 (06) (BRS, NR3, UE1, UVA, UVB, U2K, U42, Y91, Z88) |
2008-2008 |
01 |
| 008 |
25892103 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
K1 (06) (NR3, UE1, U2K, U3U, Y91, Z88) (EXC BRS, U42) |
2008-2008 |
01 |
| 008 |
25892103 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
K1 (06) (NR3, UE1, U2K, XA7, U3U, Y91, Z88) (EXC BRS, U42) |
2008-2008 |
01 |
| 008 |
25892104 |
HARNESS, I/P WRG (EXTERNAL RING TERMINAL) (INCLS 4, 5) |
K1 (06) (NR3, UE1, U3U, Y91, Z88) (EXC BRS, U2K, U42) |
2008-2008 |
01 |
| 008 |
25892105 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
K1 (06) (NR3, UVA, UVB, U42, Y91, Z88) (EXC BRS, UE1, U2K) |
2008-2008 |
01 |
| 008 |
25892105 |
HARNESS, I/P WRG (INTERNAL GROUND IN UBEC) (INCLS 4, 5) |
K1 (06) (NR3, U3U, Y91, Z88) (EXC BRS, UE1, U2K, U42) |
2008-2008 |
01 |
| 008 |
25892106 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
K1 (06) (NR3, UE1, UVA, UVB, U42, Y91, Z88) (EXC BRS, U2K) |
2008-2008 |
01 |
| 008 |
25892122 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
K1 (06) (NR3, UE1, UVA, UVB, U2K, U42, Y91, Z88) (EXC BRS) |
2008-2008 |
01 |
| 008 |
25892123 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
K1 (06) (NR3, UE1, US9, U2K, Y91, Z88) (EXC BRS, U42) |
2008-2008 |
01 |
| 008 |
25892124 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
K1 (06) (US9, Y91, Z88) (EXC BRS, UE1, U2K, U42) |
2008-2008 |
01 |
| 008 |
25892133 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
K1 (06) (BRS, NR3, UE1, U3U, Y91, Z88) (EXC U2K, U42) |
2008-2008 |
01 |
| 008 |
25892134 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
K1 (06) (BRS, NR3, U3U, Y91, Z88) (EXC UE1, U2K, U42) |
2008-2008 |
01 |
| 008 |
25892134 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
K1 (06) (BRS, NR3, UVA, UVB, U42, Y91, Z88) (EXC UE1, U2K) |
2008-2008 |
01 |
| 008 |
25892135 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
K1 (06) (BRS, NR3, UE1, UVA, UVB, U42, Y91, Z88) (EXC U2K) |
2008-2008 |
01 |
| 008 |
25892146 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
K1 (06) (BRS, NR3, UE1, US9, U2K, Y91, Z88) (EXC U42) |
2008-2008 |
01 |
| 008 |
25892147 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
K1 (06) (BRS, NR3, US9, Y91, Z88) (EXC U2K, U42) |
2008-2008 |
01 |
| 008 |
25892149 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
K1 (06) (BRS, NR3, UE1, UVA, UVB, U2K, U42, Y91, Z88) |
2008-2008 |
01 |
| 009 |
12146933 |
COVER, I/P WRG HARN DATA LINK CONN |
K107 (06) (T89) (EXPORT) |
2007-2008 |
01 |
| 010 |
11589012 |
|
|
2007-2009 |
01 |
| 011 |
11609411 |
|
|
2007-2009 |
02 |
| 012 |
|
BLOCK, ENG WRG HARN JUNC ( |
|
2007-2009 |
|
