| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
|
HARNESS, RF WRG (СМ. ГРУППУ 02.000 ЖГУТЫ ПРОВОДОВ/ROOF ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2007-2009 |
|
| 003 |
|
RECEIVER, DIGITAL RDO (СМ. ГРУППУ 9.000 АНТЕННА/АУДИОСИСТЕМА ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2007-2009 |
|
| 004 |
19116678 |
CABLE, DIGITAL RDO АНТЕННА (PART OF 8) (IN I/P WRG) |
CK1 (06) (UE1, Y91, Z88) (EXC U2K) |
2008-2008 |
01 |
| 004 |
19116705 |
CABLE, DIGITAL RDO АНТЕННА (PART OF 8) (IN I/P WRG) (ACDelco #19116705) |
CK1 (06) (UE1, U2K, Y91, Z88) |
2008-2008 |
01 |
| 005 |
19149310 |
BLOCK, I/P WRG HARN JUNC (PART OF 8) |
C1, 2, 3 |
2007-2009 |
01 |
| 006 |
|
HARNESS, BODY WRG (СМ. ГРУППУ 02.000 ЖГУТЫ ПРОВОДОВ/КУЗОВ ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2007-2009 |
|
| 007 |
|
MODULE, COMN INTERFACE (W/MOBILE TEL XCVR) (СМ. ГРУППУ 09.000 COMMUNICATIONS SYSTEM ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) (CASTING NUMBER 15800440) |
|
2007-2009 |
|
| 008 |
25892103 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
C1 (06) (UE1, U2K, U3U, Y91, Z88) (EXC BRS, U42) |
2008-2008 |
01 |
| 008 |
25892104 |
HARNESS, I/P WRG (EXTERNAL RING TERMINAL) (INCLS 4, 5) |
C1 (06) (U3U, UE1, Y91, Z88) (EXC BRS, U2K, U42) |
2008-2008 |
01 |
| 008 |
25892106 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
C1 (06) (UE1, UVA, UVB, U42, Y91, Z88) (EXC BRS, U2K) |
2008-2008 |
01 |
| 008 |
25892122 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
C1 (06) (UE1, UVA, UVB, U2K, U42, Y91, Z88) (EXC BRS) |
2008-2008 |
01 |
| 008 |
25892123 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
C1 (06) (UE1, US9, U2K, Y91, Z88) (EXC BRS, U42) |
2008-2008 |
01 |
| 008 |
25892124 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
C1 (06) (UE1, US9, Y91, Z88) (EXC BRS, U2K, U42) |
2008-2008 |
01 |
| 008 |
25892132 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
C1 (06) (BRS, UE1, U2K, U3U, Y91, Z88) (EXC U42) |
2008-2008 |
01 |
| 008 |
25892133 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
C1 (06) (BRS, UE1, U3U, Y91, Z88) (EXC U2K, U42) |
2008-2008 |
01 |
| 008 |
25892135 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
C1 (06) (BRS, UE1, UVA, UVB, U42, Y91, Z88) (EXC U2K) |
2008-2008 |
01 |
| 008 |
25892146 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
C1 (06) (BRS, UE1, US9, U2K, Y91, Z88) (EXC U42) |
2008-2008 |
01 |
| 008 |
25892147 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
C1 (06) (BRS, UE1, US9, Y91, Z88) (EXC U2K, U42) |
2008-2008 |
01 |
| 008 |
25892149 |
HARNESS, I/P WRG (EXTERNAL GROUND RING TERMINAL) (INCLS 4, 5) |
C1 (06) (BRS, UE1, UVA, UVB, U2K, U42, Y91, Z88) |
2008-2008 |
01 |
| 010 |
11589012 |
БОЛТ, HWH, M4.2X1.41X25, 16.4 THD, 12.5 OD, GM6010M STL, GMW4205 (I/P WRG HARN DATA LINK CONN) (9.665)
|
2007-2009 |
01 |
|
| 011 |
11609411 |
ГАЙКА, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (I/P WRG HARN GND)
|
2007-2009 |
02 |
|
| 012 |
|
BLOCK, ENG WRG HARN JUNC (СМ. ГРУППУ 02.000 BLOCK/ДВИГАТЕЛЬ HARNESS JUNCTION ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2007-2009 |
|
