(TC16-393) - 2008-2009 CK107(06) ЗАДНЕЕ СИДЕНЬЕ/BENCH-40% SIDE (AM8, POWER FOLDING ARS, EXC HYBRID HP2) CADILLAC - ESCALADE (2WD) 2009

Поз.НомерОписаниеПрименениеНоменклатураКол-во
001 15843841 SEAT, RR (ONLY AVAILABLE DURING CURRENT MODEL YEAR) (EBONY) CK107 (06) (AM8, ARS, KA6, Y91, Z88, 194) (EXC KB6) 2009-2009 01
001 15843842 SEAT, RR (ONLY AVAILABLE DURING CURRENT MODEL YEAR) (CASHMERE) CK107 (06) (AM8, ARS, KA6, Y91, Z88, 394) (EXC KB6) 2009-2009 01
001 15843847 SEAT, RR (ONLY AVAILABLE DURING CURRENT MODEL YEAR) (EBONY) CK107 (06) (AM8, ARS, KA6, Z75, 194) (EXC AX4, HP2) 2007-2009 01
001 15843859 SEAT, RR (ONLY AVAILABLE DURING CURRENT MODEL YEAR) (EBONY) CK107 (06) (AM8, ARS, AX4, KA6, Z75, 194) (EXPORT) 2007-2009 01
001 15914187 SEAT, RR (ONLY AVAILABLE DURING CURRENT MODEL YEAR) (EBONY) CK107 (06) (AM8, 19C, 5T5) 2009-2009 01
001 25908006 SEAT, RR (ONLY AVAILABLE DURING CURRENT MODEL YEAR) (CASHMERE) CK107 (06) (AM8, ARS, KA6, Z75, 394) (EXC AX4, HP2) 2009-2009 01
001 25908012 SEAT, RR (ONLY AVAILABLE DURING CURRENT MODEL YEAR) (CASHMERE) CK107 (06) (AM8, ARS, AX4, KA6, Z75, 394) (EXPORT) 2009-2009 01
001 25970963 SEAT, RR (ONLY AVAILABLE DURING CURRENT MODEL YEAR) (EBONY) CK107 (06) (AM8, 19C) (EXC 5T5) 2009-2009 01
001 25970964 SEAT, RR (ONLY AVAILABLE DURING CURRENT MODEL YEAR) (CASHMERE) CK107 (06) (AM8, 33C) 2009-2009 01
001 25970965 SEAT, RR (ONLY AVAILABLE DURING CURRENT MODEL YEAR) (TITANIUM) CK107 (06) (AM8, 83C) 2009-2009 01
002 15291651 COVER, R/SEAT BK CUSH (EBONY) CK1 (06) (AM8, KA6, Y91, Z88, 194) (EXC KB6) 2009-2009 01
002 15291652 COVER, R/SEAT BK CUSH (CASHMERE) CK1 (06) (AM8, KA6, Y91, Z88, 394) (EXC KB6) 2009-2009 01
002 15865525 COVER, R/SEAT BK CUSH (EBONY) CK1, 2 (06) (AM8, 193) (EXC KB6) 2009-2009 01
002 15865526 COVER, R/SEAT BK CUSH (CASHMERE) CK1, 2 (06) (AM8, 333) (EXC KB6) 2009-2009 01
002 15865527 COVER, R/SEAT BK CUSH (TITANIUM) CK1, 2 (06) (AM8, 833) (EXC KB6) 2009-2009 01
002 15914204 COVER, R/SEAT BK CUSH (EBONY) CK1, 2 (06) (AM8, 19C, 5T5) 2009-2009 01
002 20758111 COVER, R/SEAT BK CUSH (EBONY) (USED ON VEHICLES BUILT 12/01/08 AFTER) (1ST DES SEE 25970991) CK1, 2 (06) (AM8, 19C) (EXC 5T5) (2ND DES) 2009-2009 01
002 20758112 COVER, R/SEAT BK CUSH (CASHMERE) (USED ON VEHICLES BUILT 12/01/08 AFTER) (1ST DES SEE 25970992) CK1, 2 (06) (AM8, 33C) (2ND DES) 2009-2009 01
002 20758113 COVER, R/SEAT BK CUSH (TITANIUM) (USED ON VEHICLES BUILT 12/01/08 AFTER) (1ST DES SEE 25970993) CK1, 2 (06) (AM8, 83C) (2ND DES) 2009-2009 01
