| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 100 |
|
BLOCK, ENG (MCHG) |
|
2008-2009 |
|
| 110 |
|
CAP, CR/SHF BRG |
|
2008-2009 |
|
| 114 |
12560272 |
|
D (LY7) |
2008-2009 |
10 |
| 115 |
11518861 |
|
|
2008-2009 |
08 |
| 116 |
11609410 |
|
|
2008-2009 |
04 |
| 117 |
11589000 |
|
|
2008-2009 |
04 |
| 119 |
12557520 |
PLUG, ENG BLK OIL GAL (CUP-.390IN OD, .040IN THK, STEEL) |
D (LY7) |
2008-2009 |
01 |
| 120 |
12621351 |
CRANKSHAFT,
| D (LY7) |
2008-2009 |
01 |
|
| 121 |
12601937 |
KEY, CR/SHF BALR |
D (LY7) |
2008-2009 |
01 |
| 122 |
|
BEARING, CR/SHF UPR (*KIT1) |
|
2008-2009 |
|
| 123 |
|
BEARING, CR/SHF LWR (*KIT1, KIT2) |
|
2008-2009 |
|
| 124 |
|
BEARING, CR/SHF THR (*KIT2) |
|
2008-2009 |
|
| 126 |
11562127 |
PLUG, ENG BLK OIL GAL (CUP-14.22 OD, 6.6 THK, 304SS) (0.253) |
D (LY7) |
2008-2009 |
01 |
| 127 |
11561583 |
PLUG, ENG BLK OIL GAL (M14X1.5X16, 22 OD) (0.253) |
D (LY7) |
2008-2009 |
04 |
| 129 |
11561751 |
PLUG, CYL HD WAT JKT HOLE (M20X1.5X30.5) (1.531) |
D (LY7) |
2008-2009 |
02 |
| 130 |
11562127 |
PLUG, ENG BLK CORE HOLE (CUP-14.22 OD, 6.6 THK, 304SS) (0.253) |
D (LY7) |
2009-2009 |
01 |
| 130 |
11569584 |
PLUG, ENG BLK CORE HOLE (CUP DIA 34.4MM) |
D (LY7) |
2008-2009 |
02 |
| 131 |
12597210 |
PIN, TRANS LOC |
DM (MV7) |
2008-2009 |
02 |
| 133 |
12620955 |
SEAL, CR/SHF RR OIL
| D (LY7) |
2008-2009 |
01 |
|
| 134 |
11588712 |
|
|
2008-2009 |
05 |
| 135 |
22531637 |
PIN, |
D (LY7) |
2008-2009 |
02 |
| 137 |
12570326 |
PIN, CYL HD LOC
| D (LY7) |
2008-2009 |
04 |
|
| 140 |
12603197 |
PLATE, A/TRNS FLEX |
D (LY7) |
2008-2009 |
01 |
| 141 |
11518862 |
|
|
2008-2009 |
08 |
| 200 |
12608432 |
ROD, CONN (INCLS 201, 202) |
D (LY7) |
2008-2009 |
06 |
| 201 |
11519680 |
|
D (LY7) |
2008-2009 |
12 |
| 202 |
|
BUSHING, CONN ROD ( |
|
2008-2009 |
|
| 203 |
|
BEARING, CONN ROD (UPPER) (*KIT4) |
|
2008-2009 |
|
| 204 |
|
BEARING, CONN ROD (LOWER) (*KIT4) |
|
2008-2009 |
|
| 210 |
12585675 |
PISTON, (W/PIN) (INCLS 211, 212) (.25 O.S.) |
D (LY7) |
2008-2009 |
06 |
| 210 |
12590866 |
PISTON, (W/PIN) (INCLS 211, 212) (STD) |
D (LY7) |
2008-2009 |
06 |
| 211 |
|
PIN, PSTN ( |
|
2008-2009 |
|
| 212 |
12566186 |
RETAINER, PSTN PIN ( |
D (LY7) |
2008-2009 |
12 |
| 213 |
|
RING, PSTN CMPRN UPR (*KIT3) |
|
2008-2009 |
|
| 214 |
|
RING, PSTN CMPRN LWR (*KIT3) |
|
2008-2009 |
|
| 215 |
|
RAIL, PSTN OIL RING (*KIT3) |
|
2008-2009 |
|
| 216 |
|
SPACER, PSTN OIL RING RL (*KIT3) |
|
2008-2009 |
|
| 390 |
12603180 |
BALANCER, CR/SHF (DUAL BELT)
| D (LY7) |
2008-2009 |
01 |
|
| 391 |
11569873 |
|
D (LY7) |
2008-2009 |
01 |
| 490 |
12610143 |
NOZZLE, PSTN OIL |
D (LY7) |
2008-2009 |
03 |
| 491 |
11588712 |
|
|
2008-2009 |
03 |
| 720 |
12613030 |
SENSOR, CR/SHF POSN (INCLS 721, 722)
| DM (LP1, LY7, MYB, MX0, MV1) |
2009-2009 |
01 |
|
| 721 |
|
SEAL, CR/SHF POSN SEN (O RING) ( |
|
2008-2009 |
|
| 722 |
11562426 |
|
|
2008-2009 |
01 |
| 723 |
12605738 |
SENSOR, KNOCK (INCLS 724) (ACDelco #213-4404) |
D (LY7) |
2009-2009 |
02 |
| 724 |
11589313 |
|
|
2008-2009 |
01 |
| 850 |
|
PLATE, CLU PRESS ( |
|
2008-2009 |
|
| 851 |
11570903 |
|
|
2008-2009 |
06 |
| 852 |
|
PLATE, CLU DRVN ( |
|
2008-2009 |
|
| 900 |
24243879 |
PLATE, CLU PRESS DRVN (W/CVR) (INCLS 850, 852) |
DM (MV7) |
2008-2009 |
01 |
| 901 |
12575412 |
FLY |
D (LY7) |
2008-2009 |
01 |
| 902 |
11588884 |
|
|
2008-2009 |
08 |
| K03 |
12608615 |
RING KIT, PSTN (INCLS 213-216) (STD) |
D (LY7) |
2008-2009 |
06 |
| K04 |
12598657 |
BEARING KIT, CONN ROD (INCLS 203, 204)
| D (LY7) |
2008-2009 |
06 |
|
