| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 011 |
20897231 |
PLATE, CARGO NET BRKT TR (TITANIUM) (1 FRT/1 RR) |
D35 (4AL, 4AM) |
2010-2011 |
02 |
| 011 |
20897234 |
PLATE, CARGO NET BRKT TR (TITANIUM) (1 FRT/1 RR) |
D35 (4AL, 4AM) |
2010-2011 |
02 |
| 011 |
20897230 |
PLATE, CARGO NET BRKT TR (CASHMERE) (1 FRT/1 RR) |
DR35 (4AC) (EXPORT) |
2011-2011 |
02 |
| 011 |
20897233 |
PLATE, CARGO NET BRKT TR (CASHMERE) (1 FRT/1 RR) |
DR35 (4AC) (EXPORT) |
2011-2011 |
02 |
| 012 |
96946829 |
RETAINER, HDLNG T/PNL (TITANIUM) (26MM LG 7.00 DIA) (LARGE PUSH PIN) |
D35 (4AL, 4AM) |
2010-2011 |
01 |
| 012 |
10371732 |
RETAINER, HDLNG T/PNL (CASHMERE) (26MM LG 7.00 DIA) (LARGE PUSH PIN) |
D35 (4AC) |
2010-2011 |
01 |
| 013 |
25868417 |
TELLTALE, INFO CTR (HDLNG TR) (ACDelco #25868417) |
D35 (UD7, VRK) |
2010-2011 |
01 |
| 014 |
15291486 |
BEZEL, INFO CTR TELLTALE (CASHMERE) |
D35 (UD7, VRK, 4AC) |
2010-2011 |
01 |
| 014 |
15291487 |
BEZEL, INFO CTR TELLTALE (TITANIUM) |
D35 (UD7, VRK, 4AL, 4AM) |
2010-2011 |
01 |
| 015 |
25932366 |
LAMP, RDG (INCLS 16-18) (TITANIUM) |
D35 (4AL, 4AM) |
2010-2011 |
01 |
| 015 |
25932367 |
LAMP, RDG (INCLS 16-18) (CASHMERE) |
D35 (VRK, 4AC, 4AR) |
2011-2011 |
01 |
| 016 |
|
LENS, DM RDG LP (PART OF 15) |
|
2010-2011 |
|
| 017 |
01999382 |
BULB, (PART OF 15) (ACDelco #W5WLL) (LONGER LIFE) |
|
2010-2011 |
02 |
| 018 |
11588650 |
CLIP, 12X14X16.6, GM4345M (PART OF 15) |
|
2010-2011 |
02 |
| 019 |
20942363 |
HANDLE, R/RL RR ASST (INCLS 20) (TITANIUM) |
DM35-69 (C3U, 4AL, 4AM) |
2010-2011 |
01 |
| 019 |
20942366 |
HANDLE, R/RL RR ASST (INCLS 20) (TITANIUM) |
DM35-69 (C3U, 4AL, 4AM) |
2010-2011 |
01 |
| 019 |
20942362 |
HANDLE, R/RL RR ASST (INCLS 20) (CASHMERE) |
DM35 (C3U, 4AC) |
2010-2011 |
01 |
| 019 |
20942365 |
HANDLE, R/RL RR ASST (INCLS 20) (CASHMERE) |
DM35 (C3U, 4AC) |
2010-2011 |
01 |
| 019 |
20942363 |
HANDLE, R/RL RR ASST (INCLS 20) (TITANIUM) |
DR35-69 (C3U, 4AL, 4AM) (EXPORT) |
2010-2011 |
01 |
| 019 |
20942366 |
HANDLE, R/RL RR ASST (INCLS 20) (TITANIUM) |
DR35-69 (C3U, 4AL, 4AM) (EXPORT) |
2010-2011 |
01 |
| 019 |
20942362 |
HANDLE, R/RL RR ASST (INCLS 20) (CASHMERE) |
DR35 (C3U, 4AC) (EXPORT) |
2010-2011 |
01 |
| 019 |
20942365 |
HANDLE, R/RL RR ASST (INCLS 20) (CASHMERE) |
DR35 (C3U, 4AC) (EXPORT) |
2010-2011 |
01 |
| 020 |
11569613 |
BOLT, HFH, M6X1X25, 19 THD, 12 OD, GM6202M STL, GMW3359, TAPTITE (PART OF 19) |
|
2010-2011 |
04 |
| 001 |
20943437 |
PANEL, HDLNG TR (INCLS 2, 6, 7, 33, 34) (TITANIUM) |
DM35 (C3U, U2X, 4AL, 4AM) (EXC UE1) |
2011-2011 |
01 |
| 001 |
20943438 |
PANEL, HDLNG TR (INCLS 2, 6, 7, 33, 34) (CASHMERE) |
DM35 (C3U, U2X, 4AC) (EXC UE1) |
