| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
12594935 |
SENSOR, HTD OXY (POSN 1) (ACDelco #213-3850) |
DM(LLT, JJB) |
2011-2011 |
02 |
| 002 |
25857958 |
SEAL, CTLTC CONV (PART OF 3, 9) (INLET SEAL (W/O SHIELD)) |
DM(LLT, JJB) |
2011-2011 |
01 |
| 003 |
25939989 |
CONVERTER, 3WAY CTLTC (INCLS 2, 4, 5, 8) |
DM(LLT, JJB) |
2011-2011 |
01 |
| 004 |
15879730 |
SEAL, CTLTC CONV (PART OF 3, 9) (SPHERICAL OUTLET SEAL) |
DM(LLT, JJB) |
2011-2011 |
02 |
| 005 |
11569946 |
STUD, STRAIGHT, M8X1.25X38, M8X1.25X12, W/EXT SOC, 56 OAL, 10.9, GM6164M (PART OF 3, 9) |
|
2011-2011 |
04 |
| 006 |
11516076 |
NUT, PREVAILING TORQUE TENSION FLG HD (M8X1.25X17.4 OD (EXH MUFF) |
|
2011-2011 |
04 |
| 007 |
|
MUFFLER, EXH (W/EXH TAIL PIPE 3 WAY CTLTC CONV) (SEE GROUP 03.000 EXHAUST SYSTEM/REAR FOR DETAILED ILLUSTRATED VIEW) |
|
2011-2011 |
|
| 008 |
11570494 |
STUD, CTLTC CONV (PART OF 3, 9) (M10X1.5X48, 28 THD, 17 OD) |
DM(LLT, JJB) |
2011-2011 |
02 |
| 009 |
25971634 |
CONVERTER, 3WAY CTLTC (INCLS 2, 4, 5, 8) |
DM(LLT, JJB) |
2011-2011 |
01 |
| 010 |
15032594 |
NUT, CTLTC CONV (HEX M10X1.5) (ATTACH EXH MANIFOLD PIPE) (3.613) (MUST USE T/W STUD 11610853) |
DM |
2011-2011 |
04 |
