| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
11588650 |
CLIP, 12X14X16.6, GM4345M (TRIM TO BODY) (ЧАСТЬ OF 4)
|
2004-2007 |
01 |
|
| 001 |
15769052 |
CLIP, S/S SUPT (TRIM TO BODY) (ЧАСТЬ OF 4) (16.070) |
D69 |
2003-2005 |
02 |
| 002 |
11588650 |
CLIP, 12X14X16.6, GM4345M (TRIM TO BODY) (ЧАСТЬ OF 4)
|
2003-2007 |
01 |
|
| 003 |
11609460 |
SCREW, RND WA, M4.2X1.41X10, 4.2 THD, 11 OD, GM6010M, GMW4205, C/R, TAP (ЧАСТЬ OF 4) |
|
2003-2007 |
01 |
| 004 |
10364903 |
PANEL, QTR UPR TR (INCLS 1-3, 5) (NEUTRAL) |
D69 (70I) |
2003-2005 |
01 |
| 004 |
10364906 |
PANEL, QTR UPR TR (INCLS 1-3, 5) (NEUTRAL) |
D69 (70I) |
2003-2005 |
01 |
| 004 |
15280045 |
PANEL, QTR UPR TR (INCLS 1-3, 5) (GRAY) |
D69 (13I, 19I) |
2004-2007 |
01 |
| 004 |
15280046 |
PANEL, QTR UPR TR (INCLS 1-3, 5) (GRAY) |
D69 (13I, 19I) |
2004-2007 |
01 |
| 005 |
25772916 |
PLUG, C/PLR UPR G/MLDG БОЛТ HOLE FIN (ЧАСТЬ OF 4) (GRAY) (AIRBAG) (14.865)
| D69 (13I, 19I) |
2005-2007 |
02 |
|
| 005 |
25772917 |
PLUG, C/PLR UPR G/MLDG БОЛТ HOLE FIN (ЧАСТЬ OF 4) (NEUTRAL) (AIRBAG) (14.865)
| D (70I) |
2003-2005 |
02 |
|
| 006 |
25670009 |
RETAINER, BODY L/PLR G/MLDG (ЧАСТЬ OF 7) (YELLOW) (9.5MM HOLE) (ROUND) (11.179) |
D69 |
2003-2007 |
02 |
| 007 |
25750532 |
MOLDING, BODY L/PLR GARN (INCLS 6, 8, 9) (EBONY) |
D69 |
2003-2005 |
01 |
| 007 |
25750533 |
MOLDING, BODY L/PLR GARN (INCLS 6, 8, 9) (EBONY) |
D69 |
2003-2005 |
01 |
| 008 |
|
GUIDE, R/SEAT SHLDR BELT (ЧАСТЬ OF 7) |
D (70I) |
2003-2005 |
|
| 008 |
|
GUIDE, R/SEAT SHLDR BELT (ЧАСТЬ OF 7) |
D (19I, 13I) |
2003-2007 |
|
| 009 |
11588477 |
RETAINER, BODY L/PLR G/MLDG (ЧАСТЬ OF 7) (, 8.6X20, ) (PLASTIC TREE) (16.575) |
D69 |
2003-2007 |
06 |
| 010 |
25750537 |
PLATE, RR S/D SILL TR (INCLS 11) (EBONY) |
D69 |
2004-2006 |
01 |
| 010 |
25750538 |
PLATE, RR S/D SILL TR (INCLS 11) (EBONY) |
D69 |
2004-2006 |
01 |
| 011 |
25672428 |
RETAINER, RR S/D SILL TR PLT (ЧАСТЬ OF 10) (7 X 14MM HOLE) (RECTANGLE) (11.175)
| D69 |
2003-2007 |
04 |
|
| 012 |
25757126 |
PANEL, C/PLR LWR TR (INCLS 13, 17, 18) (EBONY) |
D69 |
2004-2005 |
01 |
| 012 |
25757127 |
PANEL, C/PLR LWR TR (INCLS 13, 17, 18) (EBONY) |
D69 |
2004-2005 |
01 |
| 013 |
25732230 |
RETAINER, C/PLR LWR T/PNL (ЧАСТЬ OF 12) (CIRCULAR PUSH-PIN) |
D69 |
2003-2007 |
02 |
| 014 |
25672428 |
RETAINER, FRT S/D SILL TR PLT (ЧАСТЬ OF 16) (7 X 14MM HOLE) (RECTANGLE)
| D69 |
2003-2007 |
08 |
|
| 015 |
11588650 |
CLIP, 12X14X16.6, GM4345M (TRIM TO BODY INNER) (ЧАСТЬ OF 16)
| D69 |
2003-2007 |
02 |
|
| 016 |
15280039 |
PLATE, FRT S/D SILL TR (INCLS 14, 15) (EBONY) |
D69 |
2005-2005 |
01 |
| 016 |
15280040 |
PLATE, FRT S/D SILL TR (INCLS 14, 15) (EBONY) |
D69 |
2005-2005 |
01 |
| 017 |
25672428 |
RETAINER, C/PLR LWR T/PNL (ЧАСТЬ OF 12) (7 X 14MM HOLE) (RECTANGLE) (11.175)
| D69 |
2003-2007 |
06 |
|
| 018 |
11588650 |
CLIP, 12X14X16.6, GM4345M (ЧАСТЬ OF 12)
|
2003-2007 |
01 |
|
| 019 |
11588650 |
CLIP, 12X14X16.6, GM4345M (TRIM TO BODY INNER) (ЧАСТЬ OF 20)
| D69 |
2003-2007 |
04 |
|
| 020 |
15280051 |
PANEL, C/PLR UPR TR (INCLS 19) (GRAY) |
D69 (13I, 19I) |
2004-2007 |
01 |
| 020 |
15280052 |
PANEL, C/PLR UPR TR (INCLS 19) (GRAY) |
D69 (13I, 19I) |
2004-2007 |
01 |
| 020 |
25750046 |
PANEL, C/PLR UPR TR (INCLS 19) (NEUTRAL) |
D69 (70I) |
2003-2005 |
01 |
| 020 |
25750047 |
PANEL, C/PLR UPR TR (INCLS 19) (NEUTRAL) |
D69 (70I) |
2003-2005 |
01 |
