| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
15298281 |
VALVE, BRK PRESS MOD (ACDelco #15298281) |
D |
2009-2013 |
01 |
| 002 |
|
INSULATOR, BRK PRESS MOD VLV (*KIT1) |
|
2011-2013 |
|
| 003 |
11514517 |
NUT, HEX, W/CON SPR WA, M6X1, 5.7THK, 18 O.D., 9, 7111M (P/S FLUID RSVR BRKT) |
|
2009-2013 |
02 |
| 004 |
25818513 |
BRACKET, ELEK BRK CONT MDL (INCLS 5) |
DN |
2009-2013 |
01 |
| 005 |
|
INSULATOR, BRK PRESS MOD VLV BRKT (PART OF 4) (*KIT1) |
|
2011-2013 |
|
| 006 |
|
BOLT, ELEK BRK CONT MDL BRKT (*KIT1) |
|
2011-2013 |
|
| 007 |
11570136 |
BOLT, HEX HD, W/CON SPR WA, M6X1X23, 14 THD, 17 O.D., 8.8, GMW3359 (P/S GR INL OTLT PIPE CLIP BRKT) |
|
2009-2013 |
01 |
| 008 |
20803608 |
MODULE, ELEK BRK TRACT CONT (ACDelco #20803608) |
DN |
2009-2013 |
01 |
| 009 |
25854972 |
BOLT, ELEK BRK CONT MDL (ECU TO HCU ATTACH) (M4X0.7X19.5, 10THD) |
D |
2009-2013 |
04 |
| K01 |
15286358 |
INSULATOR KIT, BRK PRESS MOD VLV (INCLS 2, 5, 6) |
D |
2009-2013 |
01 |