2011-2011 |
01 |
| 001 |
22784102 |
PANEL, HDLNG TR (INCLS 2, 6, 7, 33, 34) (CASHMERE) |
D35 (C3U, UAV, UE1, 4AC, 4AR) |
2011-2011 |
01 |
| 001 |
22787413 |
PANEL, HDLNG TR (INCLS 2, 6, 7, 33, 34) (TITANIUM) |
D35 (C3U, UAV, UE1, 4AL, 4AM) |
2011-2011 |
01 |
| 001 |
22787392 |
PANEL, HDLNG TR (INCLS 2, 6, 7, 33, 34) (TITANIUM) |
D35 (C3U, U2X, 4AL, 4AM) |
2011-2011 |
01 |
| 001 |
22787393 |
PANEL, HDLNG TR (INCLS 2, 6, 7, 33, 34) (CASHMERE) |
D35 (C3U, U2X, 4AC) |
2011-2011 |
01 |
| 001 |
22787395 |
PANEL, HDLNG TR (INCLS 2, 6, 7, 33, 34) (TITANIUM) |
D35 (C3U, UE1, U2R, U2S, U2T, 4AL, 4AM) |
2011-2011 |
01 |
| 001 |
22787396 |
PANEL, HDLNG TR (INCLS 2, 6, 7, 33, 34) (CASHMERE) |
D35 (C3U, UE1, U2R, U2S, U2T, 4AC) |
2011-2011 |
01 |
| 001 |
22787411 |
PANEL, HDLNG TR (INCLS 2, 6, 7, 33, 34) (CASHMERE) |
D35 (C3U, U2Y, 4AC, 4AR) |
2011-2011 |
01 |
| 001 |
22787416 |
PANEL, HDLNG TR (INCLS 2, 6, 7, 33, 34) (TITANIUM) |
D35 (C3U, UAV, U2S, U2T, UE1, 4AL, 4AM) |
2011-2011 |
01 |
| 001 |
22787417 |
PANEL, HDLNG TR (INCLS 2, 6, 7, 33, 34) (CASHMERE) |
D35 (C3U, UAV, U2S, U2T, UE1, 4AC, 4AR) |
2011-2011 |
01 |
| 001 |
20943437 |
PANEL, HDLNG TR (INCLS 2, 6, 7, 33, 34) (TITANIUM) |
DR35 (C3U, U2X, 4AL, 4AM) (EXC UE1) (EXPORT) |
2011-2011 |
01 |
| 001 |
20943438 |
PANEL, HDLNG TR (INCLS 2, 6, 7, 33, 34) (CASHMERE) |
DR35 (C3U, U2X, 4AC) (EXC UE1) (EXPORT) |
2011-2011 |
01 |
| 001 |
20943440 |
PANEL, HDLNG TR (INCLS 2, 6, 7, 33, 34) (TITANIUM) |
DM35 (C3U, UAV, U2R, U2S, U2T, U2Y, UE1, 4AL, 4AM) (EXPORT) |
2011-2011 |
01 |
| 001 |
20943441 |
PANEL, HDLNG TR (INCLS 2, 6, 7, 33, 34) (CASHMERE) |
DM35 (C3U, UAV, U2R, U2S, U2T, U2Y, UE1, 4AC) (EXPORT) |
2011-2011 |
01 |
| 002 |
25884445 |
ANTENNA, IGN LK KEY XMTR (PART OF 1) (PASSIVE ANTENNA W/2 PIN CONN) |
D35 |
2010-2011 |
01 |
| 003 |
20838544 |
BRACKET, CARGO NET FRT |
D35 |
2010-2011 |
01 |
| 003 |
20838545 |
BRACKET, CARGO NET FRT |
D35 |
2010-2011 |
01 |
| 004 |
11588337 |
BOLT, HEX W/FL WA, M6X1X20, 9 THD, 17 OD, 6202M, GMW3200, TAP, DOG PT. (CARGO NET FRT BRKT) |
|
2010-2011 |
02 |
| 005 |
20907106 |
BRACKET, ASST HDL |
D35 |
2010-2011 |
01 |
| 005 |
20907107 |
BRACKET, ASST HDL |
D35 |
2010-2011 |
01 |
| 006 |
15123133 |
RETAINER, HDLNG T/PNL WIRE (PART OF 1) (16.742) |
D35-69 |
2010-2011 |
01 |
| 007 |
20847797 |
RETAINER, HDLNG T/PNL (PUSH IN) (PART OF 1) |
D35 |
2010-2011 |
01 |
| 007 |
20847798 |
RETAINER, HDLNG T/PNL (PUSH IN) (PART OF 1) |
D35 |
2010-2011 |
01 |
| 008 |
11569707 |
RETAINER-PUSHIN, FITS HOLE 6.0, HD OD 18, L=27.4, GMP.PA66.063, DOUBLE HD (HDLNG T/PNL) |
|
2010-2011 |
02 |
| 009 |
11609411 |
