| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
25904451 |
TANK, FUEL (29.6 GAL) (ORDER T/W 25904931)
| CK157 (06) (LM7, LQ4, LQ9, LR4) |
2004-2006 |
01 |
|
| 002 |
15745095 |
STRAP, F/TNK (FRT) |
CK1 (06-36) |
2004-2006 |
01 |
| 003 |
11519894 |
BOLT-HEX W/CON WA, M10X1.5X55, 42.3 THD, 20 OD, 10.9, 7114M, MACH, MAT-PT (F/TNK STRP) |
|
2004-2006 |
04 |
| 004 |
15745096 |
STRAP, F/TNK (RR) |
CK1 (06-36) |
2004-2006 |
01 |
| 005 |
11517806 |
NUT-U, M10X1.5, 30.5X28.6, 15.5 C/E, 2-5 PNL, 1050, 7111M (F/TNK STRP) |
|
2004-2006 |
02 |
| 006 |
15078884 |
SHIELD, F/TNK RR |
CK157 (06) (LM7, LQ4, LQ9, LR4) |
2004-2006 |
01 |
| 007 |
10009923 |
ГАЙКА, BOLT RETAINING ПРУЖИНА, M8X1.25, 25 O.D., ZOR (F/TNK SHLD) |
|
2004-2006 |
04 |
| 008 |
15077638 |
SHIELD, F/TNK HT (FRONT) |
CK157 (06) (LM7, LQ4, LQ9, LR4) |
2004-2006 |
01 |
| 009 |
15168952 |
RETAINER, F/TNK H/SHLD |
CK157 (06) (LM7, LQ4, LQ9, LR4) |
2004-2006 |
03 |
