| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
20819982 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (EBONY) (USED ON VEHICLES BUILT W/ TWO RECRG AIR BUTTONS OR ONE BLANK BUTTON T/W ONE RECRG AIR BUTTON ON CONTROL. 1ST DES SEE 25835206.) |
DN69 (KA1, UAV, U2X, U2Y, 19I, 31I, 84I) (2ND DES) |
2009-2009 |
01 |
| 001 |
20819983 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (EBONY) (USED ON VEHICLES BUILT W/ TWO RECRG AIR BUTTONS OR ONE BLANK BUTTON T/W ONE RECRG AIR BUTTON ON CONTROL. 1ST DES SEE 25835212.) |
DN69 (KB6, UAV, U2X, U2Y, 19I, 31I, 84I) (2ND DES) |
2009-2009 |
01 |
| 001 |
25835206 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (EBONY) (ACDelco #25835206) (USED ON VEHICLES BUILT W/ HTD RR WDO WASHER FLUID BUTTON ON CONTROL. 2ND DES SEE 20819982.) |
DN69 (KA1, UAV, U2X, U2Y, 19I, 31I, 84I) (1ST DES) |
2009-2009 |
01 |
| 001 |
25835212 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (EBONY) (ACDelco #25835212) (USED ON VEHICLES BUILT W/ HTD RR WDO WASHER FLUID BUTTON ON CONTROL. 2ND DES SEE 20819983.) |
DN69 (KB6, UAV, U2X, U2Y, 19I, 31I, 84I) (1ST DES) |
2009-2009 |
01 |
| 001 |
25837737 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (EBONY) (ACDelco #25837737) (USED ON VEHICLES BUILT W/ HTD RR WDO WASHER FLUID BUTTON ON CONTROL. 2ND DES SEE 25947720.) |
DM69 (KA1, UAV, U2X, U2Y, 19I) (1ST DES) |
2009-2009 |
01 |
| 001 |
25837737 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (EBONY) (ACDelco #25837737) (USED ON VEHICLES BUILT W/ HTD RR WDO WASHER FLUID BUTTON ON CONTROL. 2ND DES SEE 25947720.) |
DR (KA1, UAV, U2X, U2Y, 19I) (1ST DES) (EXPORT) |
2009-2009 |
01 |
| 001 |
25895256 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (LT TITANIUM) (ACDelco #25895256) (USED ON VEHICLES BUILT W/ HTD RR WDO WASHER FLUID BUTTON ON CONTROL. 2ND DES SEE 25947721.) |
DM69 (UAV, U2X, U2Y, 84I) (1ST DES) |
2009-2009 |
01 |
| 001 |
25895256 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (LT TITANIUM) (ACDelco #25895256) (USED ON VEHICLES BUILT W/ HTD RR WDO WASHER FLUID BUTTON ON CONTROL. 2ND DES SEE 25947721.) |
DR69 (UAV, U2X, U2Y, 84I) (1ST DES) (EXPORT) |
2009-2009 |
01 |
| 001 |
25895260 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (LT TITANIUM) (ACDelco #25895260) (USED ON VEHICLES BUILT W/ HTD RR WDO WASHER FLUID BUTTON ON CONTROL. 2ND DES SEE 25947725.) |
DM69 (KB6, UAV, U2X, U2Y, 84I) (1ST DES) |
2009-2009 |
01 |
| 001 |
25895260 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (LT TITANIUM) (ACDelco #25895260) (USED ON VEHICLES BUILT W/ HTD RR WDO WASHER FLUID BUTTON ON CONTROL. 2ND DES SEE 25947725.) |
DR69 (KB6, UAV, U2X, U2Y, 84I) (1ST DES) (EXPORT) |
2009-2009 |
01 |
| 001 |
25947720 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (EBONY) (USED ON VEHICLES BUILT W/ TWO RECRG AIR BUTTONS OR ONE BLANK BUTTON T/W ONE RECRG AIR BUTTON ON CONTROL. 1ST DES SEE 25960567.) |
DM (KA1, UAV, U2X, U2Y, 19I) (2ND DES) |
2009-2009 |
01 |
| 001 |
25947720 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (EBONY) (USED ON VEHICLES W/VIN 1G6DV57V390135393 AFTER1ST DES SEE 25960567) |
DR (KA1, UAV, U2X, U2Y, 19I) (2ND DES) (EXPORT) |
2009-2009 |
01 |
| 001 |
25947721 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (LT TITANIUM) (USED ON VEHICLES BUILT W/ TWO RECRG AIR BUTTONS OR ONE BLANK BUTTON T/W ONE RECRG AIR BUTTON ON CONTROL. 1ST DES SEE 25895256.) |
DM69 (UAV, U2X, U2Y, 84I) (2ND DES) |
2009-2009 |
01 |
| 001 |
25947721 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (LT TITANIUM) (USED ON VEHICLES BUILT W/ TWO RECRG AIR BUTTONS OR ONE BLANK BUTTON T/W ONE RECRG AIR BUTTON ON CONTROL. 1ST DES SEE 25895256.) |
