| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
25925125 |
INSULATOR, FLR PNL R/SEAT |
D69 |
2009-2009 |
01 |
| 002 |
10376174 |
BARRIER, RR W/H INR PNL UPR SND |
D69 |
2009-2009 |
02 |
| 003 |
|
DEADENER, R/CMPT FLR PNL |
|
2009-2009 |
|
| 004 |
25757810 |
DEADENER, R/CMPT FLR PNL (390X150) (W/O HOLE) (RECTANGULAR IN SHAPE) (12.980) |
D69 |
2009-2009 |
03 |
| 005 |
|
SEAL, R/END PNL |
|
2009-2009 |
|
| 006 |
|
TAPE, QTR OTR PNL FIL |
|
2009-2009 |
|
| 007 |
11515174 |
SEALING STRIP, FLR PNL DRN HOLE CVR (4 1/4 X 7 1/2) (TRIM AS REQD) (12.941) |
D69 |
2009-2009 |
02 |
| 008 |
|
DEADENER, FLR PNL RR |
|
2009-2009 |
|
| 009 |
25757810 |
DEADENER, FLR PNL TUN FRT (390X150) (W/O HOLE) (RECTANGULAR IN SHAPE) |
D69 |
2009-2009 |
04 |
| 010 |
25784232 |
INSULATOR, EXH H/SHLD (INCLS 11) (RWD) (12.980) |
D69 (MYB, MX0) |
2009-2009 |
01 |
| 010 |
25805178 |
INSULATOR, EXH H/SHLD (INCLS 11) |
D69 (MN6) |
2009-2009 |
01 |
| 010 |
25964067 |
INSULATOR, EXH H/SHLD (INCLS 11)
| D69 (MYB, MX7) |
2009-2009 |
01 |
|
| 010 |
25964067 |
INSULATOR, EXH H/SHLD (INCLS 11)
| DN69 |
2009-2009 |
01 |
|
| 011 |
11570585 |
ГАЙКА, EXH H/SHLD (ЧАСТЬ OF 10) |
D |
2009-2009 |
04 |
| 012 |
15250712 |
BARRIER, F/FLR PNL F/FLR CNSL SND (RWD) |
DM69 (MV7, MN6) |
2009-2009 |
01 |
| 012 |
15250712 |
BARRIER, F/FLR PNL F/FLR CNSL SND (RWD) |
DM69 (MYB, MX0) |
2009-2009 |
01 |
| 012 |
15250712 |
BARRIER, F/FLR PNL F/FLR CNSL SND (RWD) |
DR69 (MV7, MN6) (EXPORT) |
2009-2009 |
01 |
| 012 |
15250712 |
BARRIER, F/FLR PNL F/FLR CNSL SND (RWD) |
DR69 (MYB, MX0) (EXPORT) |
2009-2009 |
01 |
| 012 |
15263003 |
BARRIER, F/FLR PNL F/FLR CNSL SND (AWD) |
D69 (MYB, MX7) |
2009-2009 |
01 |
| 012 |
15263003 |
BARRIER, F/FLR PNL F/FLR CNSL SND (AWD) |
DM69 |
2009-2009 |
01 |
| 012 |
20765440 |
BARRIER, F/FLR PNL F/FLR CNSL SND (AWD) |
DN69 |
2009-2009 |
01 |
| 013 |
|
DEADENER, FLR PNL FRT |
|
2009-2009 |
|
| 014 |
25722024 |
BARRIER, DA PNL INTR SND (1 LH SI OF TUNNEL) (1 RH SI - PASS THRU DR) (TWO PIECE) |
D |
2009-2009 |
AR |
| 015 |
25757810 |
DEADENER, FLR PNL RR (390X150) (W/O HOLE) (RECTANGULAR IN SHAPE) |
D69 |
2009-2009 |
01 |
| 016 |
|
DEADENER, DA PNL |
|
2009-2009 |
|
| 017 |
25872977 |
SEALING STRIP, BODY H/PLR INR PNL (TO PLNM PNL) |
D69 |
2009-2009 |
01 |
| 017 |
25872978 |
SEALING STRIP, BODY H/PLR INR PNL (TO PLNM PNL) |
D69 |
2009-2009 |
01 |
| 018 |
15250701 |
BARRIER, DA PNL INTR SND (BUILT 05/19/08 PRIOR) (FOR 2ND DES SEE 25991497) |
DR (1ST DES) (EXPORT) |
2009-2009 |
01 |
| 018 |
25883757 |
BARRIER, DA PNL INTR SND |
DM |
2009-2009 |
01 |
| 018 |
25883757 |
BARRIER, DA PNL INTR SND |
DN |
2009-2009 |
01 |
| 018 |
25991497 |
BARRIER, DA PNL INTR SND (BUILT AFTER 05/19/08) (FOR 1ST DES SEE 15250701) |
DR (2ND DES) (EXPORT) |
2009-2009 |
01 |
| 019 |
20064875 |
RETAINER, PUSH-IN, 20.5MMLG, 42.76MM 1.68HD DIA, PLASTIC (DA PNL INTR SND BARR (PUSH IN))
|
2009-2009 |
02 |
|
| 020 |
10009923 |
ГАЙКА, БОЛТ RETAINING ПРУЖИНА, M8X1.25, 25 O.D., ZOR (DA PNL INTR SND BARR (PUSH IN)) |
|
2009-2009 |
04 |
| 021 |
25904719 |
BARRIER, RR W/H INR PNL SND |
D69 |
2009-2009 |
01 |
| 021 |
25904720 |
BARRIER, RR W/H INR PNL SND |
D69 |
2009-2009 |
01 |
| 022 |
25757810 |
DEADENER, FLR PNL R/SEAT (390X150) (W/O HOLE) (RECTANGULAR IN SHAPE) |
D69 |
2009-2009 |
03 |
