| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
20954790 |
GUIDE, RF S/RL AIRBAG (INCLS 2, 3) |
D47 |
2011-2011 |
01 |
| 001 |
20954791 |
GUIDE, RF S/RL AIRBAG (INCLS 2, 3) |
D47 |
2011-2011 |
01 |
| 002 |
11609539 |
SCREW, RD CROWNED WA HD, M4.2X1.41X16, STL ISO 2702, GMW4205 (PART OF 1) |
|
2011-2011 |
02 |
| 003 |
11609651 |
RETAINER, R/RL AIRBAG (PART OF 1) (METAL PUSH-IN NUT, M4.2X1.41, 21.8X15X20.5) (14.731) |
D47 |
2011-2011 |
02 |
| 004 |
11519031 |
RETAINER, PUSH IN, 19.5X26.1X1.8, ACETAL, NATURAL, FOAM SEALER (PART OF 15) |
|
2011-2011 |
06 |
| 005 |
|
GROMMET, BODY SI RR T/PNL (PART OF 15) |
|
2011-2011 |
|
| 006 |
|
BOLT, RDO RR S/D SPKR (PART OF 15) |
|
2011-2011 |
|
| 007 |
20879901 |
PLATE, AIRBAG NA (PART OF 10, 18) (EBONY) |
DM47(4AL, 4AM, 4AR) |
2011-2011 |
02 |
| 007 |
20879901 |
PLATE, AIRBAG NA (PART OF 10, 18) (EBONY) |
DN47(4AL, 4AM, 4BZ) |
2011-2011 |
02 |
| 008 |
11609539 |
SCREW, RD CROWNED WA HD, M4.2X1.41X16, STL ISO 2702, GMW4205 (PART OF 10) |
|
2011-2011 |
02 |
| 009 |
11609651 |
RETAINER, CTR PLR UPR G/MLDG (PART OF 10) (METAL PUSH-IN NUT, M4.2X1.41, 21.8X15X20.5) (14.731) |
DM, DN47 |
2011-2011 |
02 |
| 010 |
22752068 |
MOLDING, CTR PLR UPR GARN (INCLS 7-9, 11, 12) (EBONY) (W/O BEZEL ESCUTCHEON) (T/W 20940523) |
DM47(4AL, 4AM, 4AR) |
2011-2011 |
01 |
| 010 |
22752068 |
MOLDING, CTR PLR UPR GARN (INCLS 7-9, 11, 12) (EBONY) (W/O BEZEL ESCUTCHEON) (T/W 20940523) |
DN47(4AL, 4AM, 4BZ) |
2011-2011 |
01 |
| 010 |
22752070 |
MOLDING, CTR PLR UPR GARN (INCLS 7-9, 11, 12) (EBONY) (W/O BEZEL ESCUTCHEON) (T/W 20940525) |
DM47(4AL, 4AM, 4AR) |
2011-2011 |
01 |
| 010 |
22752070 |
MOLDING, CTR PLR UPR GARN (INCLS 7-9, 11, 12) (EBONY) (W/O BEZEL ESCUTCHEON) (T/W 20940525) |
DN47(4AL, 4AM, 4BZ) |
2011-2011 |
01 |
| 011 |
11588650 |
CLIP, 12X14X16.6, GM4345M (PART OF 10) |
|
2011-2011 |
02 |
| 012 |
25992401 |
BEZEL, R/SEAT SHLDR BELT OPG (PART OF 10) (TITANIUM) (CENTER) (16.714) |
D47 |
2011-2011 |
01 |
| 013 |
25725733 |
SPEAKER, RDO RR S/D (PART OF 15) (ACDelco #25725733) |
DM, DN47 |
2011-2011 |
02 |
| 014 |
11519032 |
RETAINER, PUSH IN, 19.5X28.4X1.8, FITS HOLE 9.1, ACETAL, BLK (PART OF 15) |
|
2011-2011 |
04 |
| 015 |
20940499 |
PANEL, BODY SI FRT LWR TR (INCLS 4-6, 13, 14, 16) (EBONY) (BUILT PRIOR TO 7/12/10) (FOR 2ND DES SEE 20966113) |
DM47(4AL) (1ST DES) |
2011-2011 |
01 |
| 015 |
20940500 |
PANEL, BODY SI FRT LWR TR (INCLS 4-6, 13, 14, 16) (CASHMERE) (BUILT PRIOR TO 7/12/10) (FOR 2ND DES SEE 20966114) |
DM47(4AR) (1ST DES) |
2011-2011 |
01 |
| 015 |
20940501 |
PANEL, BODY SI FRT LWR TR (INCLS 4-6, 13, 14, 16) (TITANIUM) (BUILT PRIOR TO 7/12/10) (FOR 2ND DES SEE 22838894) |
DM47(4AM) (1ST DES) |
2011-2011 |
01 |
| 015 |
20940503 |
PANEL, BODY SI FRT LWR TR (INCLS 4-6, 13, 14, 16) (EBONY) (BUILT PRIOR TO 7/12/10) (FOR 2ND DES SEE 20966117) |