DR69 (UAV, U2X, U2Y, 84I) (2ND DES) (EXPORT) |
2009-2009 |
01 |
| 001 |
25947722 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (LT CASHMERE) (USED ON VEHICLES BUILT W/ TWO RECRG AIR BUTTONS OR ONE BLANK BUTTON T/W ONE RECRG AIR BUTTON ON CONTROL. 1ST DES SEE 25960568.) |
DM (KA1, UAV, U2X, U2Y, 39I) (2ND DES) |
2009-2009 |
01 |
| 001 |
25947722 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (LT CASHMERE) (USED ON VEHICLES BUILT W/ TWO RECRG AIR BUTTONS OR ONE BLANK BUTTON T/W ONE RECRG AIR BUTTON ON CONTROL. 1ST DES SEE 25960568.) |
DR (KA1, UAV, U2X, U2Y, 39I) (2ND DES) (EXPORT) |
2009-2009 |
01 |
| 001 |
25947724 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (EBONY) (USED ON VEHICLES BUILT W/ TWO RECRG AIR BUTTONS OR ONE BLANK BUTTON T/W ONE RECRG AIR BUTTON ON CONTROL. 1ST DES SEE 25960569.) |
DM (KB6, UAV, U2X, U2Y, 19I) (2ND DES) |
2009-2009 |
01 |
| 001 |
25947724 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (EBONY) (USED ON VEHICLES BUILT W/ TWO RECRG AIR BUTTONS OR ONE BLANK BUTTON T/W ONE RECRG AIR BUTTON ON CONTROL. 1ST DES SEE 25960569.) |
DR (KB6, UAV, U2X, U2Y, 19I) (2ND DES) (EXPORT) |
2009-2009 |
01 |
| 001 |
25947725 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (LT TITANIUM) (USED ON VEHICLES BUILT W/ TWO RECRG AIR BUTTONS OR ONE BLANK BUTTON T/W ONE RECRG AIR BUTTON ON CONTROL. 1ST DES SEE 25895260.) |
DM69 (KB6, UAV, U2X, U2Y, 84I) (2ND DES) |
2009-2009 |
01 |
| 001 |
25947725 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (LT TITANIUM) (USED ON VEHICLES BUILT W/ TWO RECRG AIR BUTTONS OR ONE BLANK BUTTON T/W ONE RECRG AIR BUTTON ON CONTROL. 1ST DES SEE 25895260.) |
DR69 (KB6, UAV, U2X, U2Y, 84I) (2ND DES) (EXPORT) |
2009-2009 |
01 |
| 001 |
25947726 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (LT CASHMERE) (USED ON VEHICLES BUILT W/ TWO RECRG AIR BUTTONS OR ONE BLANK BUTTON T/W ONE RECRG AIR BUTTON ON CONTROL. 1ST DES SEE 25960570.) |
DM (KB6, UAV, U2X, U2Y, 39I) (2ND DES) |
2009-2009 |
01 |
| 001 |
25947726 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (LT CASHMERE) (USED ON VEHICLES BUILT W/ TWO RECRG AIR BUTTONS OR ONE BLANK BUTTON T/W ONE RECRG AIR BUTTON ON CONTROL. 1ST DES SEE 25960570.) |
DR (KB6, UAV, U2X, U2Y, 39I) (2ND DES) (EXPORT) |
2009-2009 |
01 |
| 001 |
25960568 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (CASHMERE) (ACDelco #25960568) (USED ON VEHICLES BUILT W/ HTD RR WDO WASHER FLUID BUTTON ON CONTROL. 2ND DES SEE 25947722.) |
DM (KA1, UAV, U2X, U2Y, 39I) (1ST DES) |
2009-2009 |
01 |
| 001 |
25960568 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (CASHMERE) (ACDelco #25960568) (USED ON VEHICLES BUILT W/ HTD RR WDO WASHER FLUID BUTTON ON CONTROL. 2ND DES SEE 25947722.) |
DR (KA1, UAV, U2X, U2Y, 39I) (1ST DES) (EXPORT) |
2009-2009 |
01 |
| 001 |
25960569 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (EBONY) (ACDelco #25960569) (USED ON VEHICLES BUILT W/ HTD RR WDO WASHER FLUID BUTTON ON CONTROL. 2ND DES SEE 25947724.) |
DM (KB6, UAV, U2X, U2Y, 19I) (1ST DES) |
2009-2009 |
01 |
| 001 |
25960569 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (EBONY) (ACDelco #25960569) (USED ON VEHICLES BUILT W/ HTD RR WDO WASHER FLUID BUTTON ON CONTROL. 2ND DES SEE 25947724.) |
DR (KB6, UAV, U2X, U2Y, 19I) (1ST DES) (EXPORT) |
2009-2009 |
01 |
| 001 |
25960570 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (CASHMERE) (ACDelco #25960570) (USED ON VEHICLES BUILT W/ HTD RR WDO WASHER FLUID BUTTON ON CONTROL. 2ND DES SEE 25947726.)
