| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
25795029 |
PANEL, R/WDO DRN |
DM, DN47 |
2011-2013 |
01 |
| 002 |
25978127 |
PANEL, R/WDO |
DM, DN47 |
2011-2013 |
01 |
| 003 |
25839351 |
TRAY, BAT |
D47 |
2011-2012 |
01 |
| 004 |
|
EXTENSION, LOAD FLR PNL C/BAR |
|
2012-2013 |
|
| 005 |
|
BAR, FLR PNL RR INTER CR |
|
2012-2013 |
|
| 006 |
25650571 |
BRACKET, SPA WHL STOW (PART OF 8) (55.1X84.5X126) (3 RECTANGULAR ATTACH BOLT HOLES) |
D |
2011-2013 |
01 |
| 007 |
25978128 |
PANEL, R/END |
DM, DN47 |
2011-2013 |
01 |
| 008 |
25978220 |
PANEL, R/CMPT FLR (INCLS 6) |
DM, DN47 |
2011-2013 |
01 |
| 009 |
|
BAR, FLR PNL #4 |
|
2012-2013 |
|
| 010 |
|
SEAL, FLR K/UP PNL (TO RKR INR PNL) |
|
2012-2013 |
|
| 011 |
25675853 |
BRACKET, F/TNK |
D |
2011-2013 |
02 |
| 012 |
|
PLATE, R/SEAT BELT ANC (BKL SI) |
|
2012-2013 |
|
| 013 |
15251409 |
EXTENSION, FLR PNL #5 C/BAR |
D47 |
2011-2013 |
02 |
| 014 |
20884792 |
BAR, FLR PNL #5 |
D47 |
2011-2013 |
01 |
| 015 |
25859828 |
REINFORCEMENT KIT, R/CMPT FLR PNL RL INTER |
DM, DN |
2011-2013 |
01 |
| 015 |
25859827 |
REINFORCEMENT KIT, R/CMPT FLR PNL RL INTER (INSTRUCTION #19120709) |
DM, DN |
2011-2013 |
01 |
| 016 |
|
EXTENSION, R/CMPT FLR PNL RL (PART OF 17, 18) |
|
2012-2013 |
|
| 017 |
20777232 |
RAIL, R/CMPT FLR PNL (W/RR SUSP SUPT) (PART OF 18) (INCLS 16) |
DM, DN47 |
2011-2013 |
01 |
| 017 |
22745739 |
RAIL, R/CMPT FLR PNL (W/RR SUSP SUPT) (PART OF 18) (INCLS 16) |
DM, DN47 |
2011-2013 |
01 |
| 018 |
20835770 |
RAIL, R/CMPT FLR PNL RR (INCLS 16, 17, 19, 20) |
D47 |
2011-2013 |
01 |
| 018 |
20835771 |
RAIL, R/CMPT FLR PNL RR (INCLS 16, 17, 19, 20) |
D47 |
2011-2013 |
01 |
| 019 |
11519001 |
NUT, RR SUSP FRM (PART OF 18) (HEX, M16X2.0X37.9, OD 50, SAE1010, PLAIN.TEFLON) (8.899) |
D |
2011-2013 |
02 |
| 020 |
25911674 |
REINFORCEMENT, RR SUSP SUPT (PART OF 18) |
D |
2011-2013 |
01 |
| 020 |
25911675 |
REINFORCEMENT, RR SUSP SUPT (PART OF 18) |
D |
2011-2013 |
01 |
| 021 |
20899301 |
PANEL, RKR INR |
D47 |
2011-2013 |
01 |
| 021 |
20899302 |
PANEL, RKR INR |
D47 |
2011-2013 |
01 |
| 022 |
|
REINFORCEMENT, FLR PNL CTR |
|
2012-2013 |
|
| 023 |
22754956 |
REINFORCEMENT, FLR PNL #4 C/BAR |
DN |
2011-2013 |
01 |
| 023 |
25974141 |
REINFORCEMENT, FLR PNL #4 C/BAR |
DM47-35-69 (EXC CZ9) |
2012-2013 |
01 |
| 024 |
11519387 |
BOLT, HWASH, M8X1.25X20, 14 THD, 24 OD, GMW25 (8.8)STEEL, GMW3359, M-POINT. (FLR PNL #4 C/BAR REINF) |
|
2011-2013 |
02 |
| 025 |
25689604 |
BRACKET, PARK BRK CBL (218 X 83 X 59) (ATTACHES TO F/FLR PANEL) |
D |
2011-2013 |
01 |
| 026 |
|
PANEL, FLR PNL FIL (AT TUN PNL) |
|
2012-2013 |
|
| 027 |
|
PANEL, F/FLR |
|
2012-2013 |
|
| 028 |
|
BAR, FLR PNL #2 CR |
|
2012-2013 |
|
| 029 |
|
EXTENSION, FLR PNL #2 C/BAR |
|
2012-2013 |
|
| 030 |
|
EXTENSION, FLR PNL #2 C/BAR |
|
2012-2013 |
|
| 031 |
|
SEALER, F/FLR PANEL |
|
2012-2013 |
|
| 032 |
|
REINFORCEMENT, FLR PNL AT TUN PNL |
|
2012-2013 |
|
| 033 |
|
BRACKET, F/FLR CNSL RR |
|
2012-2013 |
|
| 034 |
|
BAR, FLR PNL #3 CR |
|
2012-2013 |
|
| 035 |
|
EXTENSION, FLR PNL #3 BAR |
|
2012-2013 |
|
| 036 |
|
BAR, FLR PNL #4 CR |
|
2012-2013 |
|
| 037 |
|
BRACKET, VEH YAW SEN LATL ACCLRM |
|
2012-2013 |
|
| 038 |
|
SEAL, FLR K/UP PNL (TO RKR INR PNL) |
|
2012-2013 |
|
| 039 |
|
SEALING STRIP, R/FLR PNL |
|
2012-2013 |
|
| 040 |
11515174 |
SEALING STRIP, FLR PNL DRN HOLE CVR (4 1/4 X 7 1/2) (TRIM AS REQD) (OUTBOARD) (12.941) |
DM, DN47 |
2012-2013 |
02 |
| 041 |
|
SUPPORT, R/SEAT H/RST |
|
2012-2013 |
|
| 042 |
|
PLATE, CHILD ST RST SYS BELT BRKT ANC |
|
2012-2013 |
|
| 043 |
|
PLATE, CHILD ST RST SYS BELT BRKT ANC |
|
2012-2013 |
|
| 044 |
22803880 |
PANEL, RR W/H INR |
D47 |
2011-2013 |
01 |
| 044 |
22803879 |
PANEL, RR W/H INR |
D47 |
2011-2013 |
01 |
| 045 |
20951293 |
REINFORCEMENT, R/WDO PNL |
DM, DN47 |
2011-2012 |
01 |
| 045 |
20951294 |
REINFORCEMENT, R/WDO PNL |
DM, DN47 |
2011-2012 |
01 |
