| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
20916640 |
HARNESS, STRG WHL PAD ACSRY WRG (PART OF 13) |
DM35-47-69 (KB7, N30, UVD, 03F) |
2011-2013 |
01 |
| 001 |
20916640 |
HARNESS, STRG WHL PAD ACSRY WRG (PART OF 13) |
DR35-69 (KB7, N30, UVD, 03F) (EXPORT) |
2011-2013 |
01 |
| 002 |
20892780 |
SWITCH, A/TRNS MAN SHFT AUX POSN (PART OF 13) (ACDelco #20892780) (LABELED 20892780) |
DM, DN35-47-69 (KB7) |
2011-2013 |
01 |
| 002 |
20892780 |
SWITCH, A/TRNS MAN SHFT AUX POSN (PART OF 13) (ACDelco #20892780) (LABELED 20892780) |
DR35-69 (KB7) (EXPORT) |
2011-2013 |
01 |
| 003 |
25919049 |
BEZEL, STRG WHL SPOKE CONT SW (PART OF 13) (SILVER) (3 OCLOCK TRIM PLATE) |
DM |
2011-2013 |
01 |
| 003 |
25919049 |
BEZEL, STRG WHL SPOKE CONT SW (PART OF 13) (SILVER) (3 OCLOCK TRIM PLATE) |
DR |
2011-2013 |
01 |
| 004 |
25889493 |
BOLT, STRG WHL HORN SW (PART OF 13) (PAN HEAD, SPECIAL THREAD, 8 OD, 13 LENGTH, 1022 STL.) (6.512) |
DM (N30, 03F) |
2011-2013 |
06 |
| 004 |
25889493 |
BOLT, STRG WHL HORN SW (PART OF 13) (PAN HEAD, SPECIAL THREAD, 8 OD, 13 LENGTH, 1022 STL.) (6.512) |
DR (N30, 03F) |
2011-2013 |
06 |
| 005 |
25850372 |
SWITCH, RDO CONT (PART OF 13) (ARGENT) (9.649) |
D35-47-69 |
2011-2013 |
01 |
| 005 |
25850372 |
SWITCH, RDO CONT (PART OF 13) (ARGENT) |
D35-47-69 |
2011-2013 |
01 |
| 006 |
25889494 |
BOLT, STRG WHL HORN SW (PART OF 13) (TAPPING SCREW, SHLDR, 23 LENGTH, 13.5 OD, STL, ZN) |
DM35-47-69 (N30, 03F) |
2011-2013 |
03 |
| 006 |
25889494 |
BOLT, STRG WHL HORN SW (PART OF 13) (TAPPING SCREW, SHLDR, 23 LENGTH, 13.5 OD, STL, ZN) |
DR35-47-69 (N30, 03F) |
2011-2013 |
03 |
| 007 |
11610164 |
BOLT, STRG WHL (M15X1.5X28.77) |
D |
2011-2013 |
01 |
| 008 |
25943875 |
AIRBAG, STRG WHL (EBONY) (14.865) |
DM35-69 (4AL, 4AM, 4AR) (EXC EF7, Z49) |
2011-2013 |
01 |
| 008 |
20936094 |
AIRBAG, STRG WHL (EBONY) (14.865) |
DM35-69 (EF7, Z49, 4AL, 4AM, 4AR) |
2011-2013 |
01 |
| 008 |
20936095 |
AIRBAG, STRG WHL (COCOA) (14.865) |
DM35-69 (EF7, Z49, 4AC) |
2011-2013 |
01 |
| 008 |
25943876 |
AIRBAG, STRG WHL (COCOA) (14.865) |
DM35-69 (4AC) (EXC EF7, Z49) |
2011-2013 |
01 |
| 008 |
25943876 |
AIRBAG, STRG WHL (COCOA) (14.865) |
DR35-69 (4AC) (EXPORT) |
2011-2013 |
01 |
| 008 |
25943875 |
AIRBAG, STRG WHL (EBONY) (14.865) |
DR35-69 (4AL, 4AM) (EXPORT) |
2012-2013 |
01 |
| 009 |
25889495 |
CONTACT, STRG WHL HORN (PART OF 13) |
D35 |
2011-2013 |
01 |
| 010 |
20916638 |
COVER, STRG WHL SPOKE LWR (PART OF 13) (SILVER) (6 OCLOCK TRIM PLATE) |
DM (N30, UVD) |
2011-2013 |
01 |