DM47(4AL) (1ST DES) |
2011-2011 |
01 |
| 015 |
20940504 |
PANEL, BODY SI FRT LWR TR (INCLS 4-6, 13, 14, 16) (CASHMERE) (BUILT PRIOR TO 7/12/10) (FOR 2ND DES SEE 20966118) |
DM47(4AR) (1ST DES) |
2011-2011 |
01 |
| 015 |
20940505 |
PANEL, BODY SI FRT LWR TR (INCLS 4-6, 13, 14, 16) (TITANIUM) (BUILT PRIOR TO 7/12/10) (FOR 2ND DES SEE 20966119) |
DM47(4AM) (1ST DES) |
2011-2011 |
01 |
| 015 |
20940508 |
PANEL, BODY SI FRT LWR TR (INCLS 4-6, 13, 14, 16) (EBONY) (BUILT PRIOR TO 7/12/10) (FOR 2ND DES SEE 20966122) |
DN47(4AL) (1ST DES) |
2011-2011 |
01 |
| 015 |
20940509 |
PANEL, BODY SI FRT LWR TR (INCLS 4-6, 13, 14, 16) (TITANIUM) (BUILT PRIOR TO 7/12/10) (FOR 2ND DES SEE 20978049) |
DN47(4AM) (1ST DES) |
2011-2011 |
01 |
| 015 |
20940512 |
PANEL, BODY SI FRT LWR TR (INCLS 4-6, 13, 14, 16) (EBONY) (BUILT PRIOR TO 7/12/10) (FOR 2ND DES SEE 20978053) |
DN47(4AL) (1ST DES) |
2011-2011 |
01 |
| 015 |
20959312 |
PANEL, BODY SI FRT LWR TR (INCLS 4-6, 13, 14, 16) (SAFFRON) (BUILT PRIOR TO 7/12/10) (FOR 2ND DES SEE 20978050) |
DN47(4BZ) (1ST DES) |
2011-2011 |
01 |
| 015 |
20959314 |
PANEL, BODY SI FRT LWR TR (INCLS 4-6, 13, 14, 16) (SAFFRON) (BUILT PRIOR TO 7/12/10) (FOR 2ND DES SEE 20978052) |
DN47(4BZ) (1ST DES) |
2011-2011 |
01 |
| 015 |
20966127 |
PANEL, BODY SI FRT LWR TR (INCLS 4-6, 13, 14, 16) (TITANIUM) |
DN47(4AM) |
2011-2011 |
01 |
| 016 |
25794104 |
GUIDE, R/SEAT SHLDR BELT INTER (PART OF 15) (TITANIUM) (CHILD COMFORT GUIDE) (16.714) |
DM, DN47(4AM) |
2011-2011 |
02 |
| 016 |
25794106 |
GUIDE, R/SEAT SHLDR BELT INTER (PART OF 15) (CASHMERE) (CHILD COMFORT GUIDE) (16.714) |
DM47(4AR) |
2011-2011 |
02 |
| 016 |
25794106 |
GUIDE, R/SEAT SHLDR BELT INTER (PART OF 15) (CASHMERE) (CHILD COMFORT GUIDE) (16.714) |
DN47(4BZ) |
2011-2011 |
02 |
| 016 |
25794108 |
GUIDE, R/SEAT SHLDR BELT INTER (PART OF 15) (EBONY) (CHILD COMFORT GUIDE) (16.714) |
DM, DN47(4AL) |
2011-2011 |
02 |
| 017 |
11609539 |
SCREW, RD CROWNED WA HD, M4.2X1.41X16, STL ISO 2702, GMW4205 (PART OF 18) |
|
2011-2011 |
02 |
| 018 |
20997098 |
MOLDING, BODY SI R/WDO GARN (INCLS 7, 17, 19, 20) (EBONY) |
DM47(4AL, 4AM, 4AR) |
2011-2011 |
01 |
| 018 |
20997098 |
MOLDING, BODY SI R/WDO GARN (INCLS 7, 17, 19, 20) (EBONY) |
DN47(4AL, 4AM, 4BZ) |
2011-2011 |
01 |
| 018 |
20997100 |
MOLDING, BODY SI R/WDO GARN (INCLS 7, 17, 19, 20) (EBONY) |
DM47(4AL, 4AM, 4AR) |
2011-2011 |
01 |
| 018 |
20997100 |
MOLDING, BODY SI R/WDO GARN (INCLS 7, 17, 19, 20) (EBONY) |
DN47(4AL, 4AM, 4BZ) |
2011-2011 |
01 |
| 019 |
11588650 |
CLIP, 12X14X16.6, GM4345M (PART OF 18) |
|
2011-2011 |
04 |
| 020 |
11609651 |
RETAINER, BODY SI R/WDO G/MLDG (PART OF 18) (METAL PUSH-IN NUT, M4.2X1.41, 21.8X15X20.5) (14.731) |
DM, DN47 |
2011-2011 |
02 |
