| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 003 |
89058852 |
БОЛТ, CLU ACTR (M6X1.0X20) |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 004 |
89048559 |
БОЛТ, CLU ACTR (M8X1.25X20) (4.104) |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
03 |
| 007 |
89058759 |
CASE, TRANS INTER (INCLS 8, 9) |
DM (MV7) |
2008-2010 |
01 |
| 009 |
89058791 |
PIN, TRANS INTER CASE LOC (ЧАСТЬ OF 7) |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
02 |
| 011 |
19178542 |
CASE, TRANS FRT (INCLS 12-16) |
DM (MV7) |
2008-2010 |
01 |
| 012 |
89058833 |
SEAL, MAIN SHF (ЧАСТЬ OF 11) |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 013 |
|
SHIELD, INPUT SHF BRG OIL (ЧАСТЬ OF 11) |
|
2008-2010 |
|
| 014 |
89058791 |
PIN, TRANS INTER CASE LOC (ЧАСТЬ OF 11) |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
02 |
| 015 |
89059311 |
PIN, TRANS CASE LOC (ЧАСТЬ OF 11) |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
02 |
| 016 |
89059312 |
PLUG, TRANS CASE HOLE (ЧАСТЬ OF 11) |
DM (MV7) |
2008-2010 |
01 |
| 017 |
|
TROUGH, TRANS RR CASE OIL |
|
2008-2010 |
|
| 018 |
89058837 |
SLINGER, INPUT SHF BRG OIL (FRONT) |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 019 |
89058839 |
TROUGH, M/TRNS OIL |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 020 |
89058840 |
TROUGH, TRANS INTER CASE OIL |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 021 |
|
RETAINER, CNTR GR BRG |
|
2008-2010 |
|
| 021 |
89058820 |
RETAINER, CNTR GR BRG (4.352) |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 023 |
89058760 |
CASE, TRANS RR (INCLS 24-26) |
DM (MV7) |
2008-2010 |
01 |
| 024 |
|
BUSHING, SHFT SHF (ЧАСТЬ OF 23) |
|
2008-2010 |
|
| 025 |
89058774 |
BEARING, SHFT SHF (ЧАСТЬ OF 23) |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 026 |
89058791 |
PIN, TRANS INTER CASE LOC (ЧАСТЬ OF 23) |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
02 |
| 027 |
89058853 |
БОЛТ, TRANS INTER CASE (M10X1.25X40) (4.104) |
DM (MV7) |
2008-2010 |
06 |
| 028 |
89058854 |
БОЛТ, TRANS INTER CASE (M10X1.25X80) (4.104) |
DM (MV7) |
2008-2010 |
05 |
| 029 |
89059319 |
GASKET, TRANS RR CASE |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 030 |
89058843 |
PLUG, CLU HSG HOLE |
DM (MV7) |
2008-2010 |
01 |
| 031 |
89059313 |
VENT, M/TRNS |
DM (MV7) |
2010-2010 |
01 |
| 033 |
89048245 |
GASKET, TRANS OIL DRN PLUG (ACDelco #89048245) |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 035 |
89059315 |
БОЛТ, REV IDLER GR SHF RET |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 036 |
19132971 |
PLUG, SHFT SHF DTNT |
DM (MV7) |
2008-2010 |
01 |
| 038 |
19132970 |
БОЛТ, CNTR GR BRG RET (4.307) |
DM (MV7) |
2010-2010 |
01 |
| 068 |
89058860 |
DETENT, SHFT SHF |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 068 |
89059329 |
DETENT, SHFT SHF (CAM) |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 075 |
92195066 |
ПРУЖИНА, SHFT SHF DTNT |
DM (LF1, LLT, MV7, JJB) |
2009-2010 |
01 |
| 086 |
19178541 |
EXTENSION, TRANS (INCLS 87, 88) |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 087 |
89058838 |
SLINGER, INPUT SHF BRG OIL (ЗАДНИЙ) (ЧАСТЬ OF 86) |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 088 |
19180996 |
SEAL, SHFT CONT SHF (ЧАСТЬ OF 86) |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 092 |
89058835 |
SEAL, RR ВЫХОДНОЙ SHF |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 108 |
19178540 |
FLANGE, TRANS PROP SHF |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 126 |
19132973 |
ГАЙКА, PROP SHF TRANS FLG |
DM (LF1, LLT, MV7) |
2010-2010 |
01 |
| 136 |
89058775 |
BEARING, REV IDLER GR |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 193 |
89058836 |
SEAL, PROP SHF TRANS FLG FLUID |
DM (MV7) |
2010-2010 |
01 |
| 204 |
89058790 |
SHAFT, REV IDLER GR |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 205 |
89058789 |
GEAR, REV IDLER |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 209 |
89059318 |
RETAINER, B/U LP SW |
DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
| 213 |
89058851 |
SENSOR, M/TRNS ВЫХОДНОЙ SPD (4.337) |
DM (MV7) |
2010-2010 |
01 |
| 213 |
89058851 |
SENSOR, M/TRNS ВЫХОДНОЙ SPD |
DM (MV7) |
2010-2010 |
01 |
| 900 |
24242161 |
CYLINDER, CLU ACTR
| DM (LF1, LLT, MV7, JJB) |
2010-2010 |
01 |
|
