| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
24238683 |
CYLINDER, CLU MAS (INCLS 12) |
DN (MN6) |
2009-2009 |
01 |
| 002 |
89047699 |
SENSOR, CLU PED POSN ( |
D (MN6) |
2009-2010 |
01 |
| 003 |
11515755 |
|
|
2009-2010 |
02 |
| 004 |
11609999 |
SCREW, HEX HD FL WA, M4X0.7X20, 13 THD, 12 OD, 9.8, GMW3044, W/NYLON ( |
|
2009-2010 |
01 |
| 005 |
11609746 |
|
|
2009-2010 |
02 |
| 006 |
|
BUSHING, CLU PED RTN SPR ( |
|
2009-2010 |
|
| 007 |
|
BUSHING, CLU PED RTN SPR GDE ( |
|
2009-2010 |
|
| 008 |
|
|
|
2009-2010 |
|
| 009 |
|
PAD, CLU PED ( |
|
2009-2010 |
|
| 010 |
25858073 |
PEDAL, CLU (W/BRKT) (INCLS 2, 4, 6-9, 13) |
DN (MN6, W2E) |
2009-2009 |
01 |
| 010 |
25932331 |
PEDAL, CLU (W/BRKT) (INCLS 2, 4, 6-9, 13) |
DN (MN6, AQ9) (EXC KAE) |
2009-2010 |
01 |
| 011 |
11609411 |
|
|
2009-2010 |
01 |
| 012 |
|
CAP, CLU M/CYL RSVR ( |
|
2009-2010 |
|
| 013 |
25855318 |
HARNESS, CLU SHFT CONT ACTR WRG ( |
DN |
2009-2010 |
01 |