| DM (KB6, UAV, U2X, U2Y, 39I) (1ST DES) |
2009-2009 |
01 |
|
| 001 |
25960570 |
CONTROL, AM/FM STEREO CLK CD PLYR RDO (INCLS 2-9, 14-16, 20) (CASHMERE) (ACDelco #25960570) (USED ON VEHICLES BUILT W/ HTD RR WDO WASHER FLUID BUTTON ON CONTROL. 2ND DES SEE 25947726.)
| DR (KB6, UAV, U2X, U2Y, 39I) (1ST DES) (EXPORT) |
2009-2009 |
01 |
|
| 002 |
|
RETAINER, I/P ACSRY TR PLT (ЧАСТЬ OF 1) |
|
2008-2010 |
|
| 003 |
|
БОЛТ, I/P ACSRY MT PLT (ЧАСТЬ OF 1) |
|
2009-2010 |
|
| 004 |
|
PLATE, I/P ACSRY LWR TR (ЧАСТЬ OF 1) |
|
2009-2010 |
|
| 005 |
|
DISPLAY, DRVR INFO (ЧАСТЬ OF 1) |
|
2009-2010 |
|
| 006 |
|
PLATE, I/P ACSRY UPR TR (ЧАСТЬ OF 1) |
|
2009-2010 |
|
| 007 |
|
CONTROL, HTR КОНДИЦИОНЕР (ЧАСТЬ OF 1) |
|
2009-2010 |
|
| 008 |
|
БОЛТ, I/P ACSRY MT PLT (ЧАСТЬ OF 1) |
|
2009-2010 |
|
| 009 |
|
CONTROL, AM/FM STEREO T/PLYR CD PLYR RDO (ЧАСТЬ OF 1) |
|
2009-2010 |
|
| 010 |
11589015 |
БОЛТ, HWH W/FL WA M4.2X1.41X20, 12.5 O.D., DOG PT, 6010M, 7253M (RDO CONT)
|
2008-2010 |
02 |
|
| 011 |
11589015 |
БОЛТ, HWH W/FL WA M4.2X1.41X20, 12.5 O.D., DOG PT, 6010M, 7253M (VIDEO DISPLAY)
|
2008-2010 |
03 |
|
| 012 |
|
DISPLAY, RDO VIDEO AUDIO DISC PLYR NAVN INFO |
|
2009-2010 |
|
| 013 |
|
ACTUATOR, RDO VIDEO AUDIO DISC PLYR NAVN INFO DISPLAY |
|
2008-2010 |
|
| 014 |
|
CONTROL, PASS TEMP (ЧАСТЬ OF 1) |
|
2009-2010 |
|
| 015 |
|
CONTROL, TEMP (ЧАСТЬ OF 1) |
|
2009-2010 |
|
| 016 |
|
БОЛТ, I/P ACSRY MT PLT (ЧАСТЬ OF 1) |
|
2009-2010 |
|
| 017 |
15862570 |
COVER, NAVN INFO DISPLAY OPG (EBONY) |
DM69 (UAV, U2X, U2Y, 19I, 84I) |
2009-2009 |
01 |
| 017 |
15862570 |
COVER, NAVN INFO DISPLAY OPG (EBONY) |
DN69 (UAV, U2X, U2Y, 19I, 31I, 84I) |
2009-2009 |
01 |
| 017 |
15862570 |
COVER, NAVN INFO DISPLAY OPG (EBONY) |
DR69 (UAV, U2X, U2Y, 19I, 84I) (EXPORT) |
2009-2009 |
01 |
| 017 |
15862571 |
COVER, NAVN INFO DISPLAY OPG (CASHMERE) |
DM69 (UAV, U2X, U2Y, 39I) |
2009-2009 |
01 |
| 017 |
15862571 |
COVER, NAVN INFO DISPLAY OPG (CASHMERE) |
DR69 (UAV, U2X, U2Y, 39I) (EXPORT) |
2009-2009 |
01 |
| 018 |
11570587 |
БОЛТ, I/P CTR COMPT (D 30 X 1.12 X 10) (ATTACH ICS COMPT ASM TO IP LWR) |
D69 |
2008-2010 |
04 |
| 019 |
25941152 |
COMPARTMENT, I/P CTR (СМ. ГРУППУ 10.000 ПРИБОРНАЯ ПАНЕЛЬ TRIM ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) (STAINLESS SILVER)
| DM (19I, 39I, 84I, 89I) |
2008-2009 |
01 |
|
| 019 |
25941152 |
COMPARTMENT, I/P CTR (СМ. ГРУППУ 10.000 ПРИБОРНАЯ ПАНЕЛЬ TRIM ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) (STAINLESS SILVER)
| DR (19I, 39I, 84I) (EXPORT) |
2009-2009 |
01 |
|
| 019 |
25941153 |
COMPARTMENT, I/P CTR (СМ. ГРУППУ 10.000 ПРИБОРНАЯ ПАНЕЛЬ TRIM ДЛЯ ДЕТАЛЬНОГО ПРОСМОТРА) (BLACK) |
DN (19I, 31I, 84I) |
2009-2009 |
01 |
| 020 |
|
ШЛАНГИ, AUDIO DISC PLYR (ЧАСТЬ OF 1) |
|
2009-2010 |
|
