| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
20836831 |
BRACKET, ECM |
DN (LSA) |
2011-2013 |
01 |
| 002 |
12633264 |
MODULE, ENG CONT (W/ 2ND MPU) (W/O CALN) (NO START E67) (ACDelco #12633264) |
DN (LSA) |
2011-2013 |
01 |
| 003 |
|
HARNESS, ENG WRG (SEE GROUP 02.000 WIRING HARNESS/ENGINE FOR DETAILED ILLUSTRATED VIEW) |
|
2009-2013 |
|
| 004 |
11516836 |
NUT, HEX W/CON WA, M6X1, 18.75 O.D., 5.55THK, 9, POR (ECM BRKT) (8.915) |
|
2009-2013 |
02 |
| 005 |
11519375 |
BOLT, HX HD, W/FL WA, M6X1X19, 10 THD, 17 O.D., 8.8, GMW3359 (ECM BRKT) |
|
2009-2013 |
01 |
