| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
25868417 |
TELLTALE, INFO CTR (HDLNG TR) (ACDelco #25868417) |
D35 (UD7, VRK) |
2010-2011 |
01 |
| 002 |
15291486 |
BEZEL, INFO CTR TELLTALE (CASHMERE) |
D35 (UD7, VRK, 4AC) |
2010-2011 |
01 |
| 002 |
15291487 |
BEZEL, INFO CTR TELLTALE (TITANIUM) |
D35 (UD7, VRK, 4AL, 4AM) |
2010-2011 |
01 |
| 003 |
20928039 |
HARNESS, B/U ALARM WRG |
DM35 (ATG, UD7) |
2010-2011 |
01 |
| 003 |
20928039 |
HARNESS, B/U ALARM WRG |
DN35 (ATG, UD7) |
2011-2011 |
01 |
| 003 |
20928040 |
HARNESS, B/U ALARM WRG |
DM35 (ATH, UD7) |
2010-2011 |
01 |
| 003 |
20928039 |
HARNESS, B/U ALARM WRG |
DR35 (ATG, UD7) (EXPORT) |
2010-2011 |
01 |
| 003 |
20928040 |
HARNESS, B/U ALARM WRG |
DR35 (ATH, UD7) (EXPORT) |
2010-2011 |
01 |
| 004 |
|
HARNESS, BODY WRG (SEE GROUP 13.000 WIRING HARNESS/BODY FOR DETAILED ILLUSTRATED VIEW) |
|
2010-2011 |
|
| 005 |
|
RETAINER, RR OBJECT SEN (PART OF 7) |
|
2010-2011 |
|
| 006 |
15271277 |
BRACKET, RR PARK ASST ALARM SEN (7.831) |
DN |
2011-2011 |
04 |
| 006 |
15271277 |
BRACKET, RR PARK ASST ALARM SEN (7.831) |
DM |
2011-2011 |
04 |
| 006 |
15271277 |
BRACKET, RR PARK ASST ALARM SEN (7.831) |
DR (EXPORT) |
2011-2011 |
04 |
| 007 |
20914917 |
SENSOR KIT, PARK ASST ALARM (INCLS 5) (7.831) |
D35 (UD7) |
2010-2011 |
04 |
| 007 |
19116085 |
SENSOR KIT, PARK ASST ALARM (INCLS 5) (PRIMED) (W/HOUSING) (7.831) |
DN |
2011-2011 |
04 |
| 007 |
19116085 |
SENSOR KIT, PARK ASST ALARM (INCLS 5) (PRIMED) (W/HOUSING) |
DN |
2011-2011 |
04 |
| 007 |
20914917 |
SENSOR KIT, PARK ASST ALARM (INCLS 5) |
D35 (UD7) |
2010-2011 |
04 |
| 008 |
22743052 |
MODULE, RR OBJECT ALARM CONT |
D35 (UD7) |
2011-2011 |
01 |
| 008 |
22743052 |
MODULE, RR OBJECT ALARM CONT |
DR35-69 (UD7) (EXPORT) |
2011-2011 |
01 |
| 009 |
|
HARNESS, W/S HDR WRG (SEE GROUP 14.000 ROOF HEADLINER FOR DETAILED ILLUSTRATED VIEW) |
|
2010-2011 |
|
