| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
13503838 |
SENSOR, AIRBAG F/END DISCRM (INCLS BOLT) |
DM, DN |
2011-2013 |
02 |
| 002 |
21996989 |
TAG, I/P AIRBAG WRNG (HANGING) |
DM, DN47 |
2011-2013 |
01 |
| 003 |
13503838 |
SENSOR, AIRBAG SI IMP (INCLS BOLT) |
DM, DN |
2011-2013 |
04 |
| 004 |
11609989 |
BOLT, AIRBAG DIAGN ENGY RESV MDL (SDM CAST GROUNDING ATTACHMENT) (M6X1X25, 15 THD, 17 OD) (8.900) |
D |
2011-2013 |
04 |
| 005 |
13580450 |
MODULE, AIRBAG SEN DIAGN |
D35-47-69 |
2011-2013 |
01 |
| 006 |
11561645 |
NUT, AIRBAG DIAGN ENGY RESV MDL (SDM CASE GROUNDING ATTACHMENT) (M6X1, 3.45THK, 13.5 OD) (CONTAINS CONDUCTIVE FINISH FOR ELECTRICAL GROUND) (8.915) |
D |
2011-2013 |
02 |
| 007 |
20936094 |
AIRBAG, STRG WHL (EBONY) |
DM47 (4AL, 4AM, 4AR) |
2011-2013 |
01 |
| 007 |
20936094 |
AIRBAG, STRG WHL (EBONY) |
DN47 (4AL, 4AM, 4BZ) |
2011-2013 |
01 |
| 008 |
15685170 |
NUT, I/P AIRBAG (PSIR MODULE TO I/P RETAINER) (M6X1.0, 19.0MM OD) (8.917) |
DM |
2011-2013 |
06 |
| 008 |
15685170 |
NUT, I/P AIRBAG (PSIR MODULE TO I/P RETAINER) (M6X1.0, 19.0MM OD) (8.917) |
DN |
2011-2013 |
06 |
| 009 |
11561388 |
BOLT, I/P AIRBAG (M6X1X20, 11 THD, 17 OD) (8.900) |
D47 |
2011-2013 |
01 |
| 010 |
22836131 |
AIRBAG, I/P |
DM, DN47 |
2013-2013 |
01 |