| 010 |
25919022 |
COVER, STRG WHL SPOKE LWR (PART OF 13) (SILVER) (6 OCLOCK TRIM PLATE) |
DM (N30) (EXC UVD) |
2011-2013 |
01 |
| 010 |
20916638 |
COVER, STRG WHL SPOKE LWR (PART OF 13) (SILVER) (6 OCLOCK TRIM PLATE) |
DR (N30, UVD) (EXPORT) |
2011-2013 |
01 |
| 010 |
25919022 |
COVER, STRG WHL SPOKE LWR (PART OF 13) (SILVER) (6 OCLOCK TRIM PLATE) |
DR (N30) (EXC UVD) (EXPORT) |
2011-2013 |
01 |
| 011 |
22865856 |
MODULE, STRG WHL HT CONT (PART OF 13) (ACDelco #22865856) |
DM (N30, UVD, 03F) |
2012-2013 |
01 |
| 011 |
22865856 |
MODULE, STRG WHL HT CONT (PART OF 13) (ACDelco #22865856) |
DR (N30, UVD, 03F) (EXPORT) |
2012-2013 |
01 |
| 012 |
|
BOLT, STRG WHL HT CONT MDL (PART OF 13) |
|
2011-2013 |
|
| 013 |
20857822 |
WHEEL, STRG (INCLS 1-6, 9-12, 14-17) (EBONY) |
DM35-69 (KB7, N30, 03F, 4AL, 4AM) (EXC UVD) |
2011-2013 |
01 |
| 013 |
20857823 |
WHEEL, STRG (INCLS 1-6, 9-12, 14-17) (COCOA) |
DM35-69 (KB7, N30, 03F, 4AC) (EXC UVD) |
2011-2013 |
01 |
| 013 |
22898837 |
WHEEL, STRG (INCLS 1-6, 9-12, 14-17) (EBONY) |
DM35-69 (KB7, N30, UVD, 03F, 4AL, 4AM) |
2011-2013 |
01 |
| 013 |
22898838 |
WHEEL, STRG (INCLS 1-6, 9-12, 14-17) (COCOA) |
DM35-69 (KB7, N30, UVD, 03F, 4AC) |
2013-2013 |
01 |
| 013 |
20857822 |
WHEEL, STRG (INCLS 1-6, 9-12, 14-17) (EBONY) |
DR35-69 (KB7, N30, 03F, 4AL, 4AM) (EXC UVD) (EXPORT) |
2011-2013 |
01 |
| 013 |
20857823 |
WHEEL, STRG (INCLS 1-6, 9-12, 14-17) (COCOA) |
DR35-69 (KB7, N30, 03F, 4AC) (EXC UVD) (EXPORT) |
2011-2013 |
01 |
| 013 |
22898838 |
WHEEL, STRG (INCLS 1-6, 9-12, 14-17) (COCOA) |
DR35-69 (KB7, N30, UVD, 03F, 4AC) (EXPORT) |
2013-2013 |
01 |
| 013 |
22898837 |
WHEEL, STRG (INCLS 1-6, 9-12, 14-17) (EBONY) |
DR35-69 (KB7, N30, UVD, 03F, 4AL, 4AM) (EXPORT) |
2013-2013 |
01 |
| 014 |
25954182 |
BOLT, A/TRNS MAN SHFT SHF POSN SW (PART OF 13) |
DM (KB7) |
2011-2013 |
02 |
| 014 |
25954182 |
BOLT, A/TRNS MAN SHFT SHF POSN SW (PART OF 13) |
DR (KB7) (EXPORT) |
2011-2013 |
02 |
| 015 |
20916648 |
SWITCH, A/TRNS MAN SHFT AUX POSN (PART OF 13) (BLACK) (ACDelco #20916648) |
D (KB7) |
2011-2013 |
01 |
| 016 |
15912879 |
SWITCH, CRCONT (PART OF 13) (ACDelco #15912879) |
DM35-47-69 (N30) |
2011-2013 |
01 |
| 016 |
15912879 |
SWITCH, CRCONT (PART OF 13) (ACDelco #15912879) |
DR35-69 (N30) (EXPORT) |
2011-2013 |
01 |
| 017 |
25919045 |
BEZEL, STRG WHL SPOKE CONT SW (PART OF 13) (SILVER) (9 OCLOCK TRIM PLATE) |
DM |
2011-2013 |
01 |
| 017 |
25919045 |
BEZEL, STRG WHL SPOKE CONT SW (PART OF 13) (SILVER) (9 OCLOCK TRIM PLATE) |
DR |
2011-2013 |
01 |
