| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
25831579 |
SENSOR, W/S O/S MSTRE (W/O BRACKET) (ACDelco #25831579) |
D35-47 (CE1) |
2012-2013 |
01 |
| 002 |
22792725 |
COVER, W/S M/FUNC SEN MT BRKT |
D47 (CE1, UAV, U2S, U2Y) |
2012-2013 |
01 |
| 002 |
22863531 |
COVER, W/S M/FUNC SEN MT BRKT |
D47 (CE1, U2X) |
2012-2013 |
01 |
| 003 |
20935701 |
COVER, I/S RR VIEW MIR WRG HARN UPR |
DM47 (UAV, U2R, U2S, U2T, U2Y) (EXC CE1) |
2012-2013 |
01 |
| 003 |
22761849 |
COVER, I/S RR VIEW MIR WRG HARN UPR |
DM47 (U2X) (EXC CE1) |
2012-2013 |
01 |
| 004 |
|
HARNESS, W/S HDR WRG (SEE GROUP 10.000 ROOF TRIM/INTERIOR FOR DETAILED ILLUSTRATED VIEW) |
|
2012-2013 |
|
| 005 |
13501863 |
MIRROR, I/S RR VIEW (INCLS 6) |
DM (DD8, UVC, U2R, U2S, U2T) (EXC UE1) |
2012-2013 |
01 |
| 005 |
13580410 |
MIRROR, I/S RR VIEW (INCLS 6) |
DM (DD8, UE1, UVC, U2R, U2S, U2T) |
2012-2013 |
01 |
| 005 |
13503047 |
MIRROR, I/S RR VIEW (INCLS 6) |
DM (DD8, UAV, U2X, U2Y) (EXC UE1) |
2012-2013 |
01 |
| 005 |
13503047 |
MIRROR, I/S RR VIEW (INCLS 6) |
DN (DD8) (EXC UE1) |
2012-2013 |
01 |
| 005 |
13584891 |
MIRROR, I/S RR VIEW (INCLS 6) (ROUND BOTTOM SHAPE) |
DM (DD8, UAV, U2X, U2Y, UE1, UVC) |
2012-2013 |
01 |
| 005 |
13584891 |
MIRROR, I/S RR VIEW (INCLS 6) (ROUND BOTTOM SHAPE) |
DN (DD8, UE1) |
2012-2013 |
01 |
| 005 |
13584891 |
MIRROR, I/S RR VIEW (INCLS 6) (ROUND BOTTOM SHAPE) |
DM (DD8, UE1) (EXC UVC) |
2012-2013 |
01 |
| 006 |
|
BOLT, I/S RR VIEW MIR (PART OF 5) |
|
2012-2013 |
|
| 007 |
15226443 |
ANTENNA, NAVIGATION TRAFFIC DATA (VICS) |
D35-47-69 (U2X) |
2012-2013 |
01 |
| 008 |
20626174 |
BRACKET, NAVN ANT (PART OF 19) (10.187) |
DM, DN47 (U2X) |
2012-2013 |
01 |
| 009 |
25653132 |
BRACKET, I/S RR VIEW MIR (PART OF 19) (10.187) |
D47 |
2012-2013 |
01 |
| 010 |
|
BRACKET, W/S O/S MSTRE SEN (PART OF 19) |
|
2012-2013 |
|
| 011 |
|
RIVET, VIN PLT |
|
2012-2013 |
|
| 012 |
|
PLATE, VIN |
|
2012-2013 |
|
| 013 |
|
TAPE, VIN PLT |
|
2012-2013 |
|
| 014 |
25921038 |
PANEL, AIR INL GRL (SEE GROUP 10.000 WIPER SYSTEM/WINDSHIELD FOR DETAILED ILLUSTRATED VIEW) |
DN47 (LSA, MG9) |
2012-2013 |
01 |
| 014 |
25921038 |
PANEL, AIR INL GRL (SEE GROUP 10.000 WIPER SYSTEM/WINDSHIELD FOR DETAILED ILLUSTRATED VIEW) |
DM47 (LFX, MG9) |
2012-2013 |
01 |
| 014 |
25949050 |
PANEL, AIR INL GRL (SEE GROUP 10.000 WIPER SYSTEM/WINDSHIELD FOR DETAILED ILLUSTRATED VIEW) |
DM, DN47 (LFX, LSA, MYA, MYD) |
2012-2013 |
01 |
| 015 |
25892885 |
PANEL, AIR INL GRL (SEE GROUP 10.000 WIPER SYSTEM/WINDSHIELD FOR DETAILED ILLUSTRATED VIEW) |
DM |
2012-2013 |
01 |
| 015 |
25892885 |
PANEL, AIR INL GRL (SEE GROUP 10.000 WIPER SYSTEM/WINDSHIELD FOR DETAILED ILLUSTRATED VIEW) |
DN |
2012-2013 |
01 |
| 016 |
|
SEAL, W/S LWR FRM REINF (PART OF 19) |
|
2012-2013 |
|
| 017 |
|
MOLDING, W/S UPR RVL (PART OF 19) |
|
2012-2013 |
|
| 018 |
|
ADHESIVE, W/S |
|
2012-2013 |
|
| 019 |
22789194 |
WINDSHIELD, (INCLS 8-10, 16, 17) |
D47 (CE1, U2X) |
2012-2013 |
01 |
| 019 |
22789195 |
WINDSHIELD, (INCLS 9, 10, 16, 17) |
D47 (CE1, UAV, U2R, U2S, U2T, U2Y) |
2012-2013 |
01 |
| 019 |
25941953 |
WINDSHIELD, (INCLS 9, 16, 17) (W/O BRACKET, NAVN ANT) |
D47 (UAV, U2S, U2T, U2Y) (EXC CE1) |
2012-2013 |
01 |
| 019 |
22768333 |
WINDSHIELD, (INCLS 8, 9, 16, 17) (W/BRACKET, NAVN ANT) |
D47 (U2X) (EXC CE1) |
2012-2013 |
01 |