NUT, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (CARGO NET BRKT) |
|
2010-2011 |
04 |
| 010 |
20838542 |
BRACKET, CARGO NET RR |
D35 |
2010-2011 |
01 |
| 010 |
20838543 |
BRACKET, CARGO NET RR |
D35 |
2010-2011 |
01 |
| 011 |
20897230 |
PLATE, CARGO NET BRKT TR (CASHMERE) (1 FRT/1 RR) |
DM35 (4AC) |
2011-2011 |
02 |
| 011 |
20897233 |
PLATE, CARGO NET BRKT TR (CASHMERE) (1 FRT/1 RR) |
DM35 (4AC) |
2011-2011 |
02 |
| 021 |
25949119 |
MOLDING, SUN RF PNL/WDO GARN (CASHMERE) |
DM35-69 (C3U, VRK, 4AC) |
2010-2011 |
01 |
| 021 |
25949118 |
MOLDING, SUN RF PNL/WDO GARN (TITANIUM) |
DM35-69 (C3U, VRK, 4AL, 4AM) |
2010-2011 |
01 |
| 021 |
25949118 |
MOLDING, SUN RF PNL/WDO GARN (TITANIUM) |
DR (C3U, VRK, 4AL, 4AM) (EXPORT) |
2010-2011 |
01 |
| 021 |
25949119 |
MOLDING, SUN RF PNL/WDO GARN (CASHMERE) |
DR (C3U, VRK, 4AC) (EXPORT) |
2010-2011 |
01 |
| 022 |
13502343 |
BULB, S/S ILLUM MIR LP (PART OF 25) (8.991) (ACDelco #13502343) |
D35 |
2010-2011 |
04 |
| 023 |
|
LENS, S/S ILLUM MIR (PART OF 25) |
|
2010-2011 |
|
| 024 |
|
CONSOLE, RF (SEE GROUP 10.000 CONSOLE/ROOF FOR DETAILED ILLUSTRATED VIEW) (TITANIUM) |
|
2010-2011 |
|
| 025 |
22761769 |
SUNSHADE, (INCLS 22, 23, 26) (CASHMERE) |
D35-69 (4AC) |
2011-2011 |
01 |
| 025 |
22761765 |
SUNSHADE, (INCLS 22, 23, 26) (TITANIUM) |
D35-69 (4AL, 4AM) |
2011-2011 |
01 |
| 025 |
22761766 |
SUNSHADE, (INCLS 22, 23, 26) (CASHMERE) |
D35-69 (4AC) |
2011-2011 |
01 |
| 025 |
22761768 |
SUNSHADE, (INCLS 22, 23, 26) (TITANIUM) |
D35-69 (4AL, 4AM) |
2011-2011 |
01 |
| 026 |
11610271 |
SCREW, PAN HD, M4.2X1.41X25, 20.5 THD, 8 OD, 6010M, GMW4205, T15 TORX, AB-PT (PART OF 25) |
|
2010-2011 |
06 |
| 027 |
15803473 |
COVER, S/S RET BOLT (CASHMERE) (16.070) |
D35-69 (4AC, 4AR) |
2010-2011 |
02 |
| 027 |
20765441 |
COVER, S/S RET BOLT (TITANIUM) (CIRCULAR S/S BOLT COVER W/HOLE IN CTR) |
D35-69 (4AL, 4AM) |
2010-2011 |
02 |
| 028 |
11610271 |
SCREW, PAN HD, M4.2X1.41X25, 20.5 THD, 8 OD, 6010M, GMW4205, T15 TORX, AB-PT (S/S SUPT) |
|
2010-2011 |
02 |
| 029 |
15877013 |
SUPPORT, S/S (INCLS 30) (TITANIUM) (16.070) |
D35-69 (4AL, 4AM) |
2010-2011 |
02 |
| 029 |
15877014 |
SUPPORT, S/S (INCLS 30) (CASHMERE) (16.070) (TIP PIN RETAINER) |
D35-69 (4AC, 4AR) |
2010-2011 |
02 |
| 030 |
|
COVER, S/S SUPPORT (PART OF 29) |
|
2010-2011 |
|
| 031 |
13502224 |
RETAINER, S/S (TIP PIN) (16.070) |
D35 |
2010-2011 |
01 |
| 031 |
13502225 |
RETAINER, S/S (TIP PIN) (16.070) |
D35 |
2010-2011 |
01 |
| 032 |
11609345 |
NUT, PUSH-IN, 4.2, SAE 1050 STL, GMW3179 (S/S SUPT) |
|
2010-2011 |
02 |
| 033 |
|
PLATE, RF CNSL BKG (PART OF 1) |
|
2010-2011 |
|
| 034 |
|
HARNESS, W/S HDR WRG (PART OF 1) |
|
2010-2011 |
|