002 25908033 COVER, R/SEAT BK CUSH (CASHMERE) CK1 (06) (AM8, KA6, Y91, Z88, 397) (EXC HP2) 2009-2009 01
002 25908033 COVER, R/SEAT BK CUSH (CASHMERE) CK1 (06) (AM8, KA6, Z75, 394) (EXC HP2) 2009-2009 01
002 25931397 COVER, R/SEAT BK CUSH (CASHMERE) CK1, 2 (06) (AM8, KB6, 336) (EXC HP2) 2009-2009 01
002 25970991 COVER, R/SEAT BK CUSH (EBONY) (USED ON VEHICLES BUILT 11/30/08 PRIOR) (2ND DES SEE 20758111) CK1, 2 (06) (AM8, 19C) (EXC 5T5) (1ST DES) 2009-2009 01
002 25970992 COVER, R/SEAT BK CUSH (CASHMERE) (USED ON VEHICLES BUILT 11/30/08 PRIOR) (2ND DES SEE 20758112) CK1, 2 (06) (AM8, 33C) (1ST DES) 2009-2009 01
002 25970993 COVER, R/SEAT BK CUSH (EBONY) (USED ON VEHICLES BUILT 11/30/08 PRIOR) (2ND DES SEE 20758113) CK1, 2 (06) (AM8, 83C) (1ST DES) 2009-2009 01
003 15291598 PAD, R/SEAT BK CUSH CK1, 2 (06) (AM8) 2007-2009 01
004 COVER, R/SEAT H/RST SUPT (PART OF 5) 2008-2009
005 15824668 RESTRAINT, R/SEAT HD (INCLS 4) (EBONY) CK107 (06) (AM8, 193, 223, 843) 2007-2009 02
005 15824668 RESTRAINT, R/SEAT HD (INCLS 4) (EBONY) CK107 (06) (AM8, 196, 226, 846) 2009-2009 02
005 15824669 RESTRAINT, R/SEAT HD (INCLS 4) (CASHMERE) CK107 (06) (AM8, 313, 333) 2007-2009 02
005 15824669 RESTRAINT, R/SEAT HD (INCLS 4) (CASHMERE) CK107 (06) (AM8, 316, 336) 2009-2009 02
005 15824670 RESTRAINT, R/SEAT HD (INCLS 4) (TITANIUM) CK107 (06) (AM8, 833) 2007-2009 02
005 15824670 RESTRAINT, R/SEAT HD (INCLS 4) (TITANIUM) CK107 (06) (AM8, 836) 2009-2009 02
005 15824672 RESTRAINT, R/SEAT HD (INCLS 4) (EBONY) CK1 (06) (AM8, 194) 2007-2009 02
005 15824672 RESTRAINT, R/SEAT HD (INCLS 4) (EBONY) CK1 (06) (AM8, 197) 2009-2009 02
005 15865811 RESTRAINT, R/SEAT HD (INCLS 4) (TITANIUM) (USED ON VEHICLES BUILT 11/30/08 PRIOR) (2ND DES SEE 20758015) CK107 (06) (AM8, 83C) (1ST DES) 2009-2009 02
005 20758013 RESTRAINT, R/SEAT HD (INCLS 4) (EBONY) (USED ON VEHICLES BUILT 12/01/08 AFTER) (1ST DES SEE 25863652) CK107 (06) (AM8, 19C) (2ND DES) 2009-2009 02
005 20758014 RESTRAINT, R/SEAT HD (INCLS 4) (CASHMERE) CK107 (06) (AM8, 31C, 33C) 2009-2009 02
005 20758015 RESTRAINT, R/SEAT HD (INCLS 4) (TITANIUM) (USED ON VEHICLES BUILT 12/01/08 AFTER) (1ST DES SEE 15865811) CK107 (06) (AM8, 83C) (2ND DES) 2009-2009 02
005 25863652 RESTRAINT, R/SEAT HD (INCLS 4) (EBONY) (USED ON VEHICLES BUILT 11/30/08 PRIOR) (2ND DES SEE 20758013) CK107 (06) (AM8, 19C) (1ST DES) 2009-2009 02
005 25928791 RESTRAINT, R/SEAT HD (INCLS 4) (CASHMERE) CK1 (06) (AM8, 394) 2007-2009 02
