| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
25996837 |
SENSOR, FRT WHL SPD (INCLS 2, 3, 6) |
DM (MN6, MX0) |
2008-2010 |
02 |
| 001 |
25996837 |
SENSOR, FRT WHL SPD (INCLS 2, 3, 6) |
DN (MN6, MX0) |
2009-2010 |
02 |
| 001 |
25996837 |
SENSOR, FRT WHL SPD (INCLS 2, 3, 6) |
DR (MN6, MX0) (EXPORT) |
2009-2010 |
02 |
| 002 |
15158259 |
CLIP, WHL SPD SEN WIRE (ЧАСТЬ OF 1, 15) (12.0MM HOLE) |
DM |
2008-2010 |
01 |
| 002 |
15158259 |
CLIP, WHL SPD SEN WIRE (ЧАСТЬ OF 1, 15) (12.0MM HOLE) |
DN |
2009-2010 |
01 |
| 002 |
15158259 |
CLIP, WHL SPD SEN WIRE (ЧАСТЬ OF 1, 15) (12.0MM HOLE) |
DR |
2009-2010 |
01 |
| 003 |
15158261 |
CLIP, WHL SPD SEN WIRE (ЧАСТЬ OF 1) (11MM HOLE) |
DM69 |
2008-2010 |
01 |
| 003 |
15158261 |
CLIP, WHL SPD SEN WIRE (ЧАСТЬ OF 1) (11MM HOLE) |
DN69 |
2009-2010 |
01 |
| 003 |
15158261 |
CLIP, WHL SPD SEN WIRE (ЧАСТЬ OF 1) (11MM HOLE) |
DR69 |
2009-2010 |
01 |
| 004 |
|
HARNESS, ENG WRG (СМ. ГРУППУ 02.000 ЖГУТЫ ПРОВОДОВ/ДВИГАТЕЛЬ ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2008-2010 |
|
| 005 |
|
VALVE, BRK PRESS MOD (W/ELEK BRK TRACT CONT MDL) (СМ. ГРУППУ 04.000 BRAKE CONTROL МОДУЛЬ ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2008-2010 |
|
| 006 |
15715954 |
CLIP, WHL SPD SEN WIRE (ЧАСТЬ OF 1) (TREE FITS 6.5 HOLE) (HOLDS (1) 10.5MM GROMMET ROUTING (1) 6.35 SPD SEN CBL) |
DM |
2008-2010 |
03 |
| 006 |
15715954 |
CLIP, WHL SPD SEN WIRE (ЧАСТЬ OF 1) (TREE FITS 6.5 HOLE) (HOLDS (1) 10.5MM GROMMET ROUTING (1) 6.35 SPD SEN CBL) |
DN |
2009-2010 |
03 |
| 006 |
15715954 |
CLIP, WHL SPD SEN WIRE (ЧАСТЬ OF 1) (TREE FITS 6.5 HOLE) (HOLDS (1) 10.5MM GROMMET ROUTING (1) 6.35 SPD SEN CBL) |
DR |
2009-2010 |
03 |
| 007 |
11516521 |
БОЛТ, HFH M6X1X20, 9.8, 7114M, DOG PT, 14.2 OD (FRT WHL SPD SEN) |
|
2008-2010 |
02 |
| 008 |
03530297 |
ГАЙКА, HFH, M6X1, 5.85THK, 14.2 O.D., 10, ZOR (VEH YAW SEN LATL ACCLRM) |
|
2008-2010 |
02 |
| 009 |
11609989 |
БОЛТ, HEX W/FLAT WASHER, M6X1X25, 15 THD, 17 OD, 6202M STL, GMW3200, TAPTITE (VEH YAW SEN LATL ACCLRM)
|
2008-2010 |
01 |
|
| 010 |
|
HARNESS, BODY WRG (СМ. ГРУППУ 02.000 ЖГУТЫ ПРОВОДОВ/КУЗОВ ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) |
|
2008-2010 |
|
| 011 |
15845467 |
SENSOR, VEH YAW (W/VEH LATL ACCLRM) (LABELED 15845467)
| DM, DN |
2010-2010 |
01 |
|
| 011 |
15845467 |
SENSOR, VEH YAW (W/VEH LATL ACCLRM) (LABELED 15845467)
| DR (EXPORT) |
2010-2010 |
01 |
|
| 011 |
20866679 |
SENSOR, VEH YAW (W/VEH LATL ACCLRM) |
DM35-69 (NOT YET AVAILABLE) |
2010-2010 |
01 |
| 011 |
20866679 |
SENSOR, VEH YAW (W/VEH LATL ACCLRM) |
DN69 (NOT YET AVAILABLE) |
2010-2010 |
01 |
| 011 |
20866679 |
SENSOR, VEH YAW (W/VEH LATL ACCLRM) |
DR35-69 (NOT YET AVAILABLE) (EXPORT) |
2010-2010 |
01 |
| 012 |
25866179 |
SENSOR, RR WHL SPD (INCLS 14) |
D69 |
2008-2010 |
02 |
| 013 |
11516521 |
БОЛТ, HFH M6X1X20, 9.8, 7114M, DOG PT, 14.2 OD (RR WHL SPD SEN) |
|
2008-2010 |
02 |
| 014 |
10317605 |
CLIP, WHL SPD SEN WIRE (ЧАСТЬ OF 12) (6.8MM HOLE) (9.242)
| DM |
2008-2010 |
03 |
|
| 014 |
10317605 |
CLIP, WHL SPD SEN WIRE (ЧАСТЬ OF 12) (6.8MM HOLE) (9.242)
| DN |
2009-2010 |
03 |
|
| 014 |
10317605 |
CLIP, WHL SPD SEN WIRE (ЧАСТЬ OF 12) (6.8MM HOLE) (9.242)
| DR |
2009-2010 |
03 |
|
| 015 |
15855539 |
SENSOR, FRT WHL SPD (INCLS 2, 16, 17) |
DM (MX7) |
2008-2010 |
02 |
| 016 |
10317605 |
CLIP, WHL SPD SEN WIRE (ЧАСТЬ OF 15) (6.8MM HOLE) (9.242)
| DM |
2008-2010 |
04 |
|
| 016 |
10317605 |
CLIP, WHL SPD SEN WIRE (ЧАСТЬ OF 15) (6.8MM HOLE) (9.242)
| DN |
2009-2010 |
03 |
|
| 016 |
10317605 |
CLIP, WHL SPD SEN WIRE (ЧАСТЬ OF 15) (6.8MM HOLE) (9.242)
| DR |
2009-2010 |
03 |
|
| 017 |
|
BRACKET, FRT WHL SPD SEN WIRE (ЧАСТЬ OF 15) |
|
2008-2010 |
|
| 017 |
25820819 |
BRACKET, FRT WHL SPD SEN WIRE (ЧАСТЬ OF 15) |
DM (MX7) |
2008-2010 |
02 |
| 018 |
11570352 |
ГАЙКА, HEX JAM M12X1.75X6, GM510 (5) STL, GMW14100. (WHL SPD SEN BRKT) |
|
2008-2010 |
02 |
