| Поз. | Номер | Описание | Применение | Номенклатура | Кол-во |
| 001 |
11589015 |
БОЛТ, HWH W/FL WA M4.2X1.41X20, 12.5 O.D., DOG PT, 6010M, 7253M (RDO ANT MDL)
|
2003-2007 |
02 |
|
| 002 |
25726417 |
АНТЕННА, ELEK NAVIGATION (ACDelco #25726417) |
D (U2V, U2X, U2Y, UAV) |
2003-2003 |
01 |
| 003 |
11570097 |
ГАЙКА, U-TYPE, M6X1, 21.4X15, 11.7 C/E, SAE 1050 STL, GMW3359. (I/P LWR EXTN)
|
2003-2007 |
04 |
|
| 004 |
11609989 |
БОЛТ, HEX W/FLAT WASHER, M6X1X25, 15 THD, 17 OD, 6202M STL, GMW3200, TAPTITE (RDO BRKT)
|
2003-2007 |
04 |
|
| 005 |
|
RADIO, AM/FM STEREO VIDEO DISC PLYR NAVN (REMAN) (INCLS 6, 7) |
|
2003-2004 |
|
| 005 |
19117628 |
RADIO, AM/FM STEREO VIDEO DISC PLYR NAVN (REMAN) (INCLS 6, 7) (ACDelco #19117628) |
DM69 (UAV) (EXC B18) |
2003-2004 |
01 |
| 006 |
09383426 |
KNOB, RDO TUNING CONT (ЧАСТЬ OF 5) (ACDelco #9383426) |
D (U2X, U2Y, U2V) |
2003-2003 |
01 |
| 006 |
12229132 |
KNOB, RDO TUNING CONT (ЧАСТЬ OF 5) (ACDelco #12229132)
| D69 (UAV) |
2003-2003 |
01 |
|
| 007 |
09383426 |
KNOB, RDO VOL CONT (ЧАСТЬ OF 5) (ACDelco #9383426) |
D (U2X, U2Y, U2V) |
2003-2003 |
01 |
| 007 |
12229132 |
KNOB, RDO VOL CONT (ЧАСТЬ OF 5) (ACDelco #12229132)
| D69 (UAV) |
2003-2003 |
01 |
|
| 008 |
11517722 |
STUD, M6X1X22.5, 12.2 THD, 14 OD, 9.8, 7113M, P-PT (RDO BRKT) |
|
2003-2007 |
04 |
| 009 |
25714920 |
BRACKET, RDO (ACDelco #25714920) |
D69 |
2003-2007 |
02 |
| 010 |
11609411 |
ГАЙКА, HEX W/CON WA, M6X1, 5.7 THK, 16 OD, 9, GMW3200 (RDO BRKT)
|
2003-2007 |
04 |
|
| 011 |
15269166 |
DISC, NAVN MAP (ЧАСТЬ OF 12) |
D69 (UAV) |
2003-2004 |
01 |
| 011 |
25766902 |
DISC, NAVN MAP (ЧАСТЬ OF 12) (EUROPE MAP DVD БЛОК) (EXH STK ON DISC LABEL@OEM 25766902) (LABELED W/OEM PN 25766902.) |
D69 (U2Y) |
2003-2004 |
01 |
| 012 |
25744259 |
CASE, CD STOW (CANADA-DISC ASM) (INCLS 11, 13) |
D (U2V, Z49) |
2003-2003 |
01 |
| 012 |
25744260 |
CASE, CD STOW (US-DISC ASM) (INCLS 11, 13) |
D69 (U2V) (EXC Z49) |
2003-2005 |
01 |
| 013 |
25744257 |
CASE, CD STOW (ЧАСТЬ OF 12) |
D69 (U2Y, U2V) |
2003-2005 |
01 |