005 25928791 RESTRAINT, R/SEAT HD (INCLS 4) (CASHMERE) CK1 (06) (AM8, 397) 2009-2009 02
007 15279351 GUIDE, R/SEAT H/RST (EBONY) (W/O BUTTON) CK1, 2 (06) (AL4, AM8, 19I, 84I) 2009-2009 02
007 15279352 GUIDE, R/SEAT H/RST (CASHMERE) (W/O BUTTON) CK1, 2 (06) (31I, 33I, 39I) 2007-2009 02
007 15279353 GUIDE, R/SEAT H/RST (TITANIUM) (W/O BUTTON) CK1, 2 (06-36) (83I) 2007-2009 02
008 15269763 FRAME, R/SEAT BK CUSH CK1, 2 (06) (AM8) 2007-2009 01
010 15291600 PAD, R/SEAT CUSH CK1, 2 (06) (AM8) (EXC HP2) 2007-2009 01
011 15269765 FRAME, R/SEAT CUSH CK1, 2 (06) (AM8) (EXC HP2) 2007-2009 01
012 11570116 SCREW -PAN HD, M6X1X10, 10 THD, 12 OD, STL SAE J1237, S424, TAPTITE ITE (R/SEAT LAT FIN CVR) (8.913) 2007-2009 09
013 11562384 ГАЙКА, HFH, M4X.7 THD, 4.75 THK, 10.5 OD, GM510M (9)STL, GM4435M-CODE A (R/SEAT FLR FIL T/PNL) 2007-2009 02
014 15279530 COVER, R/SEAT BK CUSH HGE FIN (EBONY) (INBOARD, INNER) (16.674) CK107 (06) (AM8, 19I, 22I, 84I) 2007-2009 01
014 15279531 COVER, R/SEAT BK CUSH HGE FIN (CASHMERE) (INBOARD, INNER) (16.674) CK107 (06) (AM8, 31I, 33I, 39I) 2007-2009 01
014 15279532 COVER, R/SEAT BK CUSH HGE FIN (TITANIUM) (INBOARD, INNER) (16.674) CK107 (06) (AM8, 83I) 2007-2009 01
014 15279533 COVER, R/SEAT BK CUSH HGE FIN (CASHMERE) (INBOARD, INNER) (16.674) CK107 (06) (AM8, 30I) 2007-2009 01
015 11562378 BOLT-HFH, M10X1.5X30, 18 THD, 22.3 OD, 10.9, GMW3359, W/ADH GM6175M (R/SEAT LAT) 2007-2009 12
016 15279464 KNOB, R/SEAT LAT (EBONY) (USED IN PLACE OF ALL COLORS) (16.716) CK1, 2, 3 2007-2009 02
017 15279504 COVER, R/SEAT BK CUSH HGE FIN (INCLS 41) (EBONY) (INBOARD, OUTER) (16.674) CK107 (06) (AM8, 19I, 22I, 84I) 2007-2009 01
017 15279505 COVER, R/SEAT BK CUSH HGE FIN (INCLS 41) (CASHMERE) (INBOARD, OUTER) (16.674) CK107 (06) (AM8, 31I, 33I, 39I) 2007-2009 01
017 15279506 COVER, R/SEAT BK CUSH HGE FIN (INCLS 41) (TITANIUM) (INBOARD, OUTER) CK107 (06) (AM8, 83I) 2007-2009 01
018 19121593 BELT KIT, R/SEAT (BKL SI) (SINGLE BKL) (EBONY) CK1, 2 (06) (AM8, 19I) 2009-2009 01
018 19121595 BELT KIT, R/SEAT (BKL SI) (CASHMERE) CK1, 2 (06) (AM8, 33I, 39I) 2009-2009 01
018 19121596 BELT KIT, R/SEAT (BKL SI) (SINGLE BKL) (TITANIUM) CK1, 2 (06) (AM8, 83I) 2007-2009 01
020 15275888 LATCH, R/SEAT RSR (OUTBOARD) CK107 (06) (AM8) 2007-2009 02
021 11562380 BUSHING, R/SEAT HGE CK1, 2 (06) (AM8) 2007-2009 08
022 15275901 ПРУЖИНА, R/SEAT RECL (TUMBLE) CK1, 2 (06) (AM8) 2007-2009 02
023 15275903 ПРУЖИНА, R/SEAT RECL (MANDREL) CK1, 2 (06) (AM8) 2007-2009 02
