| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
25812252 |
SHIELD, F/CMPT FRT SIGHT (INCLS 2, 3, 8) |
DN (LSA) |
2009-2010 |
01 |
| 002 |
15788083 |
PLUG, F/CMPT UPR S/RL ACC HOLE (ЧАСТЬ OF 1) (30.2 X 7.7) (ROUND) (FITS 18.5 DIA HOLE) (12.940)
| D69 (LSA) |
2010-2010 |
02 |
|
| 003 |
25927029 |
EMBLEM, F/END UPR TIE BAR (ЧАСТЬ OF 1) |
DN (LSA) |
2009-2010 |
01 |
| 004 |
15856789 |
SHIELD, F/CMPT SI SIGHT (INCLS 5) (W/ INSULATOR) (REMOVE INSULATING MATERIAL AS NECESSARY)
| DN |
2009-2010 |
01 |
|
| 005 |
19167509 |
INSULATOR, UPR INT MANIF CVR (ЧАСТЬ OF 4) (3.405) |
DN (LSA) |
2010-2010 |
02 |
| 006 |
12591715 |
GROMMET, UPR INT MANIF SIGHT SHLD (ЧАСТЬ OF 7) (32MM OD @ TOP) (ROUND AT TOP/TAPERED CONICAL BOTTOM) |
DN (LSA) |
2010-2010 |
01 |
| 007 |
15856790 |
SHIELD, F/CMPT SI SIGHT (INCLS 6) (W/ INSULATOR) (REMOVE INSULATING MATERIAL AS NECESSARY) |
DN69 |
2009-2010 |
01 |
| 008 |
|
SEAL, RAD AIR UPR (ЧАСТЬ OF 1) |
|
2009-2010 |
|
| 009 |
10382313 |
RETAINER, F/CMPT FRT SIGHT SHLD (025.0X35.6) (PUSH PIN) (8.090)
| D69 |
2009-2010 |
06 |
|
