| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
89027012 |
ШЛАНГИ KIT, RR BRK CLPR (INCLS 2-6, 14-16) |
C1 (06-36) (JH2) |
2006-2006 |
01 |
| 001 |
89027013 |
ШЛАНГИ KIT, RR BRK CLPR (INCLS 2-6, 14-16) |
C1 (06-36) (JH2) |
2006-2006 |
01 |
| 002 |
|
PLUG, RR BRK CLPR TUBE ST (PART OF 1) |
|
2004-2006 |
|
| 003 |
89027011 |
БОЛТ, RR DISC BRK PAD SPR (PART OF 1, 10, 14) (*KIT1, KIT2) |
C1 (06-36) (JH2) |
2006-2006 |
04 |
| 004 |
|
SEAL, RR BRK CLPR BLEDR VLV (O RING) (PART OF 1, 5) |
|
2004-2006 |
|
| 005 |
88982611 |
BOLT KIT, RR BRK BLEDR VLV (PART OF 1) (INCLS 4, 6) (4.665) |
C1 (06-36) |
2002-2006 |
02 |
| 006 |
|
CAP, RR BRK BLEDR VLV (PART OF 1, 5) |
|
2004-2006 |
|
| 007 |
|
PIN, RR BRK CLPR PSTN COT (*KIT1) |
|
2004-2006 |
|
| 008 |
|
BUSHING, RR BRK SHOE (*KIT1) |
|
2004-2006 |
|
| 009 |
|
BOOT, RR BRK CLPR GDE PIN (*KIT1) |
|
2004-2006 |
|
| 010 |
|
PAD KIT, RR DISC BRK (INCLS 3, 12, 13) |
|
2005-2006 |
|
| 010 |
89027010 |
PAD KIT, RR DISC BRK (INCLS 3, 12, 13) (ACDelco #171-0870)
| C1 (06-36) (JH2) |
2006-2006 |
01 |
|
| 011 |
|
BRACKET, RR BRK CLPR |
|
2002-2006 |
|
| 011 |
88982612 |
BRACKET, RR BRK CLPR |
C1 (06-36) (JH2) |
2004-2006 |
02 |
| 012 |
|
CLIP, RR BRK (PART OF 10) (*KIT2) |
|
2004-2006 |
|
| 013 |
|
CLIP, RR BRK (PART OF 10) (*KIT2) |
|
2004-2006 |
|
| 014 |
89027014 |
PISTON KIT, RR BRK CLPR (INCLS 3, 15, 16) (PART OF 1) |
C1 (06-36) (JH2) |
2006-2006 |
02 |
| 015 |
|
BOOT, RR BRK CLPR PSTN (PART OF 1, 14) |
|
2004-2006 |
|
| 016 |
|
SEAL, RR BRK CLPR PSTN (PART OF 1, 14) |
|
2004-2006 |
|
| 017 |
|
PIN, RR BRK CLPR GDE (*KIT1) |
|
2004-2006 |
|
| K01 |
89027015 |
PIN KIT, RR BRK CLPR GDE (INCLS 3, 7-9, 17) |
C1 (06-36) (JH2) |
2004-2006 |
02 |
| K02 |
89027018 |
RETAINER KIT, RR DISC BRK PAD (INCLS 3, 12, 13) |
C1 (06-36) (JH2) |
2006-2006 |
01 |
