| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
20982719 |
CALIPER, FRT BRK (INCLS 4-7, 12, 13) (YELLOW) (V LOGO) (ACDelco #172-2521) |
DN (J56, J6E) |
2013-2013 |
01 |
| 001 |
20982734 |
CALIPER, FRT BRK (INCLS 4-7, 12, 13) (YELLOW) (V LOGO) (ACDelco #172-2522) |
DN (J56, J6E) |
2013-2013 |
01 |
| 001 |
22885106 |
CALIPER, FRT BRK (INCLS 4-7, 12, 13) (RED) (ACDelco #172-2595) |
DN (J56, J6F) |
2013-2013 |
01 |
| 001 |
22885108 |
CALIPER, FRT BRK (INCLS 4-7, 12, 13) (RED) (ACDelco #172-2596) |
DN (J56, J6F) |
2013-2013 |
01 |
| 001 |
25912477 |
CALIPER, FRT BRK (INCLS 4-7, 12, 13) (SILVER) (V LOGO) (ACDelco #172-2487) |
DN (J56) (EXC J6E, J6F) |
2013-2013 |
01 |
| 001 |
25912967 |
CALIPER, FRT BRK (INCLS 4-7, 12, 13) (SILVER) (V LOGO) (ACDelco #172-2488) |
DN (J56) (EXC J6E, J6F) |
2013-2013 |
01 |
| 001 |
20982719 |
CALIPER, FRT BRK (4.057 KGS) (INSTALL .60) (INCLS 4-7, 12, 13) (YELLOW) (V LOGO) (ACDelco #172-2521) |
DN (EF7, Z49, RXO) |
2013-2013 |
01 |
| 001 |
20982734 |
CALIPER, FRT BRK (4.057 KGS) (INSTALL .60) (INCLS 4-7, 12, 13) (YELLOW) (V LOGO) (ACDelco #172-2522) |
DN (EF7, Z49, RXO) |
2013-2013 |
01 |
| 002 |
25940448 |
PIN KIT, FRT DISC BRK PAD (INCLS 3, 8, 9) |
DN (J56) |
2011-2013 |
01 |
| 002 |
25940448 |
PIN KIT, FRT DISC BRK PAD (INCLS 3, 8, 9) |
DN (J6E, J6F) |
2012-2013 |
01 |
| 003 |
|
SPRING, FRT BRK CLPR (PART OF 2) |
|
2011-2013 |
|
| 004 |
25940445 |
PISTON KIT, FRT BRK CLPR (INCLS 5) (PART OF 1) (30/34/38MM) (INCLS 6 PISTONS 6 PISTON SEALS) (ACDelco #25940445) |
DN (J56, J6E) |
2011-2013 |
02 |
| 005 |
|
SEAL, FRT BRK CLPR PSTN (PART OF 1, 4) |
|
2011-2013 |
|
| 006 |
19207044 |
BOOT KIT, FRT BRK CLPR PSTN (PART OF 1) |
DN (J56) |
2011-2013 |
02 |
| 006 |
19207044 |
BOOT KIT, FRT BRK CLPR PSTN (PART OF 1) |
DN (J6E) |
2011-2013 |
02 |
| 007 |
|
PIPE, FRT BRK LWR (PART OF 1) |
|
2011-2013 |
|
| 008 |
|
BOLT, FRT BRK CLPR GDE PIN (PART OF 2) |
|
2011-2013 |
|
| 009 |
|
PIN, FRT BRK CLPR GDE (PART OF 2) |
|
2011-2013 |
|
| 010 |
|
SHIM, FRT BRK PAD (ANTI-NOISE) (PART OF 11) |
|
2011-2013 |
|
| 011 |
25940447 |
PAD KIT, FRT DISC BRK (INCLS 10) (ACDelco #171-1040) |
DN (J56) |
2011-2013 |
01 |
| 011 |
25940447 |
PAD KIT, FRT DISC BRK (INCLS 10) (ACDelco #171-1040) |
DN (J6E, J6F) |
2012-2013 |
01 |
| 012 |
25900782 |
VALVE KIT, FRT BRK CLPR BLEDR (INCLS 13) (PART OF 1) (INCLS CAP) (ACDelco #25900782) |
DN |
2011-2013 |
02 |
| 013 |
|
CAP, FRT BRK CLPR BLEDR VLV (PART OF 1, 12) |
|
2011-2013 |
|
