| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
10396716 |
|
CK1 (U3R) |
2007-2007 |
01 |
| 002 |
25865834 |
CABLE, TV, NAV, AMP, VEH LOC TRAF INFO INTERFACE (I/P) (ACDelco #25865834) |
K1 (UL2, U3R, VFJ) |
2007-2009 |
01 |
| 004 |
|
HARNESS, I/P WRG (INCLS 3) ( |
|
2007-2009 |
|
| 005 |
11610157 |
|
|
2007-2009 |
AR |
| 006 |
20815326 |
RADIO, AM/FM STEREO NAVN (INCLS 8, 9) (ACDelco #20815326)
| CK1 (U3R) |
2007-2007 |
01 |
|
| 006 |
20815326 |
RADIO, AM/FM STEREO NAVN (INCLS 8, 9) (9.650) (ACDelco #20815326)
| CK1 (U3R) |
2007-2007 |
01 |
|
| 006 |
25798198 |
RADIO, AM/FM STEREO NAVN (INCLS 8, 9) (LABELED 25798198) (ACDelco #25798198) |
CK1 (U3R) |
2007-2007 |
01 |
| 006 |
25798198 |
RADIO, AM/FM STEREO NAVN (INCLS 8, 9) (LABELED 25798198) (9.650) (ACDelco #25798198) |
CK1 (U3R) |
2007-2007 |
01 |
| 007 |
11589012 |
|
|
2007-2009 |
06 |
| 008 |
19116343 |
KNOB, RDO TUNING CONT (PART OF 6, 13) |
CK1, 2, 3 (U3U) |
2007-2008 |
01 |
| 008 |
19116474 |
KNOB, RDO TUNING CONT (PART OF 6, 13) |
CK1 (U3R) |
2007-2008 |
01 |
| 009 |
19116343 |
KNOB, RDO VOL CONT (PART OF 6, 13) |
CK1, 2, 3 (U3U) |
2007-2008 |
01 |
| 009 |
19116474 |
KNOB, RDO VOL CONT (PART OF 6, 13) |
CK1 (U3R) |
2007-2008 |
01 |
| 010 |
|
DISC, NAVN DATA (FOR SERVICE SEE GM PARTS PROCESS/POLICY BULLETIN FOR LATEST SERVICE INFORMATION) |
|
2007-2009 |
|
| 011 |
25878602 |
PLATE, I/P ACSRY CTR TR (INCLS 12) ( |
CK1 (Z75, 19I) |
2007-2007 |
01 |
| 011 |
25878603 |
PLATE, I/P ACSRY CTR TR (INCLS 12) ( |
CK1 (Z75, 30I) |
2007-2009 |
01 |
| 012 |
11589329 |
CLIP, 12X8.9X15.5, SAE 1050 SPR STL, GMW3044 (PART OF 11)
|
2007-2009 |
07 |
|
| 013 |
25787813 |
RADIO, AM/FM STEREO CLK AUDIO/VIDEO DISC PLYR (INCLS 8, 9) (ACDelco #25787813)
| CK1 (YQ3) |
2007-2007 |
01 |
|
