| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
20960678 |
BEZEL, F/FLR CNSL TRANS SHFT OPG (INCLS 2-7) (V-BLACK) |
DN (MYD, 4AL, 4AM, 4AR, 4BZ) |
2010-2012 |
01 |
| 002 |
25801116 |
INDICATOR, A/TRNS CONT (SHFTR TR PLT) (PART OF 1) |
DN (MYD) |
2009-2013 |
01 |
| 003 |
11509231 |
SCREW, RD HD C/R TAP, M4.2X1.41X13.0, GM6010M STL, GM813M NICKEL ORGANIC (PART OF 1) |
|
2009-2013 |
04 |
| 004 |
15935228 |
SWITCH, PARK BRK (PART OF 1) (ACDelco #15935228) |
D |
2009-2012 |
01 |
| 005 |
11561814 |
BOLT, PARK BRK CONT MDL (PART OF 1) (DELTA 30 X 8) (11.927) |
DM, DN |
2011-2012 |
01 |
| 006 |
25803086 |
RETAINER, F/FLR CNSL TRANS SHFT OPG TR PLT (PART OF 1) |
DN (4AL, 4AM, 4AR, 4BZ) |
2010-2012 |
01 |
| 007 |
11610112 |
CLIP, F/FLR CNSL TR PLT (TR PLT TO SI PNL) (PART OF 1) (10.4 X 13 X 9) (14.683) |
D69 |
2009-2013 |
02 |
| 008 |
25961838 |
KNOB, A/TRNS CONT LVR |
DN (MYD, 5AC) |
2010-2013 |
01 |
| 008 |
25961839 |
KNOB, A/TRNS CONT LVR |
DN (MYD) (EXC 5AC) |
2011-2013 |
01 |
| 009 |
11570687 |
BOLT, A/TRNS CONT LVR KNOB |
D |
2010-2013 |
01 |
| 010 |
25824062 |
BOOT, A/TRNS CONT (EBONY) |
DN (MYD) |
2010-2013 |
01 |
| 011 |
11609411 |
NUT, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (A/TRNS RANGE SEL LVR CBL BRKT) |
|
2009-2013 |
04 |
| 012 |
25824054 |
BASE, A/TRNS CONT |
DN (MYD) |
2009-2013 |
01 |
| 013 |
11609411 |
NUT, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (A/TRNS RANGE SEL ROD ADJ) |
|
2009-2013 |
01 |
| 014 |
25947776 |
LINK, A/TRNS RANGE SEL LVR |
DN (MYD, JJB) |
2009-2011 |
01 |
| 015 |
11514603 |
NUT, M10X1.5 15MM SOCKET (A/TRNS RANGE SEL LVR) |
|
2009-2013 |
01 |
