| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
|
REINFORCEMENT, STRG COL SUPT BRKT |
|
2008-2010 |
|
| 002 |
25785092 |
BARRIER, BRK PED BRKT SND |
DM69 (MV1, MV7, MN6) |
2008-2008 |
01 |
| 002 |
25913292 |
BARRIER, BRK PED BRKT SND |
DM69 (MYB, MX0, MX7) |
2008-2009 |
01 |
| 003 |
|
BRACKET, BRK PED ( |
|
2008-2008 |
|
| 004 |
|
|
|
2008-2008 |
|
| 005 |
11517518 |
|
|
2008-2010 |
01 |
| 006 |
11514519 |
|
|
2008-2010 |
06 |
| 007 |
|
STUD, BRK PED BRKT ( |
|
2008-2008 |
|
| 008 |
|
BRACKET, BRK PED ( |
|
2008-2008 |
|
| 009 |
03817880 |
RETAINER, BRK PED PUSH ROD ( |
D |
2008-2010 |
01 |
| 010 |
15849743 |
ROD, BRK PED PUSH ( |
DM (MYB, MN6) |
2008-2008 |
01 |
| 011 |
00410230 |
WASHER, |
|
2008-2010 |
01 |
| 012 |
25771615 |
COVER, BRK PED ( |
D |
2008-2008 |
01 |
| 013 |
15254562 |
PEDAL, BRK (W/BRKT) (INCLS 3-5, 7-12, 14-19) |
D69 (MYB) |
2008-2008 |
01 |
| 013 |
15254563 |
PEDAL, BRK (W/BRKT) (INCLS 3-5, 7-12, 14-19) |
D69 (MN6) |
2008-2008 |
01 |
| 014 |
25814705 |
SENSOR KIT, BRK PED POSN ( |
DM |
2008-2010 |
01 |
| 015 |
|
PIN, BRK PED PUSH ROD ( |
|
2008-2008 |
|
| 016 |
|
PIN, BRK PED PIV ( |
|
2008-2008 |
|
| 017 |
15594358 |
BUSHING, BRK PED PIV ( |
D |
2008-2010 |
02 |
| 018 |
10434956 |
BUSHING, BRK PED PUSH ROD ( |
D |
2008-2010 |
01 |
| 019 |
11609999 |
SCREW, HEX HD FL WA, M4X0.7X20, 13 THD, 12 OD, 9.8, GMW3044, W/NYLON ( |
|
2008-2010 |
01 |
| 020 |
11609411 |
|
|
2008-2010 |
08 |