024 15275905 STRUT, R/SEAT CK1, 2 (06) (AM8) 2007-2009 01
024 15930099 STRUT, R/SEAT CK1, 2 (06) (AM8) 2007-2009 01
025 15279554 PANEL, R/SEAT CUSH TR (EBONY) (16.716) CK107 (06) (AM8, 19I, 22I, 84I) (EXC HP2) 2007-2009 01
025 15279555 PANEL, R/SEAT CUSH TR (CASHMERE) (16.716) CK107 (06) (AM8, 31I, 33I, 39I) (EXC HP2) 2007-2009 01
025 15279556 PANEL, R/SEAT CUSH TR (TITANIUM) (16.716) CK107 (06) (AM8, 83I) (EXC HP2) 2007-2009 01
026 15279609 COVER, R/SEAT RSR FIN (EBONY) (REAR) CK107 (06) (AM8, 19I, 22I, 84I) 2007-2009 01
026 15279610 COVER, R/SEAT RSR FIN (CASHMERE) (REAR) CK107 (06) (AM8, 31I, 33I, 39I) 2007-2009 01
026 15279611 COVER, R/SEAT RSR FIN (TITANIUM) (REAR) CK107 (06) (AM8, 83I) 2007-2009 01
026 15279612 COVER, R/SEAT RSR FIN (CASHMERE) (REAR) CK107 (06) (AM8, 30I) 2007-2009 01
027 15269772 RISER, R/SEAT CK107 (06) (AM8) (EXC HP2) 2007-2009 01
028 11562379 БОЛТ, R/SEAT HGE (M10X1.5X92) CK1, 2, 3 2007-2009 02
029 RETAINER, R/SEAT FLR FIL T/PNL (PART OF 30) 2008-2009
030 15279599 COVER, R/SEAT RSR FIN (INCLS 29) (EBONY) (FRONT) CK107 (06) (AM8, 19I, 22I, 84I) 2007-2009 01
030 15279600 COVER, R/SEAT RSR FIN (INCLS 29) (CASHMERE) (FRONT) CK107 (06) (AM8, 31I, 33I, 39I) 2007-2009 01
030 15279601 COVER, R/SEAT RSR FIN (INCLS 29) (TITANIUM) (FRONT) CK107 (06) (AM8, 83I) 2007-2009 01
030 15279602 COVER, R/SEAT RSR FIN (INCLS 29) (CASHMERE) (FRONT) CK107 (06) (AM8, 30I) 2007-2009 01
031 15843763 HARNESS, ST RECL WRG (ELEMENT) CK1 (06) (AM8, ARS, KA6, Y91, Z88, 194, 394) (EXC KB6) 2007-2009 01
032 15279406 PIN, R/SEAT H/RST ADJ ROD LAT (EBONY) CK1, 2 (06) (AM8, 19I) 2009-2009 02
032 15279407 PIN, R/SEAT H/RST ADJ ROD LAT (CASHMERE) CK1, 2 (06) (AM8, 33I, 39I) 2009-2009 02
032 15279408 PIN, R/SEAT H/RST ADJ ROD LAT (TITANIUM) CK1, 2 (06) (AM8, 83I) 2007-2009 02
033 15824750 ACTUATOR, R/SEAT RECL (INCLS CABLE) CK1, 2 (06) (AM8, ARS) 2007-2009 01
034 15942229 CABLE, R/SEAT BK CUSH LAT CK1, 2 (06) (AM8, ARS) 2007-2009 01
035 15275915 CABLE, R/SEAT LAT (INBOARD) (SYNCH) CK1, 2 (06) (AM8) 2007-2009 01
036 15275914 CABLE, R/SEAT LAT (OUTBOARD) (FLOOR LATCH) CK1, 2 (06) (AM8) 2007-2009 02
037 25896457 LATCH, R/SEAT BK CUSH (OUTBOARD) CK1, 2 (06) (AM8) 2007-2009 01
038 15279419 HANDLE, R/SEAT RECL (INCLS 39) (EBONY) CK1, 2 (06) (19I, 22I, 84I) 2007-2009 01
038 15279420 HANDLE, R/SEAT RECL (INCLS 39) (CASHMERE) CK1, 2 (06) (31I, 33I, 39I) 2007-2009 01
038 15279429 HANDLE, R/SEAT RECL (INCLS 39) (TITANIUM) CK1, 2 (06) (83I) 2007-2009 01
039 RETAINER, R/SEAT ADJR RLR (PART OF 38) 2008-2009
040 15279484 COVER, R/SEAT BK CUSH HGE FIN (INCLS 41) (EBONY) (OUTBOARD, OUTER) (16.674) CK107 (06) (AM8, 19I, 22I, 84I) 2007-2009 01
040 15279485 COVER, R/SEAT BK CUSH HGE FIN (INCLS 41) (CASHMERE) (OUTBOARD, OUTER) (16.674) CK107 (06) (AM8, 31I, 33I, 39I) 2007-2009 01
040 15279486 COVER, R/SEAT BK CUSH HGE FIN (INCLS 41) (TITANIUM) (OUTBOARD, OUTER) (16.674) CK107 (06) (AM8, 83I) 2007-2009 01
041 RETAINER, R/SEAT FLR FIL T/PNL (PART OF 17, 40) 2008-2009
042 15279494 COVER, R/SEAT BK CUSH HGE FIN (EBONY) (OUTBOARD, INNER) (16.674) CK107 (06) (AM8, 19I, 22I, 84I) 2007-2009 01
042 15279495 COVER, R/SEAT BK CUSH HGE FIN (CASHMERE) (OUTBOARD, INNER) (16.674) CK107 (06) (AM8, 31I, 33I, 39I) 2007-2009 01
042 15279496 COVER, R/SEAT BK CUSH HGE FIN (TITANIUM) (OUTBOARD, INNER) (16.674) CK107 (06) (AM8, 83I) 2007-2009 01
043 15291658 COVER, R/SEAT CUSH (CASHMERE) CK1 (06) (AM8, KA6, Y91, Z88, 394) (EXC KB6) 2009-2009 01
043 15865714 COVER, R/SEAT CUSH (EBONY) CK1, 2 (06) (AM8, 193) (EXC HP2, KB6) 2009-2009 01
043 15865715 COVER, R/SEAT CUSH (CASHMERE) CK1, 2 (06) (AM8, 333) (EXC HP2, KB6) 2009-2009 01
043 15865716 COVER, R/SEAT CUSH (TITANIUM) CK1, 2 (06) (AM8, 833) (EXC HP2, KB6) 2009-2009 01
043 15914208 COVER, R/SEAT CUSH (EBONY) CK1, 2 (06) (AM8, 19C, 5T5) 2009-2009 01
043 20758119 COVER, R/SEAT CUSH (EBONY) (USED ON VEHICLES BUILT 12/01/08 AFTER) (1ST DES SEE 25970999) CK1, 2 (06) (AM8, 19C) (EXC 5T5) (2ND DES) 2009-2009 01
043 20758120 COVER, R/SEAT CUSH (CASHMERE) (USED ON VEHICLES BUILT 12/01/08 AFTER) (1ST DES SEE 25971000) CK1, 2 (06) (AM8, 33C) (EXC 5T5) (2ND DES) 2009-2009 01
043 20758121 COVER, R/SEAT CUSH (TITANIUM) (USED ON VEHICLES BUILT 12/01/08 AFTER) (1ST DES SEE 25971001) CK1, 2 (06) (AM8, 83C) (EXC 5T5) (2ND DES) 2009-2009 01
043 25908034 COVER, R/SEAT CUSH (CASHMERE) CK1 (06) (AM8, KA6, Z75, 394) 2009-2009 01
043 25931403 COVER, R/SEAT CUSH (CASHMERE) CK1, 2 (06) (AM8, KB6, 336) 2009-2009 01
043 25970999 COVER, R/SEAT CUSH (EBONY) (USED ON VEHICLES BUILT 11/30/08 PRIOR) (2ND DES SEE 20758119) CK1, 2 (06) (AM8, 19C) (EXC 5T5) (1ST DES) 2009-2009 01
043 25971000 COVER, R/SEAT CUSH (CASHMERE) (USED ON VEHICLES BUILT 11/30/08 PRIOR) (2ND DES SEE 20758120) CK1, 2 (06) (AM8, 33C) (1ST DES) 2009-2009 01
043 25971001 COVER, R/SEAT CUSH (TITANIUM) (USED ON VEHICLES BUILT 11/30/08 PRIOR) (2ND DES SEE 20758121) CK1, 2 (06) (AM8, 83C) (1ST DES) 2009-2009 01
